MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
Downsized, 85C
@Downsized
from current standard SMG series
@Endurance
: 2,000 hours at 85C
@Non
solvent resistant type
@RoHS
Compliant
SMQ
Downsized
SMG
?SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
-40 to +85C(6.3 to 400V
dc
)
-25 to +85C(450V
dc
)
Characteristics
6.3 to 450V
dc
P20%
(M)
6.3 to 100V
dc
[F18
I=0.03CV or 4MA, whichever is greater.
(at 20C, 120Hz)
160 to 450V
dc
Time
After 1minute
CV
CV[1,000 I=0.1CV+40 max.
CV
>
1,000 I=0.04CV+100 max.
(at 20C)
(at 20C after 3 minutes)
(at 20C after 1 minute)
Dissipation Factor
(tane)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Shelf Life
]F20
I=0.03CV
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
Rated voltage (V
dc
)
6.3V 10V 16V 25V 35V 50V
63V 100V 160 to 250V 315 to 400V 450V
tanE (Max.)
0.28 0.24 0.20 0.16 0.14 0.12 0.09 0.08
0.20
0.24
0.24
(at 20C, 120Hz)
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase.
Rated voltage (V
dc
)
6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 200V 250V 350V 400V 450V
Z(-25C)/Z(+20C)
[F8
6
2
2
2
2
4
2
3
3
3
4
4
5
]F10
6
2
2
2
2
4
2
3
3
3
4
4
5
Z(-40C)/Z(+20C)
[F8
3
3
3
4
8
5
10
8
8
10
8
12
-
]F10
12
3
3
3
4
6
5
4
8
4
10
6
- (at 120Hz)
The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 2,000 hours
at 85C.
Capacitance change
[P20%
of the initial value
D.F. (tanE)
[200%
of the initial specified value
Leakage current
[The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 85C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Rated voltage
6.3 to 100V
dc
160 to 450V
dc
Capacitance change
[P20%
of the initial value
[P20%
of the initial value
D.F. (tanE)
[200%
of the initial specified value
[200%
of the initial specified value
Leakage current
[The
initial specified value
[500%
of the initial specified value
?DIMENSIONS
[mm]
@Terminal
Code : E
FP0.5
FP0.5
(F12.5 to
F18)
FD'
Vent
(except
F5)
L'
15min.
Fd
f5
to
f18
Sleeve (PET : Black)
4min.
(F5 to
F10)
Gas escape end seal
FP0.5
Fd
]f20
FD'
Sleeve (PET : Black)
Vent
L'
15min.
4min.
fD
fd
F
fD'
L'
5
0.5
2.0
6.3
0.5
2.5
10 12.5
8
0.6 0.6 0.6
3.5 5.0 5.0
FD+0.5max.
L+1.5max.
16
0.8
7.5
18
0.8
7.5
22
20
1.0
1.0
10.0 10.0
FD+0.5max.
L+2.0max.
?PART
NUMBERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
E S MQ
A A A
E
A A A A A
M
A A A
N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0MF:1R0,10MF:100,100MF:101)
Lead forming·taping code
Terminal code
Voltage code (ex. 6.3V:6R3,50V:500,100V:101)
Series code
Category
Please refer to "Product code guide
(radial lead type)"
(1/3)
CAT. No. E1001K
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
Downsized, 85C
?STANDARD
RATINGS
WV
(V
dc
)
Cap
(mF)
10
22
33
47
68
100
1.0
2.2
3.3
4.7
10
22
33
47
68
100
Case size
fDbL(mm)
10B12.5
12.5B20
12.5B25
16B25
16B25
18B31.5
6.3B11
8B11.5
8B11.5
10B12.5
10B16
12.5B25
16B25
16B25
16B31.5
18B35.5
Rated ripple
current
tane
(mArms/
85c,120Hz)
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
90
185
240
325
400
530
22
38
48
60
90
205
275
280
340
440
Part No.
WV
(V
dc
)
Cap
(mF)
2.2
3.3
4.7
10
22
33
47
68
100
Case size
fDbL(mm)
8B11.5
10B12.5
10B12.5
10B20
12.5B25
16B25
16B31.5
18B35.5
18B40
Rated ripple
current
tane
(mArms/
85c,120Hz)
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
28
40
46
80
140
180
220
260
280
Part No.
350
400
ESMQ351ESS100MJC5S
ESMQ351ESS220MK20S
ESMQ351ESS330MK25S
ESMQ351ESS470ML25S
ESMQ351ESS680ML25S
ESMQ351ESS101MMN3S
ESMQ401ESS1R0MF11D
ESMQ401ESS2R2MHB5D
ESMQ401ESS3R3MHB5D
ESMQ401ESS4R7MJC5S
ESMQ401ESS100MJ16S
ESMQ401ESS220MK25S
ESMQ401ESS330ML25S
ESMQ401ESS470ML25S
ESMQ401ESS680MLN3S
ESMQ401ESS101MMP1S
450
ESMQ451ESS2R2MHB5D
ESMQ451ESS3R3MJC5S
ESMQ451ESS4R7MJC5S
ESMQ451ESS100MJ20S
ESMQ451ESS220MK25S
ESMQ451ESS330ML25S
ESMQ451ESS470MLN3S
ESMQ451ESS680MMP1S
ESMQ451ESS101MM40S
SS
: Enter the appropriate lead forming or taping code.
?RATED
RIPPLE CURRENT MULTIPLIERS
@Frequency
Multipliers
(F5 to
F18)
Capacitance (mF)
Frequency (Hz)
(F20 to
F22)
50
0.65
0.75
0.80
0.85
120
1.00
1.00
1.00
1.00
300
1.35
1.25
1.15
1.03
1k
1.75
1.50
1.30
1.05
10k
2.30
1.75
1.40
1.08
100k
2.50
1.80
1.50
1.08
Frequency (Hz)
Rated Voltage (V
de
)
1.0 to 4.7
10 to 68
100 to 1,000
2,200 to
6.3 to 50
63 to 100
50
0.95
0.92
120
1.00
1.00
300
1.03
1.07
1k
1.05
1.13
10k
1.08
1.19
100k
1.08
1.20
The endurance of capacitors is reduced with internal heating produced by ripple current at the rate of halving the lifetime with every 5C rise.
When long life performance is required in actual use, the rms ripple current has to be reduced.
(3/3)
