ELP
SERIES
l
l
l
l
Directly mountable on printed circuit board without holders.
Smaller low profile sizes than ordinary capacitors.
Terminal spacing fixed at 10mm for PC board plug in.
Aluminum case designed explosion-proof vent.
Characteristics
16 ~ 100V
160 ~ 450V
680 ~ 47000uF
47 ~ 2200uF
-40 ~ +85
℃
-25 ~ +85
℃
±20%
at 120Hz , 20
℃
( 10% Tol. is available upon request)
I=3
CV
uA max C: Capacitance, V:W.V. (After 5 minutes)
Less than the value under table (%)
10
½
16
25
½
35
50
½
63
80
½
100
160
½
250 350
½
450
uF \\ W.V.
( at 20
℃
, 120Hz)
47
½
390
-
-
-
-
15
20
470
½3900
25
20
20
20
15
20
4700½8200
35
30
30
25
10000½22000
40
35
30
27000½47000
45
40
35
Stability at Low Temperature
Impedance ratio at 120Hz between the -25
℃
or -40
℃
value and 20
℃
value shall not exceed :
Z-25
℃
/Z 20
℃
3
Z-40
℃
/Z 20
℃
12
The following specifications shall satisfied when the capacitors are restored to 20
℃
after rated
Load Life
working voltage applied for 2,000 hours at max. operating temperature with the rated ripple current
applied.
Capacitance change
≦±20%
of the initial value.
Dissipation factor
≦±200%
of the initial specified value
Leakage current
≦
The initial specified value.
After storage for 1000 hours at 85
℃
with no voltage applied, the capacitor shall meet the specified
Shelf Life
limit in load life.
Voltage Range
Capacitance Range
Temperature Range
Capacitance Tolerance
Leakage Current
Dissipation Factor(tanδ)
Diagram of dimensions
Multiplier for R.C. vs Temparature
Temp.(℃)
Multiplier
(mm)
70
1.2
85
1.00
Dia
45
1.55
60
1.3
α
22
2
25
2
30
3
35
3
Multiplier for Ripple Current VS Frequency
Cap.(uF)\\ (Hz)
10<Cap.≦100
100<Cap.≦1000
1000<Cap.
60
0.8
0.8
0.8
120
1
1
1
1K
1.36
1.25
1.17
10K
1.48
1.35
1.25
50K - 100K
1.53
1.38
1.28
