Type 278 Tantalum Solid Electrolytic Capacitors are ultra miniature tantalum chip capacitors with case size 2012 (2.0
×
1.25
×
1.2 mm thick). The capacitors are designed to meet the demands for further downsizing of devices.
FEATURES
1. Suitable for surface mounting with high precise dimensional accuracy
2. Soldering : 260°C for 10 seconds by reflow
3. Type 278 is suitable for ultra miniaturized applications, such as DVC, DSC and PCMCIA cards, and high-function compact
portable devices, such as mobile phones and PHS.
4. Lead-free and RoHS Compliant
RATING
Item
Category Temperature Range (Operating Temperature Range)
Rated Temperature (Max. Operating Temp. at Rated Voltage)
Rated Voltage
Capacitance (Nominal Capacitance)
Capacitance Tolerance
Failure Rate Level
Ratings
-55 ~ +125°C
+85°C
2.5 ~ 35 VDC
0.1 ~ 47
µF
±
10%,
±
20%
1%/1000 h
85°C, rated voltage, 1000 hrs., Circuit resistance of
0.5
Ω/V
See CATALOG NUMBERS AND RATING.
Remarks
To be used at derated voltage when temperature
exceeds 85°C (At 125°C, 2/3
×
rated voltage)
STANDARD RATING
R.V.(VDC)
Cap.(µF)
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
2.5
4
June, 2007
6.3
10
16
20
S
S
S
S
S
S
S
S
25
35
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
DIMENSIONS
L
W
Case
size
S
EIA
Code
2012
L
±
0.2
W
±
0.2
Tmax.
P
1
±
0.2
P
2
min.
(mm)
C
±
0.1
T
P
1
P
2
P
1
2.0
1.25
1.2
0.5
0.8
0.9
C
MARKING
[S Case]
Capacitance (
2
)
Rated Voltage (
1
)
Capacitance Tolerance
Polarity (anode notation)
Without bar:
±
20%
With bar:
±
10%
(1)
Rated voltage (VDC)
Code
(2)
Capacitance (µF)
Code
2.5
e
1
A
4
G
6.3
J
1.5
E
10
A
2.2
J
16
C
3.3
N
20
D
25
E
35
V
6.8
W
4.7
S
_
In case to indicate a capacitance not listed above, _ (1/10) or
used. (Ex.: J indicates 1/10 of J (2.2), 0.22).
(10 times) is
RECOMMENDED PAD DIMENSIONS
(mm)
Case
size
S
EIA
Code
2012
a
Flow
2.2
Reflow
1.4
b
1.2
c
0.9
b
c
a
In order to expect the self alignment effect, it is recommended that land width is almost the same size as terminal of capacitor, and space between lands (c)
nearly equal to the space between terminals for appropriate soldering.
−２−
PERFORMANCE
No
Item
Performance
Test method
1
Leakage Current (µA)
Shall be within any of the following ranges and specified according to CATALOG JIS C 5102, 7.7
NUMBERS AND RATING.
Applied voltage: Rated voltage Duration: 5 min
• (0.01 CV or 0.5
µA,
whichever is greater) • 0.02 CV or less
Measuring temperature: Room temperature
Shall be within the specified tolerance.
JIS C 5102, 7.8
Measuring frequency: 120 Hz
±
20% Measuring voltage: 0.5 Vrms +1.5 ~
2 VDC Measuring temperature: Room temperature
JIS C 5102, 7.9
Measuring frequency: 120 Hz
±
20% Measuring voltage: 0.5 Vrms +1.5 ~
2 VDC Measuring temperature: Room temperature
JIS C 5102, 7.12
Leakage Current
Capacitance
Dissipation Factor
Capacitance
Change
Dissipation Factor
Shall not exceed the value in No.1.
Shall be within the specified tolerance.
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
10% of the value at Step 1
• Within
±
20% of the value at Step 1
• Within 0/-30% of the value at Step 1
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall not exceed the value in No.1.
Shall be within
±
2% of the value at Step 1.
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• 0.1 CV or 5
µA,
whichever is greater
• 0.2 CV or less
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
10% of the value at Step 1
• Within
±
20% of the value at Step 1
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• 0.125 CV or 6.3
µA,
whichever is greater • 0.25 CV or less
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
15% of the value at Step 1
• Within
±
20% of the value at Step 1
• Within
±
30% of the value at Step 1
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall not exceed the value in No.1.
Shall be within
±
2% of the value at Step 1.
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Not exceeding the value in No.1: Leakage current code A
• Not exceeding twice the value in No.1: Leakage current code C
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
5% of the value before test
• Within
±
10% of the value before test
• Within
±
20% of the value before test
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
There shall be no evidence of mechanical damage.
