SWT
SERIES
Triple Output 30W - 100W
SWT65
SWT100
SWT30
SWT40
warranty
1
Y
E
A
R
S
■ Features
CE marking applicable
● 100V/200V worldwide-applicable input / Multiple
outputs / Super low cost type
● Applicable to consumer products such as bill dis-
criminator machines and games
● Peak load current available (SWT30/40)
■ Model naming method
SWT 30−522
Nominal output voltage
Output power
Series name
■ Applications
■ Conformity to RoHS Directive
This means that, in conformity with EU Directive 2002/95/
EC, lead, cadmium, mercury, hexavalent chromium, and
specific bromine-based flame retardants, PBB and PBDE,
have not been used, except for exempted applications.
SWT
■ Product Line up
30W（50W）
40W（50W）
Output
Voltage Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model
+5V
2A（3A）
2A（3A）
2A（3A）
3A（4.5A）
3A（4.5A）
−5V
−
0.3A（−）
−
−
0.3A（−）
+12V
1.5A（3A）
1.5A（3A）
−
2A（3A）
2A（3A）
SWT30-522
SWT30-525
SWT30-5FF
SWT40-522
SWT40-525
−12V
0.3A（−）
−
−
0.3A（−）
−
+15V
−
−
1A（2.2A）
−
−
−15V
−
−
0.3A（−）
−
−
Output Current
（Peak）
/Model
3A（4.5A）
−
−
SWT40-5FF
−
1.5A（2.4A）
0.3A（−）
65W（−）
100W（−）
Output
Voltage Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model Output Current
（Peak）
/Model
+5V
6A（−）
6A（−）
6A（−）
8A（−）
8A（−）
8A（−）
−5V
−
0.5A（−）
−
−
0.8A（−）
−
+12V
2.5A（−）
2.5A（−）
−
4A（−）
4A（−）
−
SWT100-522
SWT100-525
SWT100-5FF
SWT65-522
SWT65-525
SWT65-5FF
−12V
0.5A（−）
−
−
0.8A（−）
−
−
+15V
−
−
1.8A（−）
−
−
3.2A（−）
−15V
−
−
0.5A（−）
−
−
0.8A（−）
・All specifications are subject to change without notice.
A-273
SWT
30
SWT30 Specifications
MODEL
ITEMS/UNITS
SWT30-522
SWT30-525
SWT30-5FF
CH
(*2)
V
(*2) Hz
(*1)
％
A
A
VDC
A
A
A
W
1
2
3
1
2
47 - 63
70
0.90 / 0.45
3
1
2
3
Voltage Range
Frequency
Input Efficiency (typ)
AC85 - 265 (Continuously) / DC110 - 340
Current (100/200VAC)(typ) (*1)
Inrush Current (100/200VAC)(typ)
Nominal Voltage
Minimum Current
Maximum Current
Maximum Peak Current (*10)
Maximum Peak Power
Output
Maximum Line Regulation (*3)(*4)
Maximum Load Regulation (*3)(*5)
Temperature Coefficient (*3)(*6)
15 / 30 (cold start, Ta=25℃)
+5
0.2
2
3
31.6 (49.6)
+12
0.4
1.5
-12
0
0.3
ー
+5
0.2
2
3
+12
0.4
1.5
-5
0
0.3
ー
+5
0.2
2
3
+15
0.4
1
2.2
-15
0
0.3
ー
29.5 (47.5)
CH1:1% , CH2: 2% , CH3: 1%
CH1:2%, CH2: 4%, CH3: 2%
0.04%/℃
±5V:
120;
±12V:
150;
±15V:
150
17
CH1 +5V fixed, CH2.3 fixed
Maximum Ripple & Noise (*3) mVp-p
Hold-up Time (100VAC)(typ) (*1) ms
Voltage Adjustable Range
Over Current Protection (*7)
Function Over Voltage Protection (*8) VDC
Output Terminals
Operating Temperature
Storage Temperature
Operating Humidity
Environment Storage Humidity
Vibration
Shock
Cooling
Isolation
Standards
Mechanical
Withstand Voltage
Isolation Resistance
Safety Standards
EMI
Weight
Size (W x H x D)
g
mm
(*9)
℃
℃
％RH
％RH
Shipment condition: CH1:
±1%,
CH2(+12V):
±3%,
CH2(+15V):±5%, CH3:
±5%
Automatic recovery, O.C.P point : >170%
>6V (CH1 only)
All channels common ground (2 terminals)
Convection cooling 0 to 50: 100% load; 60: 70% load
-20 to +85
30 - 90 (No dewdrop)
10 - 95 (No dewdrop)
10 - 55Hz amplitude (sweep 1min) Less than 19.6m/s² X , Y ,Z 1Hr each
Less than 196.1m/s²
Convection cooling
I/P-O/P: 3kVAC(20mA), I/P-FG: 2.5kVAC(20mA), O/P-FG: 500VAC(100mA) for 1min
More than 100MΩ at Ta=25℃ and 70%RH, Output - FG 500VDC
Approved by UL60950-1, CSA C22.2 No.60950-1, EN60950-1. Built to meet DENAN.
