Push-In |
Spacing 2.54 mm
AKZ4791/..KD-2.54-H-BASALTGREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
0.75 mm²
0.14 mm²
0.75 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PBT
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
Article Designation
AKZ4791/2KD-2.54-H-BASALTGREY
AKZ4791/3KD-2.54-H-BASALTGREY
AKZ4791/4KD-2.54-H-BASALTGREY
AKZ4791/5KD-2.54-H-BASALTGREY
AKZ4791/6KD-2.54-H-BASALTGREY
AKZ4791/7KD-2.54-H-BASALTGREY
AKZ4791/8KD-2.54-H-BASALTGREY
AKZ4791/9KD-2.54-H-BASALTGREY
AKZ4791/10KD-2.54-H-BASALTGREY
AKZ4791/11KD-2.54-H-BASALTGREY
AKZ4791/12KD-2.54-H-BASALTGREY
Article Number
54791020422F
54791030422F
54791040422F
54791050422E
54791060422E
54791070422E
54791080422D
54791090422D
54791100422D
54791110422D
54791120422D
PU
200
200
200
100
100
100
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 0.14 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Brass
10.0 mm
1.2 mm
Colours
BASALT GREY
GREEN
LIGHT GREEN
RAL7012
RAL6018
similar RAL 6018
RAL7012
RAL6018
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Ratings
*
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
150 V
6A
AWG 26-20
AWG 26-20
1.3 kV
C
-
-
-
-
-
D
150 V
6A
AWG 26-20
AWG 26-20
1.3 kV
min
0.2 mm²
0.2 mm²
1.25 kV
130 V
9A
*
max
0.75 mm²
0.75 mm²
* Approval Pending
