Tension spring |
Spacing 5.0 mm
AK3001/..FD-5.0-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
2.5 mm²
0.14 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
12.90
17.90
22.90
27.90
32.90
37.90
42.90
47.90
52.90
57.90
62.90
67.90
72.90
77.90
82.90
87.90
92.90
97.90
102.90
107.90
112.90
117.90
122.90
Article Designation
AK3001/2FD-5.0-PEBBLE GREY
AK3001/3FD-5.0-PEBBLE GREY
AK3001/4FD-5.0-PEBBLE GREY
AK3001/5FD-5.0-PEBBLE GREY
AK3001/6FD-5.0-PEBBLE GREY
AK3001/7FD-5.0-PEBBLE GREY
AK3001/8FD-5.0-PEBBLE GREY
AK3001/9FD-5.0-PEBBLE GREY
AK3001/10FD-5.0-PEBBLE GREY
AK3001/11FD-5.0-PEBBLE GREY
AK3001/12FD-5.0-PEBBLE GREY
AK3001/13FD-5.0-PEBBLE GREY
AK3001/14FD-5.0-PEBBLE GREY
AK3001/15FD-5.0-PEBBLE GREY
AK3001/16FD-5.0-PEBBLE GREY
AK3001/17FD-5.0-PEBBLE GREY
AK3001/18FD-5.0-PEBBLE GREY
AK3001/19FD-5.0-PEBBLE GREY
AK3001/20FD-5.0-PEBBLE GREY
AK3001/21FD-5.0-PEBBLE GREY
AK3001/22FD-5.0-PEBBLE GREY
AK3001/23FD-5.0-PEBBLE GREY
AK3001/24FD-5.0-PEBBLE GREY
Article Number
53001020021F
53001030021F
53001040021F
53001050021E
53001060021E
53001070021E
53001080021D
53001090021D
53001100021D
53001110021D
53001120021D
53001130021D
53001140021D
53001150021D
53001160021D
53001170021D
53001180021D
53001190021D
53001200021D
53001210021D
53001220021D
53001230021D
53001240021D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Tension Spring
Copper Alloy
Stainless Steel
6.0 mm
1.0 mm
Colours
PEBBLE GREY
GREEN
ORANGE
BLUE
21
RAL7032
RAL6018
RAL2011
RAL5015
RAL7032
22
23
24
RAL6018
RAL2011
RAL5015
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
15 A
AWG 28-14
AWG 28-14
1.6 kV
C
-
-
-
-
-
D
300 V
10 A
AWG 28-14
AWG 28-14
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
24 A
max
2.5 mm²
2.5 mm²
2.0 kV
