8STA Series
High Density
Souriau Offer New Layout in High Density
SOURIAU brings to market a lightweight, robust and reliable 8STA High
Density solution from the smallest to the largest size with #26 contact.
A reliable & robust solution
Well proven design as standard 8STA: derived
from MIL-DTL-38999 & JN1003.
Provides flexibility according to your application.
From shell size 02 to 1
4.
Space and weight saving for box design.
Designed for 24 to 30 AWG wire, smaller
diameter tubing and boots.
High Density layout 1
4-68 example:
Twice the number of contacts - a size smaller
shell can be used for the same application.
NEW
7 shell sizes available
LAYOUT
14
-
68
PCB pin & socket contacts
Lightweight & flexible
Significant space saving
1
4-35
1
4-68
1
8-35
37 contacts
#22D
68
contacts
#26
66 contacts
#22D
8STA Series
High Density
Description
• Derived from MIL-DTL-38999 & JN1003
standard
• Rugged aluminium body to ensure long
service life in the harshest environment
• 100% scoop proof
• Available in 7 layouts: 02-05; 04-06;
06-09; 08-1 10-26; 1
2;
2-43; 1
4-68
NEW
• Contacts #26 for AWG 24 to 30
• 6 colours coded keyways orientations
• Boot termination feature
Technical features
Mechanical
•
Shell:
Aluminium
•
Shell palting:
Conductive black zinc
•
Insulator:
Liquid silicone rubber
•
Seal:
Liquid Silicone rubber
•
Contact:
Copper alloy
• Contact plating:
Gold
• Endurance:
500 mating cycles
• Shock:
300g for 3 ms and EIA-364-27
• Vibration:
1 m/s2, 10 to 2000 Hz
47
Environmental
•
Temperature range:
-55°c to +1
75°c
•
Sealing mated connectors:
IP 67 (1 metre for 30 min minimum)
•
Salt spray:
48 hours
Electrical
• Contact resistance:
Size 26: 16mΩ
• Insultation resitance:
≥5000MΩ
(at 400Vdc)
• Contact rating:
Size 26: 3 Amp
• Shell continuity:
≤10mΩ
Contact layouts
02-05
04-06
06-09
08-1
2
1
0-26
1
2-43
1
4-68
2
8STA Series
High Density
Ordering information
Basic series
Shell type:
0:
Oval flange receptacle
1:
In line receptacle
2:
Oval Flange receptacle with PCB contacts
6:
Plug
7:
Jam nut receptacle
Shell size:
02; 04; 06; 08; 1 1 1
0; 2; 4
Contact layout:
See previous page
Type of contact:
P:
Pin
S:
Socket
Orientation:
N:
Red;
A:
Yellow;
B:
Blue;
C:
Orange;
D:
Green;
E:
Grey (shell size 02 only);
U:
Universal
Specification:
None :
Standard crimp version
499:
Integrated clinch nut on the flange:
. M2 insert - for shell sizes 02, 04 & 06 (shell type 0 & 2 only)
. M3 insert - for shell sizes 08, 10, 1 & 1 (shell type 0 & 2 only)
2
4
523:
Light weight in line receptacle - for shell sizes 08, 10, 1 & 1 (shell type 1 only)
2
4
528:
Integrated clinch nut on the flange:
. M2.5 insert - for shell sizes 02, 04 & 06 (shell type 0 & 2 only)
For PC tail version, please consult us.
8STA
6
1
2
43
P
N
Dimensions
Shell sizes 02, 04 & 06
Plug
A
In-line receptacle
A
C
B
Shell size
02
04
06
A
1
7.50
18.3
±0.2
21.95/22.2
ØB
7.2
8.5
±0.1
10.1/10.35
ØC
10.4
1
±0.1
3.4
1
5.05
±0.2
Shell size
02
04
06
A
1
7.50
18.1
±0.2
22.95/23.2
ØB
7.2
8.5
±0.1
10.1/10.35
C
ØC
8.3
10
±0.2
1
1.5/1
1.65
Note: All dimensions are in millimeters (mm)
3
B
8STA Series
High Density
Dimensions
Shell sizes 02, 04 & 06
Oval flange receptacle
A
with PCB
contacts
F
G
Panel cut out
E
D
B
C
J
K
H
M
Shell
size
02
04
06
Shell
size
02
04
06
A
1
7.5
1
7.9/18.3
22.9/23.2
J
#22D
1.1
7/1.24
1.19/1.24
1.19/1.24
ØB
7.2
8.4/8.6
10.1/10.3
ØC
8.3
9.8/10.2
1
1.5/1
1.6
K
D
1
5.3
16/16.4
1
7.8/18.2
E
-
1
2.8/1
3.2
1
4.7/1
4.9
F
10
10.4/10.7
1
2.6/1
2.9
G
-
8.8/9.2
10.7/10.8
H
2.45/2.55
2.5
3.9/4.1
#26
0.95/1.1
5
1.1/1.1
5
1.1/1.1
5
#22D
0.64/0.69
0.64/0.69
0.64/0.69
#26
0.49/0.54
0.49/0.54
0.49/0.54
L
1
±0.2
5.3
16.2
±0.2
18
±0.2
ØM
9.3
±0.1
1
±0.1
2
1
±0.1
3
ØN
3.1
±0.2
3.1
±0.2
3.1
±0.2
Jam nut receptacle (shell size 04)
16 - 16.2
O’ring
7.5 - 7.7
Ø8.4 - 8.6
Panel cut out
18
9.8 - 10.2
20.2 max
1
1.70
2.9 - 3.1
Ø1
±0 1
2.5
Ø22.5 max
Note: for other shell sizes please consult us.
Panel thickness: 1.5 to 5.0
Note: All dimensions are in millimeters (mm)
4
L
N
8STA Series
High Density
Dimensions
Shell sizes 08, 1 1 & 1
0, 2
4
Plug
33.5 max.
B
Shell size
08
øA
ØA max.
18.70
21.50
25.10
29.00
B max.
1
0
1
2
1
4
18.55
Color band
In-line receptacle
Standard version
G
Lightweight version (specification 523)
G
Shell size
øD
øA
øD
8
1
7.6
1
2
1
0
20.7
1
5
1
2
25.1
1
4
28.3
ØA max.
ØD
+0.20
-0.1
3
G max.
19.05 22.22
33.5
Hand grip
Jam nut receptacle
G
E
F
ø
A
Panel cut out
ø
øD
B1
A
P Panel thickness
B2
Shell size
08
1
0
1
2
1
4
ØA
±0.3
26.90
30.1
5
34.89
38.06
B1
-B2
±0.24
24.10
27.30
32.10
34.92
0
ØD
-0.12
E
±0.10
F
±0.24
G
±0.3
P max.
Panel cut out
ØA
B
±0.20
±0.1
0
1
1.97
1
4.94
19.01
22.18
25.91
23.24
36.71
3.00
1
4.50
1
7.70
22.70
25.70
1
3.60
16.80
20.90
24.10
Note: All dimensions are in millimeters (mm)
5
B
