E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Power Beads Type
S
application
Available in low profile and used in high power
CHEMATICS
Ideal for high current devices
Custom inductance value or tolerance is available
RoHS compliant version is available
E
LECTRICAL
S
PECIFICATION
@ 25
o
C
Inductance Irated
3
RoHS
(Adc)
Part Number @Irated
(nH Typ)
831-02962F
831-02963F
831-02964F
831-02965F
831-02962F
831-02963F
831-02964F
831-02965F
74
105
153
225
297
423
612
900
40
40
34
24
20
20
19
14
DCR
1
(m
Ω
)
Typ
0.18
0.18
0.18
0.18
0.74
0.74
0.74
0.74
Max
0.225
0.225
0.225
0.225
0.9
0.9
0.9
0.9
2
Part
Number
831-02962
831-02963
831-02964
831-02965
831-02962
831-02963
831-02964
831-02965
Inductance
(nH±20%)
82.5
118
170
250
330
470
680
1000
Saturation Current
(Adc)
25
o
C
40
40
40
35
40
37
25
18
125
o
C
40
40
34
24
32
26
19
14
4
5
Heating Current Connection Marking
(Adc)
40
40
40
40
20
20
20
20
Parallel
Parallel
Parallel
Parallel
Series
Series
Series
Series
2962
2963
2964
2965
2962
2963
2964
2965
Notes:
1. The DCR is measured from point a to point b, as shown on the mechanical drawing.
2. Inductance is tested at 0.1Vrms, 1MHz.
3. The rated current as listed is either the saturation current or the heating current depending on which value is lower.
4. The saturation current, Isat, is the current at which the inductance of the component drops by 10% typical at an
ambient temperature of 25ºC.
5. The heating current is the DC current required to raise the component temperature by approximately 40ºC at ambient
temperature of 25ºC. For parallel connection, the heating current of this part is 40A. For series connection, the heating
current of this part is 20A.
6. Operating temperature range: -40ºC to +130ºC. The part temperature (ambient temperature + temperature rise)
should not exceed the upper limit of the operating temperature under worst case operating conditions. Circuit
design, component placement, PWB trace size and thickness, airflow and other cooling provisions all affect the
part temperature. Part temperatures should be verified in the end application.
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
1
Tel: (852) 2765 3888
Fax: (852) 2954 3304
PI137(01)
Revised in 06/07
E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Power Beads Type
S
CHEMATICS
M
ECHANICAL
D
IMENSIONS
.300
7.62
2x .140
3.56
.300
7.62
4
3
.510
12.95 Max
.550
13.97
.250
6.35
.550
13.97
.250
6.35
1
2
.510 Max
12.95
Parallel Configuration
Series Configuration
Recommended Pad Layout
for different configurations
.280
7.11 Max
Reference or
Gauge Plane
.120
Max
3.05
.160
±
.010
4.06
±
0.25
b
a
1
.125
Typ
3.18
Weight (in gram)
Tape & Reel
:
:
4.20 typ.
350 / reel
Notes:
inches
mm
with higher precedence in mm.
.010
8. Unless otherwise specified, all tolerances are ±
0.25
.
7. All dimensions are specified in
9. For available RoHS part number, the part will be marked with “XXXXF”, instead of “XXXX”.
S
CHEMATICS
2
2
1
2
1
1
4
3
4
3
4
3
DUAL INDUCTOR CONNECTION
PARALLEL CONNECTION
SERIES CONNECTION
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
2/F Block A, Merit Industrial Centre,
94 Tokwawan Road, Kowloon,
Hong Kong
Tel: (852) 2765 3888
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: http://www.eleceltek.com
