MCN
Vishay Techno
Thick Film Capacitor Networks,
Single-In-Line, Molded SIP
FEATURES
Isolated and bussed schematics available
Custom schematics available
NP0 or X7R capacitors for line terminator
Wide
operating
(- 55 °C to 125 °C)
Molded epoxy case
Solder coated copper terminals
Solderability per MIL-STD-202 method 208E
Marking resistance to solvents per MIL-STD-202 method 215
Compliant to RoHS Directive 2002/95/EC
temperature
range
STANDARD ELECTRICAL SPECIFICATIONS
CAPACITANCE RANGE
MODEL
SCHEMATIC
NP0
(1)
01
MCN
02
09
33 pF to 3900 pF
33 pF to 3900 pF
33 pF to 3900 pF
X7R
470 pF to 0.1 µF
470 pF to 0.1 µF
470 pF to 0.1 µF
CAPACITANCE TOLERANCE
(2)
±%
10, 20
10, 20
10, 20
CAPACITANCE VOLTAGE
V
DC
50
50
50
Notes
(1)
NP0 capacitors may be substituted for X7R capacitors
(2)
Tighter tolerances available on request
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: MCN0801N101KTB (preferred part number format)
M
GLOBAL
MODEL
MCN
C
N
0
8
0
1
N
1
0
TOLERANCE
K
= 10 %
M
= 20 %
1
K
T
B
PACKAGING
B
= Bulk
PIN COUNT SCHEMATIC
08
= 8 pin
09
= 9 pin
10
= 10 pin
01
02
09
CHARACTERISTICS CAPACITANCE
VALUE
N =
NP0
X =
X7R
(in picofarads)
2 digit significant
figure, followed
by a multiplier
101
= 100 pF
392
= 3000 pF
104
= 0.1 µF
TERMINAL
FINISH
T
= Sn90/Pb10
C
=
Sn95.5/Ag3.9/Cu0.6
Historical Part Numbering: MCN0801101KS10 (will continue to be accepted)
MCN
HISTORICAL
MODEL
08
PIN COUNT
01
SCHEMATIC
101
CAPACITANCE
VALUE
K
TOLERANCE
S10
TERMINAL
FINISH
*Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 68004
Revision: 09-Mar-11
For technical questions, contact:
te1resistors@vishay.com
www.vishay.com
17