Built to meet EN55011 / EN55022-B, VCCI-B, FCC-B.
230
76.2 x 127.0 x 30.5
SWT
(*1) At 100VAC, 200VAC and MAX. OUTPUT POWER (Convection cooling), Ta=25℃.
(*2) For cases where conformance to various safety specs (UL, CSA, EN) are required to be
described as 100~120VAC, 200~240VAC, 50/60Hz on name plate.
(*3) Please refer to Fig A for measurement determination of line & load regulation and output
ripple voltage. (Measure with JEITA RC-9131 probe)
(*4) From 85~132VAC / 170~265VAC, constant load.
(*5) From Min. load - Full load (Maximum power), constant input voltage.
(*6) From 0℃~+50℃, constant input voltage and load.
(*7) Current limiting with automatic recovery. Avoid to operate over load or dead short for more
than 30 seconds.
(*8) Over voltage clamping by zener diode.
(*9) At standard mounting method, Fig B.
●Recommended EMC Filter
RSEL-2002W
Please refer to "TDK-Lambda
EMC Filters" catalog.
(*10) Peak current operation is less than 10 sec. with duty factor less than 30%. In addition, it does not have to satisfy the total
regulation specification.
A-274
・All specifications are subject to change without notice.
SWT
30
Outline Drawing
【SWT30】
LEAD CUT LESS THAN 3.0
3.0MAX
5.7
SEE NOTE A
127±1
115.6±0.5
FG(2)
COMPONENT SIDE
64.8±0.5
76.2±1
CN1
1
FG(1)
CN2
1
+V
+5V
GND
−V
4
6
L
H
INPUT
VR1
SAFETY SEAL
17.8
OUTPUT
2
3
4
5
26.5
23.5
6
5.7
30.5±0.5
NAME PLATE
SEE NOTE D
(SEE NOTES B&C)
40.8
(unit : mm)
PCB MATERIAL
GLASS COMPOSITE : CEM-3
NOTES
A : THE 4-φ3.5 HOLES ARE CUSTOMER'S CHASSIS MOUNTING
HOLES. ALL MUST BE SCREWED IN ORDER TO CONFORM THE
VIBRATION SPEC.
B : MODEL NAME, NORMAL OUTPUT VOLTAGE AND AVERAGE
OUTPUT CURRENT ARE SHOWN HERE IN ACCORANCE WITH
THE SPECIFICATIONS.
C : COUNTRY OF MANUFACTURE WILL BE SHOWN HERE.
D : TO KEEP THE DISTANCE MORE THAN 4M/M BETWEEN PC-
BOARD EDGE AND CUSTOMER'S CHASSIS.
E : FG(1) OR FG(2) IS FOR SAFETY GROUND CONNECTION.
CONNECTORS USED:
PART DESCRIPTION
PIN HEADER (INPUT SIDE CN1)
PIN HEADER (OUTPUT SIDE CN2)
CATALOG NO. MANUFACTURER
5414-30B
5273-06A
MOLEX
MOLEX
QTY
1
1
RECOMMENDED HOUSING & TERMINAL PIN.
