533938-9 Product Details
Live Product Chat
AMP-HDI (Four Beam) & TBC (Twin Beam) Connectors
Not re vie we d for R oHS C om plia nce
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
533938-9
T E I nternal N umber: 5 3 3 9 3 8 - 9
Product Highlights:
l
C onnector
l
Receptacle
l
Number of Positions = 280
l
PC B Mount Style = Through Hole
l
PC B Mount Angle = Right Angle
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Receptacle
l
Number of Positions
= 280
l
PC B Mount Style
= Through Hole
l
PC B Mount Angle
= Right Angle
l
Make First / Break Last
= No
l
Mating Polarization
= Without
l
PC B Retention Feature
= No
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.57 [0.180]
l
Solder Tail C ontact Plating
= Tin-Lead
Body Related Features:
l
Number of Rows
= 4
l
C enterline (mm [in])
= 2.54 [0.100]
Contact Related Features:
l
C ontact Type
= Four-Beam
l
C ontact Mating Area Plating Material
= Gold (50)
l
C ontact Base Material = Beryllium C opper
l
C ontact Underplating = Nickel
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing C olor = Natural
l
Housing Material Temperature = Standard
Configuration Related Features:
l
C enter Guide = Without
Industry Standards:
l
Government/Industry Qualification = Yes
l
Government/Industry Part Number = M55302/180-45B
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
