Note: 0 setting is for instantaneous output operation.
10
CHARACTERISTICS
Item
Rated operating voltage
Rated frequency
Rated power consumption
Output rating
Rating
Operating mode
Pulse ON-delay
Pulse Flicker
Pulse ON-Flicker
Signal OFF-delay
Pulse One-shot
Pulse One-cycle
Type
PM5S-A
PM5S-S
24 to 240V AC/DC
50/60Hz common
2.6 VA (AC), 1.4 W (DC)
5A 250V AC (resistive load)
PM5S-M
Power ON-delay
Pulse ON-delay
Pulse Flicker
Pulse ON-flicker
Signal OFF-delay
Pulse One-shot
Pulse One-cycle
(with instantaneous contact)
Time range
Operating time fluctuation
Time
Setting error
accuracy
Note:) Voltage error
Temperature error
Contact arrangement
Contact
Contact resistance (Initial value)
Contact material
Mechanical (contact)
Electrical (contact)
Allowable operating voltage range
Insulation resistance (Initial value)
Electrical
function
Breakdown voltage (Initial value)
Min. power off time
Max. temperature rise
Shock resistance
Mechanical
function
Vibration resistance
Functional
Destructive
Functional
Destructive
Life
Operating
condition
Others
Ambient temperature
Ambient humidity
Atmospheric pressure
Ripple factor (DC)
Protective construction
Weight
1s to 500h (Max.) 16 time ranges switchable
±0.3%
(power off time change at the range of 0.1s to 1h)
±10%
(Max. setting time value)
±0.5%
(at the operating voltage changes between 85 to 110%)
±2%
(at 20 C ambient temp. at the range of –10 to +55 C +14 to +131 F)
Timed-out 1 Form C
Timed-out 2 Form C
Instantaneous 1 Form C
Max. 100mΩ (at 1A 6V DC)
Silver alloy
Au flash on Silver alloy
1 10
7
2 10
7
10
5
(at rated control capacity)
85 to 110% of rated operating voltage (at 20 C coil temp.)
Between live and dead metal parts
Between input and output
Min. 100MΩ
(At 500V DC)
Between contacts of different poles
Between contacts of same pole
2,000Vrms for 1 min Between live and dead metal parts
2,000Vrms for 1 min Between input and output
2,000Vrms for 1 min Between contacts of different poles
1,000Vrms for 1 min Between contacts of same pole
100ms
55 C 131 F
65 C 149 F
Min. 98m/s
2
(4 times on 3 axes)
Min. 980m/s
2
(5 times on 3 axes)
10 to 55Hz: 1 cycle/min Single amplitude of 0.35mm (10min on 3 axes)
10 to 55Hz: 1 cycle/min Single amplitude of 0.75mm (1h on 3 axes)
–10 to +55 C +14 to +131 F
Max. 85%RH
860 to 1,060hPa
20%
IP40
120g 4.233 oz
Note: 1) Unless otherwise specified, the measurement conditions at the maximum scale time standard are specified to be the rated operating voltage (within 5% ripple
factor for DC), 20°C 68°F ambient temperature, and 1s power off time.
2) For the 1s range, the tolerance for each specification becomes
±10ms.
WIRING DIAGRAMS
PM5S-A
• Timed-out 2 Form C
PM5S-S
• Timed-out 2 Form C
+
Operating
Voltage
_
A1
Signal
Input
B1
15
25
A2
16
18 26
28
PM5S-M
• Timed-out 1 Form C
• Instantaneous 1 Form C
Contact
Timed-out contact
Instantaneous contact
11
MODE SELECTION
PM5S-A/M type
A1
15
25
PWR
OUT
4
2
0
ON
6
8
10
Operation mode selector & indicator
Selects from 6 operation modes
ON: ON-delay
FL: Flicker
FO: ON-flicker
SF: Signal OFF-delay
OS: Pulse One-shot
OC: Pulse One-cycle
The 6 operating modes (PM5S-A and PM5S-M)
can be selected by the operation mode selector
switch.
S
L
SeC
PM5S-A
28
26
B1
18
16
A2
DIMENSIONS
PM5S-
75.0
2.953
mm inch
10
ON
6
SeC
B1
25
A2
8
PWR
PM5S-A
OUT
4
22.5
.886
15
A1
2
L
26
9.0
.354
75.0
2.953
48.0
1.890
S
9.0
.354
28
18
0
16
5.0
.197
14.2
.559
A
TD1217
PM5S MUL
TIRANGE TIMER
PM5S-A-24-240V
41.3
1.626
98.5
3.878
3.5
.138
20
.787
37.5
1.476
12
OPERATION MODE
PM5S-A/M
Operation mode
(
Operation
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
LED lighting LED flickering
T: Setting time t
1
, t
2
<T
)
Time chart
ON-delay
T
urn the operation selector to
ON
.
Timing operation starts when terminals A1 – B1 are con-
nected while power is on. Control output is turned ON after
the set time regardless of the duration of the set signal. Ad-
ditional signal inputs are ignored. The timer resets when
power is removed.
ON
ON
T
T
Flicker
Turn the operation selector to
FL
.
Timing operation starts when terminals A1 – B1 are con-
nected while power is on. Control output remains OFF for
the first set time period then repeatedly turns ON and OFF
for the set time. Additional signal inputs are ignored. The
timer resets when power is removed.
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
FL
T
ON
T
t
1
T
t
2
ON-flicker
FO
Turn the operation selector to
FO
.
Control output turns ON and the timing operation starts
when terminals A1 – B1 are connected while power is on.
Control output repeatedly turns OFF and ON for the set
time. Additional signal inputs are ignored. The timer resets
when power is removed.
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
ON
T
T
t
1
T
T
Signal
OFF-delay
SF
Turn the operation selector to
SF
.
The Control output turns ON when terminals A1-B1 are con-
nected while power is ON. Timing operation starts when ter-
minals A1 – B1 are opened while power is on. Control output
is turned off after the set time.
If the signal input turns ON during timing operation, the tim-
ing operation stops and resets. When the signal input turns
OFF again, timing will begin.
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
ON
T
t
1
t
2
Turn the operation selector to
OS
.
Timing operation starts when terminals A1 – B1 are con-
nected while power is ON.
Control output remains ON during the timing operation.
One-shot
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
OS
ON
T
T
T
t
1
Note: Allow 0.1s or more for power off time.
Allow 0.05s or more for signal input time.
13
Operation mode
Operation
T
urn the operation selector to
OC
.
Timing operation starts when terminals A1-B1 are connected
while power is ON. The Control output is turned ON after the
set time for a fixed duration between 0.5 and 1.0 seconds.
Additional inputs are ignored during timing.
Time chart
Power supply
Signal A1-B1
Relay output
(NO contact)
OUT. LED
POWER LED
ON
ON
0.5-1.0S
One-cycle
OC
T
T
t
1
Note: Allow 0.1s or more for power off time.
Allow 0.05s or more for signal input time.
OPERATION MODE
PM5S-S
Operation mode
(
Operation
Power supply
Time-out relay output
(NO contact)
OUT. LED
POWER LED
LED lighting
T: Setting time
LED flickering
)
Time chart
ON
ON
T
When power is applied continuously, the time cycle begins.
The Control output is turned ON after the set time. The
