AN5220: DescriptionTV SOUND IF AMPLIFIER FM DETECTOR CIRCUITS; CategoryAnalog mixed-signal IC Consumption circuit; File Size115KB，3 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html

Download Datasheet Parametric Compare View All

AN5220 Overview

TV SOUND IF AMPLIFIER FM DETECTOR CIRCUITS

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	DIP, DIP14,.3
Reach Compliance Code	unknow
JESD-30 code	R-PDIP-T14
JESD-609 code	e0
Number of terminals	14
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP14,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Base Number Matches	1

	AN5220	AN5221
Description	TV SOUND IF AMPLIFIER FM DETECTOR CIRCUITS	TV SOUND IF AMPLIFIER FM DETECTOR CIRCUITS
Is it Rohs certified?	incompatible	incompatible
package instruction	DIP, DIP14,.3	DIP, DIP14,.3
Reach Compliance Code	unknow	unknow
JESD-30 code	R-PDIP-T14	R-PDIP-T14
JESD-609 code	e0	e0
Number of terminals	14	14
Maximum operating temperature	70 °C	70 °C
Minimum operating temperature	-20 °C	-20 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP
Encapsulate equivalent code	DIP14,.3	DIP14,.3
Package shape	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified
surface mount	NO	NO
technology	BIPOLAR	BIPOLAR
Temperature level	COMMERCIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL
Base Number Matches	1	1