＊ NOT INCLUDED WITH THE PRODUCT
SOCKET HOUSING (CN1)
SOCKET HOUSING (CN2)
TERMINAL PINS (CN1, 2)
5195-06
5195-06
5194PBT
MOLEX
MOLEX
MOLEX
1
1
9
HAND CRIMPING TOOL: 11-26-0058
MANUFACTURER: MOLEX
Output Derating
OUTPUT DERATING CURVE
100
90
80
Load ％）
（
70
60
50
40
20
B, D, E
A, C
Output connecter
Output connecter
Input connecter
Output connecter
Input connecter
Output connecter
Component side
SWT
(A)
(B)
(C)
(D)
(E)
(F) DON'T USE
Recommended standard mounting method is (A). (B), (C), (D) and (E) are also pos-
sible. Please do not use (F), where the PCB will be on the top side and heat will
be trapped inside the unit.
0
10
20
30
40
50
60
70
Ta ℃）
（
・All specifications are subject to change without notice.
A-275
SWT
40
SWT40
ITEMS/UNITS
Voltage Range
Frequency
Input Efficiency (typ)
SWT40 Specifications
MODEL
SWT40-522
SWT40-525
SWT40-5FF
CH
(*2) V
(*2) Hz
(*1)
％
A
A
VDC
A
A
A
W
1
2
3
1
2
47 - 63
70
1.11 / 0.55
3
1
2
3
AC85 - 265 (continuously) / DC110 - 340
Current (100/200VAC)(typ) (*1)
Inrush Current (100/200VAC)(typ)
Nominal Voltage
Minimum Current
Maximum Current
Maximum Peak Current (*10)
Maximum Peak Power
Output
Maximum Line Regulation (*3)(*4)
Maximum Load Regulation (*3)(*5)
Temperature Coefficient (*3)(*6)
15 / 30 (cold start, Ta=25℃)
+5
0.2
3
4.5
+12
0.3
2
3
42.6 (54.6)
-12
0
0.3
ー
+5
0.2
3
4.5
+12
0.3
2
3
40.5 (51.6)
CH1: 1% , CH2: 2% , CH3: 1%
CH1: 2%, CH2: 4% , CH3: 2%
0.04%/℃
±5V:
120;
±12V:
150;
±15V:
150
17
CH1 +5V fixed, CH2.3 fixed
Shipment condition: CH1:
±1%,
CH2(+12V):
±3%,
CH2(+15V):
±5%,
CH3:
±5%
Automatic recovery, O.C.P point: >140%
>6 (CH1 only)
All channels common ground (2 terminals)
Convection cooling 0 to 50: 100% load; 60: 70% load
-20 to +85
30 - 90 (No dewdrop)
10 - 95 (No dewdrop)
10 - 55Hz amplitude (sweep 1min) Less than 19.6m/s² X ,Y ,Z 1Hr each
Less than 196.1m/s²
Convection cooling
I/P-O/P: 3kVAC(20mA), I/P-FG: 2.5kVAC(20mA), O/P-FG: 500VAC (100mA) for 1min
More than 100MΩ at Ta=25℃ and 70%RH, Output - FG 500VDC
Approved by UL60950-1, CSA C22.2 No 60950-1, EN60950-1. Built to meet DENAN.
Built to meet EN55011 / EN55022-B, VCCI-B, FCC-B
-5
0
0.3
ー
+5
0.2
3
4.5
+15
0.3
1.5
2.4
42 (51.6)
-15
0
0.3
ー
Maximum Ripple & Noise (*3) mVp-p
Hold-up Time (100VAC)(typ)(*1) ms
Voltage Adjustable Range
Over Current Protection (*7)
Function Over Voltage Protection (*8) VDC
Output Terminals
Operating Temperature
Storage Temperature
Operating Humidity
Environment Storage Humidity
Vibration
Shock
Cooling
Isolation
Standards
Mechanical
Withstand Voltage
Isolation Resistance
Safety Standards
EMI
Weight
Size (W x H x D)
g
mm
(*9)
℃
℃
％RH
％RH
280
76.2 x 127.0 x 35.6
SWT
(*1) At 100VAC, 200VAC and MAX. OUTPUT POWER (Convection cooling), Ta=25℃.
