1.5 Watt
24 Pin DIL Package V
2:1 Input Range - Metal Case
o
o
o
o
o
Wide Input Range
Regulated Single & Dual Output
Short Circuit Protection
1.5 KVDC I/O-Isolation
Option 3.5 KVDC I/O-Isolation
MODEL NUMBER
INPUT VOLTAGE
OUTPUT
VOLTAGE
3.3 VDC
5 VDC
12 VDC
15 VDC
OUTPUT
CURRENT
400 mA
300 mA
125 mA
100 mA
±200 mA
±150 mA
±63 mA
INPUT CURRENT
Eff.%
NO LOAD
FULL LOAD
171 mA
10 mA
171 mA
160 mA
160 mA
12 mA
171 mA
73
73
73
78
78
1.5VRS12W3.3M
1.5VRS12W5M
1.5VRS12W12M
1.5VRS12W15M
9-18 VDC
1.5VRD12W3.3M
1.5VRD12W5M
1.5VRD12W12M
1.5VRD12W15M
1.5VRS24W3.3M
1.5VRS24W5M
1.5VRS24W12M
1.5VRS24W15M
18-36 VDC
1.5VRD24W3.3M
1.5VRD24W5M
1.5VRD24W12M
1.5VRD24W15M
1.5VRS48W3.3M
1.5VRS48W5M
1.5VRS48W12M
1.5VRS48W15M
36-72 VDC
1.5VRD48W3.3M
1.5VRD48W5M
1.5VRD48W12M
1.5VRD48W15M
last up-date 10.02.2004
±3.3 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
±3.3 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
±3.3 VDC
±5 VDC
±12 VDC
±15 VDC
15 mA
±50 mA
400 mA
300 mA
10 mA
125 mA
100 mA
±200 mA
±150 mA
12 mA
±63 mA
160 mA
78
74 mA
83 mA
80 mA
79 mA
74 mA
83 mA
74
75
78
79
74
75
79 mA
±50 mA
400 mA
300 mA
8 mA
125 mA
42 mA
100 mA
±200 mA
±150 mA
±63 mA
±50 mA
10 mA
41 mA
11 mA
42 mA
37 mA
37 mA
43 mA
79
74
73
75
74
74
75
75
1.5 Watt - 24 Pin DIL - Package V - 2:1 Input Range - Metal Case
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
2/3
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
2:1
Pi Network
OUTPUT SPECIFICATIONS
Voltage Accuracy
Voltage Balance (Dual Output)
Temperature Coefficient
Ripple and Noise, 20MHz BW
Short Circuit Protection
Short Circuit Restart
Line Regulation
Load Regulation
±1% max.
±1%
±0.02%/°C max.
60 mV p-p max.
Continuous
Automatic
±0.5% max.
±0.5% max.
GENERAL SPECIFICATION
Efficiency
Isolation Voltage
Suffix "H"
Isolation Resistance
Isolation Capacitance
Leakage Current
Switching Frequency
Operating Temperature Range
Storage Temperature Range
Derating
Humidity
Case Material
Case Material Suffix "P"
MTBF
see table
1.500 VDC min.
3.500 VDC min.
1.000 Mohms min.
80 pF typ.
1 mA
250 kHz typ.
-25°C to +71°C
-55°C to +125°C
None Required
Up to 90%, Non Condensing
Nickel-Coated Copper
Non-Conductive Black Plastic
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
1.5 Watt - 24 Pin DIL - Package V - 2:1 Input Range - Metal Case
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/3
MECHANICAL SPECIFICATIONS
CASE "V"
NICKEL-COATED COPPER
PIN
1 & 24
2 & 23
3 & 22
9 & 16
10 & 15
11 & 14
12 & 13
PIN CONNECTIONS 1.500VDC
SINGLE
+INPUT
NC*
NC*
NO PIN
-OUTPUT
+OUTPUT
-INPUT
DUAL
+INPUT
-OUTPUT
COMMON
NO PIN
COMMON
+OUTPUT
-INPUT
*NC = NOT CONNECTED
NON-CONDUCTIVE BLACK PLASTIC
PIN
1 & 24
2&3
9
10 &15
11
12 & 13
14
16
22 & 23
PIN CONNECTIONS 3.500VDC
SINGLE
NO PIN
-INPUT
NO PIN
NO PIN
NC*
NO PIN
+OUTPUT
-OUTPUT
+INPUT
DUAL
NO PIN
-INPUT
COMMON
NO PIN
-OUTPUT
NO PIN
+OUTPUT
COMMON
+INPUT
*NC = NOT CONNECTED
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
