208-MHz, 32-bit
microcontroller with
ARM9EJ-S
™
core
LPC3180
Low-power, ARM9-based
microcontroller
A USB OTG interface with full host capability lets this high-performance microcontroller connect
directly to peripherals. Other options – including seven UARTs, two SPI, two I
2
C, a real-time clock
with separate power domain, and controllers for NAND Flash and SDRAM memory – increase
design flexibility.
Key features
4
08-MHz, 32-bit ARM9EJ-S with AHB/APB interfaces
2
4
0-nm technology for operation down to 0.9 V in low-
9
power mode
4
ector floating-point coprocessor
V
4
xternal memory interface for Flash, SDR, and DDR
E
SDRAM
4
5 KB of SRAM, 32 K of instruction and data cache
6
4
SB OTG with full-speed host capability
U
4
eneral-purpose DMA controller and memory
G
management unit
4
0-bit A/D converter
1
4
ultiple serial interfaces: two I
2
C, two SPI, seven UART
M
4
wo 32-bit timers and real-time clock with separate clock
T
and power domain
4
TAG interface with emulation-trace buffer
J
4
.2-V core voltage, 3-V and 1.8-V I/O
1
4
ecure Digital (SD) memory-card interface
S
4
ackage: LFBGA320 (13 x 13 x 0.9 mm)
P
Applications
4
ndustrial
I
4
edical
M
4
eripheral control: printers, scanners, POS
P
4
edical devices
M
4
PS, motors, security devices, servo loops
G
4
etwork control
N
The NXP microcontroller LPC3180, a 32-bit microcontroller
built around a 90-nm ARM9 core, is the industry’s first to pro-
vide a vector floating-point co-processor, integrated USB On-
The-Go (OTG), and the ability to operate in ultra-low-power
mode (down to 0.9 V).
The ARM9 core operates at up to 208 MHz and is supported
by 32 K of data cache and 32 K of instruction cache. There is
an external-memory interface for NAND Flash and SDRAM
memory (at 1.8 V for mobile SDRAM), and a 64-KB block of
on-chip SRAM.
The on-chip memory management unit (MMU) supports major
operating systems, including Linux, the leading OS for embed-
ded applications. Also, the on-chip Java byte-code coproces-
sor supports basic security and authentication applications.
The vector floating-point coprocessor increases the speed of
typical calculations by a factor of four to five in scalar mode,
and much more in optimized vector mode.
Flexible power management enables high peak performance,
especially for floating-point calculations, and can be used to
shut down the core power domain while retaining real-time-
clock and wake-up functionality.
Multiple serial communications interfaces increase design flex-
ibility, provide larger buffer size, and deliver higher processing
power. The USB 2.0 device supports On-The-Go (OTG) and
has full speed host capabilities. There are seven 16C550 UARTs
(one supports IrDA), two Fast I
2
C-bus (400 Mbps) interfaces,
two SPI interfaces, and an automatic keyscan function that sup-
ports 8 x 8 keys.
There is a 10-bit A/D converter with three channels, two 32-bit
timers with four capture/compare channels, two PWM chan-
nels, a PLL, a real-time clock with separate clock and power
domain, a Watchdog timer, and a Secure Digital (SD) memory-
card interface. The core voltage supports 1.2 V, while the I/O
ports support 1.8 and 3.0 V. The operating temperature range
is -40 to 85 °C.
For debugging, the LPC3180 supports real-time emulation,
has an on-chip embedded-trace buffer with a 2K x 24-bit RAM,
and an integrated interrupt controller. Also, for compatibility
with existing tools, it uses the standard ARM test/debug JTAG
interface.
Third-Party Development Tools
Through third-party suppliers, we offer a range of develop-
ment tools for our microcontrollers. For the most current list-
ing, please visit www.nxp.com/microcontrollers.
External Memory I/F
(NAND, SD, and DRAM)
E-ICE/RTM Interface
Embedded Trace Buffer
64-KB SRAM
Interrupt Controller
DMA
Vector Floating–Point Coprocessor
MMU
32-bit ARM926EJ-S
Bus Matrix
32-K D Cache
32-K I Cache
Power Management, Real-time Clock,
Watchdog Timer, PLL
10-bit A/D Converter
(Three Channels)
Two timers with
Capture / Compare
2 x I
2
C
(Master Only)
UART 1-7
(UART6 supports IrDA)
USB 2.0
Full-speed / Host / OTG
2 x PWM
(1 Channel Each)
2 x SPI
(Master Only)
Keyscan
I/O ports (55)
LPC3180 block diagram
LPC3180 selection guide
Type
LPC3180
(1)
External memory
interface
1
SRAM
64 KB
I-cache
32 K
D-cache
32 K
USB 2.0
(12 or 480 Mbps) + OTG
1
I
2
C
2
SPI
2
UARTs
6
(1)
ADC channels
(10-bit)
3
Package
LFBGA320
UART6 supports IrDA