(*2) For cases where conformance to various safety specs (UL,CSA, EN) are required to be
described as 100~120VAC, 200~240VAC, 50/60 Hz on name plate.
(*3) Please refer to Fig A for measurement determination of line & load regulation and output
ripple voltage. (Measure with JEITA RC-9131 probe.)
(*4) From 85~132VAC / 170~265VAC, constant load.
(*5) From Min. load - Full load (Maximum power), constant input voltage.
(*6) From 0℃ ~ +50℃, constant input voltage and load.
(*7) Current limiting with automatic recovery. Avoid to operate over load or dead short for more than 30 seconds.
(*8) Over voltage clamping by zener diode.
(*9) At standard mounting method, Fig B.
(*10) Peak current operation is less than 10 sec. with duty factor less than 30%. In addition, it does not has to satisfy
the total regulation specification.
●Recommended EMC Filter
RSEL-2002W
Please refer to "TDK-Lambda
EMC Filters" catalog.
A-276
・All specifications are subject to change without notice.
SWT
40
Outline Drawing
【SWT40】
127±1
LEAD CUT LESS THAN 3.0
3.0MAX
5.7
SEE NOTE A
115.6±0.5
FG ( 2 )
CN2
1o
+V
+5V
GND
-V
COMPO NENT SIDE
64.8±0.5
76.2±1
CN1
1o
FG(2)
OUTPUT
2o
3o
4
o
5o
6o
26.1
6oN
5.7
21.3
SAFETY SEAL
40.9
4
o L
INPUT
VR1
35.6±1
NAME PLATE
(SEE NOTES B&C)
SEE NOTE D
11.8
PCB MATERIAL
GLASS COMPOSITE : CEM-3
NOTES
A : THE 4-φ3.5 HOLES ARE CUSTOMER'S CHASSIS MOUNTING
HOLES. ALL MUST BE SCREWED IN ORDER TO CONFORM THE
VIBRATION SPEC.
B : MODEL NAME, NORMAL OUTPUT VOLTAGE AND AVERAGE
OUTPUT CURRENT ARE SHOWN HERE IN ACCORANCE WITH
THE SPECIFICATIONS.
C : COUNTRY OF MANUFACTURE WILL BE SHOWN HERE.
D : TO KEEP THE DISTANCE MORE THAN 4M/M BETWEEN PC-
BOARD EDGE AND CUSTOMER'S CHASSIS.
E : FG(1) OR FG(2) IS FOR SAFETY GROUND CONNECTION.
(unit : mm)
CONNECTORS USED:
PART DESCRIPTION
PIN HEADER (INPUT SIDE CN1)
PIN HEADER (OUTPUT SIDE CN2)
CATALOG NO. MANUFACTURER
5414-30B
5273-06A
MOLEX
MOLEX
QTY
1
1
RECOMMENDED HOUSING & TERMINAL PIN.
＊ NOT INCLUDED WITH THE PRODUCT
SOCKET HOUSING (CN1)
SOCKET HOUSING (CN2)
TERMINAL PINS (CN1, 2)
5195-06
5195-06
5194PBT
MOLEX
MOLEX
MOLEX
1
1
9
HAND CRIMPING TOOL: 11-26-0058
MANUFACTURER: MOLEX
Output Derating
OUTPUT DERATING CURVE
100
90
80
Load ％）
（
70
60
50
40
20
B, C, D, E
Component side
Output connecter
Input connecter
Output connecter
A
Output connecter
Output connecter
Input connecter
SWT
(B)
(C)
(D)
(E)
(F) DON'T USE
(A)
Recommended standard mounting method is (A). (B), (C), (D) and (E) are also pos-
sible. Please do not use (F), where the PCB will be on the top side and heat will
be trapped inside the unit.
0
10
20
30
40
50
60
70
Ta ℃）
（
・All specifications are subject to change without notice.
A-277
京公网安备 11010802033920号
EEWORLD