No separation of terminal from solder
Measuring temperature: 20
±
2°C
2
Capacitance (µF)
3
Dissipation Factor
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
4
Characteristics at
High and Low
Temperature
Step
1
Measuring temperature: -55 0/-3°C
Step
2
Step
3
Leakage Current
Capacitance Change
Dissipation Factor
Leakage Current
Measuring temperature: 20
±
2°C
Measuring temperature: 85 +3/0°C
Step
4
Capacitance
Change
Dissipation Factor
Leakage Current
Measuring temperature: 125 +3/0°C
Measuring voltage: Derated voltage at 125°C
Step
5
Capacitance
Change
Dissipation Factor
Step
6
5
Surge (VDC)
Leakage Current
Capacitance Change
Dissipation Factor
Leakage Current
Capacitance
Change
Dissipation Factor
Appearance
Measuring temperature: 20
±
2°C
JIS C 5102, 7.14
Test temperature: 85
±
2°C
Applied voltage: According to CATALOG NUMBERS AND RATING
Series protective resistance: 1000
Ω
Discharge resistance: 1000
Ω
6
Shear Test
JIS C 5143, Annex 3
Capacitors mounted under the following conditions are used as specimens.
• Indirect heating method (reflow)
• Temperature: 240
±
10°C Time: Less than 10 sec
Pressure: 5 N Duration: 5
±
1 sec
JIS C5143, Annex 4
Bending: 3 mm Duration: 5 sec
JIS C 5102, 8.2, Type A
Frequency range: 10 to 55 Hz Swing width: 1.5 mm
Vibration direction: 3 directions with mutually right-angled
Duration: 2 hours in each of these mutually perpendicular directions (total 6 hours)
Mounting: Solder terminal to the printed board
JIS C 5102, 8.3, test condition A
Peak acceleration: 490 m/s
2
Duration: 11 ms
Wave form: Half-sine
JIS C 5102, 8.4
Solder temperature: 235
±
5°C
Dipping time: 3 to 5 sec
Dipping depth: Terminal shall be dipped into melted solder.
JIS C 5143, Annex 1
Complete dipping method or terminal dipping method
Solder temperature: 260
±
5°C
Dipping time: 10
±
1 sec
7
8
Terminal Strength
Vibration
Capacitance
Appearance
Capacitance
Appearance
Measurements shall be stable.
There shall be no evidence of mechanical damage.
Initial value to remain steady during measurement.
There shall be no evidence of mechanical damage.
9
Shock
There shall be no intermittent contact of 0.5 ms or greater, short, or open. Nor shall
there be any spark discharge, insulation breakdown, or evidence of mechanical
damage.
Shall be covered to over 3/4 of terminal surface by new soldering.
10
Solderability
11
Resistance to
Soldering Heat
Leakage Current
Capacitance
Change
Dissipation Factor
Appearance
12
Temperature Cycle
Leakage Current
Shall be within any of the following ranges and specified according to CATALOG
NUMBERS AND RATING.
• Not exceeding the value in No.1: Leakage current code A
• Not exceeding twice the value in No.1: Leakage current code C
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
5% of the value before test
• Within
±
10% of the value before test
• Within
±
20% of the value before test
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
There shall be no evidence of mechanical damage.
Shall be within any of the following ranges and specified according to CATALOG
NUMBERS AND RATING.
• Not exceeding the value in No.1: Leakage current code A
• Not exceeding twice the value in No.1: Leakage current code C
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
5% of the value before test
• Within
±
10% of the value before test
• Within
±
20% of the value before test
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
There shall be no evidence of mechanical damage.
Shall be within any of the following ranges and specified according to CATALOG
NUMBERS AND RATING.
• Not exceeding the value in No.1: Leakage current code A
• Not exceeding twice the value in No.1: Leakage current code C
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
5% of the value before test
• Within
±
10% of the value before test
• Within
±
20% of the value before test
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
There shall be no evidence of mechanical damage.
Shall be within any of the following ranges and specified according to CATALOG
NUMBERS AND RATING.
• Not exceeding 1.25 times the value in No.1: Leakage current code B
• Not exceeding twice the value in No.1: Leakage current code C
Shall be within any of the following ranges and specified according to CATALOG NUMBERS AND RATING.
• Within
±
10% of the value before test
• Within
±
20% of the value before test
• Within
±
30% of the value before test
Shall not exceed the values shown in CATALOG NUMBERS AND RATING.
There shall be no evidence of mechanical damage.
Capacitance
Change
Dissipation Factor
Appearance
13
Moisture Resistance
Leakage Current
JIS C 5102, 9.3
Step 1: -55 0/-3°C, 30
±
3 min
Step 2: 25 +10/-5°C, 3 min or less
Step 3: 125 +3/0°C, 30
±
3 min
Step 4: 25 +10/-5°C, 3 min or less
Number of cycles: 5
JIS C 5102, 9.5
Temperature: 40
±
2°C
Moisture: 90 to 95%RH
Duration: 500 +24/0 hrs
Capacitance
Change
Dissipation Factor
Appearance
14
High Temperature
Load
Leakage Current
Capacitance
Change
Dissipation Factor
Appearance
JIS C 5102, 9.10
Test temperature and applied voltage: 85
±
2°C and rated voltage or
125
±
3°C and 2/3
×
rated voltage
Duration: 2000 + 72/0 hrs
Power supply impedance: 3
Ω
or less
−４−
