SR220S
THRU
SR2100S
Elektronische Bauelemente
VOLTAGE 20V ~ 100V
2.0 AMP Schottky Barrier Rectifiers
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DO-41
FEATURES
.107(2.7)
.080(2.0)
DIA.
.
Low forward voltage drop
.
High current capability
.
High reliability
.
High surge current capability
.
Epitaxial construction
MECHANICAL DATA
.034(.9)
.028(.7)
DIA.
1.0(25.4)
MIN.
.205(5.2)
.166(4.2)
1.0(25.4)
MIN.
.
Case: Molded plastic
.
Epoxy: UL 94V-0 rate flame retardant
.
Lead: Axial Lead, solderable per MIL-STD-202,
.
Polarity: Color band denotes cathode end
.
Mounting position: Any
.
Weight: 0.34 grams
method 208 guaranteed
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25
ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYPE NUMBER
SR220S SR230S SR240S SR250S SR260S
Maximum Recurrent Peak Reverse Voltage
20
30
40
50
60
Working Peak Reverse Voltage
20
30
40
50
60
Maximum DC Blocking Voltage
20
30
40
50
60
Maximum Average Forward Rectified Current,
2.0
See Fig. 1
Peak Forward Surge Current, 8.3 ms single
50
half Sine-wave superimposed on rated load
(JEDEC method)
Maximum Instantaneous Forward Voltage at 2.0A
0.50
0.65
Maximum DC Reverse Current
Ta=25
0.2
At Rated DC Blocking Voltage
Ta=100
20
Typical Junction Capacitance (Note1)
170
Typical Thermal Resistance R JA (Note 2)
35
Operating Temperature Range T
J
-50 ~ +150
Storage Temperature Range T
STG
-65 ~ +170
NOTES:
1. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
2. Thermal Resistance Junction to Ambient Vertical PC Board Mounting 0.5"(12.7mm) Lead Length.
SR280S
80
80
80
SR2100S
100
100
100
UNITS
V
V
V
A
A
0.83
V
mA
pF
/W
http://www.SeCoSGmbH.com/
01-Jun-2003 Rev. B
Any changing of specification will not be informed individual
Page 1 of 2
SR220S
THRU
SR2100S
Elektronische Bauelemente
VOLTAGE 20V ~ 100V
2.0 AMP Schottky Barrier Rectifiers
RATING AND CHARACTERISTIC CURVES (SR220S THRU SR2100S)
FIG.1-TYPICAL FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD CURRENT,(A)
FIG.2-TYPICAL FORWARD
CHARACTERISTICS
2.4
2.0
50
INSTANTANEOUS FORWARD CURRENT,(A)
1.6
2
SR
SR
1.2
0.8
0.4
0
0
20
40
60
80
SR
22
0
~S
SR
26
SR
28
3.0
1.0
0
0~
SR
21
00
100
120
140
160
180
200
AMBIENT TEMPERATURE,( C)
SR
25
0~
R2
40
10
FIG.3-MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
50
22
0~
SR
24
0
~
50
SR
21
00
Tj=25 C
Pulse Width 300us
1% Duty Cycle
0.1
PEAK FORWARD SURGE CURRENT,(A)
40
.01
.1
.3
.5
.7
.9
1.1
1.3
1.5
30
Tj=25 C
8.3ms Single Half
Sine Wave
JEDEC method
FORWARD VOLT
AGE,(V)
20
10
FIG.5 - TYPICAL REVERSE
0
1
5
10
50
100
CHARACTERISTICS
100
NUMBER OF CYCLES AT 60Hz
FIG.4-TYPICAL JUNCTION CAPACITANCE
700
600
500
400
300
200
100
0
JUNCTION CAPACITANCE,(pF)
REVERSE LEAKAGE CURRENT, (mA)
10
1.0
Tj=75 C
.1
Tj=25 C
.01
.05
.1
.5
1
5
10
50
100
.01
0
20
40
60
80
100 120 140
REVERSE VOLTAGE,(V)
PERCENT OF RATED PEAK REVERSE VOLT
AGE,(%)
http://www.SeCoSGmbH.com/
01-Jun-2003 Rev. B
Any changing of specification will not be informed individual
Page 2 of 2
