L61-3033-5100-C

Description
Visible LED
CategoryLED optoelectronic/LED    photoelectric
File Size45KB,1 Pages
ManufacturerMicroprecision Electronics SA
Download Datasheet Parametric View All

L61-3033-5100-C Overview

Visible LED

L61-3033-5100-C Parametric

Parameter NameAttribute value
Objectid8357591238
Reach Compliance Codecompliant
YTEOL2
color@wavelengthYellow
Optoelectronic device typesSINGLE COLOR LED
total height21 mm
peak wavelength583 nm
perspective24 deg
L60/L61 T1 3/4
Rear Mount LED Indicator
Special Features
Rear mounting, friction-fit—no mounting hardware required
Simplified one-piece construction
Optional internal resistor—can be customized for AC applications
Sealed against moisture and dust—water resistant
Available for panel thickness .062˝, .125˝ and .187˝
Custom body lengths available without tooling charges
Specifications
• Mounting hole: .250˝ (6.35)
• Termination: 22 AWG 6˝ gray (anode) and black (cathode) leads
stripped to 1/4˝ standard; Optional bi-pin available
• Body material: Black butyrate plastic
• Custom lead lengths and colors available
5mm Panel Mount LED Assemblies
Package Dimensions
.100
(2.54)
OPTIONAL SPACER
.375Ø
(9.5)
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2
Peak
More
Wavelength LED Data
(mm)
Page#
.254"
DIA.
(6.5)
.200"
DIA.
(5.0)
HIGH EFFICIENCY
3008
3019
3020
3022
Red
Green
Yellow
Orange
7.0
14.0
8.0
7.0
10
10
10
10
1.9
2.1
2.0
1.9
10
10
10
10
60°
60°
60°
60°
635
565
583
600
24
24
24
24
.187
(4.7)
.030
(.76)
.825 (20.95)
.280Ø
(7.1)
6" COLOR CODED
(152.4)
LOW CURRENT
3015
3016
3017
Red
Yellow
Green
2.3
2.1
2.3
2
2
2
1.8
1.9
1.8
2
2
2
50°
50°
50°
635
583
565
25
25
25
All Dimensions are in inches (mm)
Resistor Chart
OPERATING SPECIFICATIONS
Resistor
Value Code
0000
0001
0330
0390
0820
1000
1300
5100
2700
0150
0200
0430
0510
0680
Voltage
2
2
5
6
10
12
15
28
28
5
6
10
12
15
Current
(mA)
10 or 20
2
10
10
10
10
10
5
10
20
20
20
20
20
Internal
Resistor (Ohms)
None
None
330
390
820
1000
1300
5100
2700
150
200
430
510
680
BLUE
3044
3045
Blue
Blue
40.0
90.0
20
20
4.5
4.5
20
20
60°
16°
430
430
30
30
BICOLOR
9001
9002
Red
Green
Yellow
Green
25.0
20.0
10.0
20.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
625
565
590
565
27
27
ULTRA BRIGHT
3032
3033
3034
Red
Yellow
Green
125.0
140.0
140.0
20
20
20
1.9
2.1
2.2
20
20
20
24°
24°
24°
635
583
565
24
24
24
SUPER ULTRA BRIGHT
3036
3046
3047
3048
Red
Red
Green
Amber
2500.0
900.0
1750.0
1300.00
20
20
20
20
1.85
1.9
3.5
2.02
20
20
20
20
30°
30°
30°
30°
660
635
524
592
29
29
29
29
Note: Other resistor values for different current requirements are available on
request.
How To Order
LED Specifications Resistor Value Code
LED Series
Panel Thickness
WHITE
3049
White
800.0
20
3.5
20
30°
475
30
L 6 x — x x x x — x x x x — x
Bipins = 0
Leads = 1
See LED Chart
See Resistor Chart
A. .062" Thick
B. .125" Thick
C. .187" Thick
®
WILBRECHT
ELECTRONICS, INC.
1400 Energy Park Drive, Suite 18 • St. Paul, MN 55108-5248 • (651) 659-0919 • FAX (651) 659-9204 • www.wilbrecht.com
LEDCO
DIVISION
15
