ETD-BL-1T-ON-300S
Order No.: 2917382
The figure shows the ETD-BL-1T-ON- 10S 2917379 version
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2917382
Timer relay with switch-on delay (voltage-controlled) and an adjustable
time range (3 s - 300 s), with screw connection
Product notes
Commercial data
GTIN (EAN)
4
046356
367493
WEEE/RoHS-compliant since:
12/08/2008
sales group
Pack
Customs tariff
Catalog page information
H310
1 pcs.
85364900
Page 660 (IF-2009)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
Product description
Compact time relay in the 6.2 mm housing in order to control time sequences.
The time is set on the front side using a labeled knurled wheel which is sunk in order to prevent unintentional adjustment.
The time can be set using a screwdriver (blade width 2.5 mm).
The compact time relays are available with varied time ranges as well as with screw and spring-cage connections.
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 1 / 4
Feb 3, 2011
ETD-BL-1T-ON-300S
Order No.: 2917382
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2917382
Technical data
Coil side
Input voltage range
Function
Time setting range
Contact side
Contact type
Output fuse
General data
Width
Height
Depth
Status display
Mechanical service life
Ambient temperature (operation)
Ambient temperature (storage/transport)
Mounting position
Assembly instructions
Color
Housing insulation material
Permissible humidity (operation)
Rated insulation voltage
Conformance
ATEX
UL, USA / Canada
GL
Connection data
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG/kcmil min.
0.14 mm²
2.5 mm²
0.14 mm²
2.5 mm²
26
6.2 mm
80 mm
86 mm
Green LED (POWER)
Yellow LED (relay active)
Approx. 2 x 10 cycles
-20 °C ... 65 °C
-25 °C ... 80 °C
Any
on TS 35 profile rail acc. to EN 60715
green
Polyamide PA, self-extinguishing
15 % ... 85 %
300 V AC (According to EN 50178)
CE-compliant
Ex II 3 G Ex nAC II T4 X
UL/C-UL listed UL 508
GL EMC 1 C
7
24 V DC (19,2 V DC ...30 V DC)
ON: With switch-on delay
3 s ... 300 s
1 floating PDT
6.3 A (fast-blow)
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 2 / 4
Feb 3, 2011
ETD-BL-1T-ON-300S
Order No.: 2917382
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2917382
Conductor cross section AWG/kcmil max
Stripping length
Type of connection
Control contact
Control pulse length
Certificates / Approvals
14
8 mm
Screw connection
min. 50 ms
Certification
CUL Listed, GL, UL Listed
Diagrams/Drawings
Block diagram
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 3 / 4
Feb 3, 2011
ETD-BL-1T-ON-300S
Order No.: 2917382
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2917382
Address
PHOENIX CONTACT Inc., USA
586 Fulling Mill Road
Middletown, PA 17057,USA
Phone (800) 888-7388
Fax (717) 944-1625
http://www.phoenixcon.com
© 2011 Phoenix Contact
Technical modifications reserved;
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 4 / 4
Feb 3, 2011
