36701JR33KJIT: Description1 ELEMENT, 0.33uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0603, ROHS COMPLIANT; CategoryPassive components inductor; File Size99KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

36701JR33KJIT Overview

1 ELEMENT, 0.33uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0603, ROHS COMPLIANT

36701JR33KJIT Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1646066059
package instruction	0603
Reach Compliance Code	unknown
ECCN code	EAR99
uppercase and lowercase codes	0603
DC Resistance	0.85 Ω
Nominal inductance(L)	0.33 µH
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3670
Number of functions	1
Number of terminals	2
Minimum quality factor (at nominal inductance)	15
Maximum rated current	0.035 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	10%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

36701JR33KJIT Product Details

Live Product Chat

Inductors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

36701JR33KJIT

(1624114-8)

T E I nternal N umber: 1 6 2 4 1 1 4 - 8

Product Highlights:

Inductor

Inductor Type = High Frequency

Lead Type = Surface Mount Terminals

Multilayer Ferrite

Inductance = .33 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

HIGH FREQUENC Y INDUC TORS SMD SERIES 3670 0603

(PDF, English)

Catalog Pages/Data Sheets:

High Frequency Inductors SMD - Type 3670 Series - Ty...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = High Frequency

Element

= Multilayer Ferrite

Shielded

= No

Electrical Characteristics:

Inductance (?H)

= 0.33

DC Resistance (?)

= 0.85

C urrent, Maximum (mA)

= 35

Quality Factor

= 15

Package Type

= Taped and Reeled

Tolerance (%) = 10

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3670

Packaging Style

= 0603

Package, C omponent Size

= 1.6 x 0.8

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Operation/Application:

Application

= High Frequency

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

36701JR33KJIT Related Products

	36701JR33KJIT	1624114-8
Description	1 ELEMENT, 0.33uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0603, ROHS COMPLIANT	1 ELEMENT, 0.33uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0603, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
Objectid	1646066059	1646063487
package instruction	0603	0603
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
uppercase and lowercase codes	0603	0603
DC Resistance	0.85 Ω	0.85 Ω
Nominal inductance(L)	0.33 µH	0.33 µH
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3670	3670
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	15	15
Maximum rated current	0.035 A	0.035 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	10%	10%
