Halogen
Free
PRODUCTS
Typical Applications:
Video Decoding
VoIP
Clock Oscillator (Through Hole)
Wireless Base Station
Set-top Box
D14
(Through Hole Oscillator Series)
Part Number: D14 (Waveform) (ppm) - Freq - Vcc
Example: D14T25-20.000-3.3V
■
Specification
Part No.
D14 (waveform) (ppm) - Freq - Vcc
Specification
Output Waveform
Frequency Range
Temperature Stability
Operating Temperature Range
Storage Temperature Range
Aging
Supply Voltage (Vcc)
Example
D14T25-20.000-3.3V
D14
TTL / HCMOS Compatible
0.5 to 150.0MHz
± to ±
25
100ppm
0° to +70° / -40° to +85°
C
C
C
C
-55° to +125°
C
C
±
5ppm/year Max.
+5.0VDC ±
10%
15mA Max (0.5 to 24.0 MHz)
30mA Max (24.0 to 50.0 MHz)
40mA Max (50.0 to 70.0 MHz)
60mA Max (70.0 to 150.0 MHz)
40/60% or 45/55%
TTL Load
HCMOS Load
VOL
VOH
Enable
Disable
1~10 TTL
1~5 TTL
~50.0M :50pF / ~70.0M :30pF / ~150.0M:15pF
~50.0M :30pF / ~150.0M :15pF
10/10nS Max
8/8nS Max
10% Vcc Max
90% Vcc Min
Pin 1 = Hi or Open , Pin 5 active
Pin 1 = Lo , Pin 5 High Z
+3.3VDC ±
10%
15mA Max (0.5 to 24.0 MHz)
20mA Max (24.0 to 50.0 MHz)
30mA Max (50.0 to 70.0 MHz)
45mA Max (70.0 to 150.0 MHz)
OSCILLATOR
D14
Supply Current
Symmetry
Output Load
Rise and Fall Time
Output Voltage
Tristate Option
■
Dimension
(Unit:mm)
