MX-0410-BET-2001-5M0000000 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> MX-0410-BET-2001-5M0000000

MX-0410-BET-2001-5M0000000: DescriptionSine Output Oscillator; CategoryPassive components oscillator; File Size375KB，4 Pages; ManufacturerVectron International, Inc.; Websitehttp://www.vectron.com/

Download Datasheet Parametric View All

MX-0410-BET-2001-5M0000000 Overview

Sine Output Oscillator

MX-0410-BET-2001-5M0000000 Parametric

Parameter Name	Attribute value
Objectid	1253570337
Reach Compliance Code	compliant
Other features	SC-CUT CRYSTAL
Ageing	0.02 PPM/FIRST YEAR
Maximum control voltage	5 V
Minimum control voltage
Frequency Adjustment - Mechanical	NO
frequency stability	0.0002%
Frequency Stability - Voltage	0.0005 ppm
input power	2 W
Installation features	THROUGH HOLE MOUNT
Number of terminals	5
offset frequency	1 kHz
Nominal operating frequency	5 MHz
Maximum operating temperature	70 °C
Minimum operating temperature
Oscillator type	SINE
Output impedance	50 Ω
Output level	1.416 V
Oven power supply voltage	12V
Encapsulate equivalent code	DIP5/6,1.6,800
phase noise	-145 dBc/Hz
physical size	50.8mm x 50.8mm x 14.55mm
Maximum supply voltage	12.6 V
Minimum supply voltage	11.4 V
Nominal supply voltage	12 V
surface mount	NO
Preheating power	4 W
Maximum warm-up time	5 Minute

Preview

Download Datasheet

View All

Oven Controlled Crystal Oscillator

MX-041

Features

•

Ultra-High Stability

Excellent Temperature Stability

SC-Cut Crystal

Frequency Range: 5 MHZ to 15 MHZ

Low Package Height

Applications

• CDMA2000, WiMax, LTE and UMTS Base Stations

• Test and Measurement Equipment

• Broadcast Reference Standard

Performance Specifications

Frequency Stabilities

Parameter

vs. operating temperature range (refer-

enced to +25°C)

Warm-up Time

Initial Tolerance

vs. supply voltage change

vs. load change

vs. aging / day

vs aging/ day

vs. aging / 1 year

vs. aging / year (following years)

Supply voltage (Standard)

Supply voltage (Option)

Power consumption @+5V

Power consumption @+12V

-50

-0.5

-0.1

-0.5

-0.1

-20

-10

4.75

11.4

5.0

12.0

Min

-0.2

-0.4

-0.6

Typ

Max

+0.2

+0.4

+0.6

+50

+0.5

+0.1

+0.5

+0.1

+20

+10

5.25

12.6

Units

ppb

minutes

ppb

VDC

Watts

Condition

0… +70°C

-20… +70°C

-40… +85°C (+5V version)

to ± 10 ppb of final frequency (1 hour) @25°C

at time of shipment, nominal EFC

VS ± 5%

Load ± 5%

after 72 hours of operation

after 7 days of operation

after 72 hours of operation

Supply Voltage (Vs)

during warm-up

steady state @ +25°C

during warm-up

steady state @ +25°C
