FEATURES AND SPECIFICATIONS
Features and Benefits
s
Cost-effective method for interchanging PROM devices by
nontechnical personnel
s
Prevents damage to PROM device through a fully
shrouded carrier
s
Finger tabs for fast and easy insertion/withdrawal
s
Carrier is keyed and color coded to socket except universal
(purple) carrier that fits any similiar circuit count socket
Sockets available with pegs in multiple locations for
s
polarization to PCB
s
Socket contacts solder to a 1.57mm (.062") thick PC board
s
Double cantilever terminal
Physical
Housing: Glass-filled polyester, UL 94V-0
Contact: Beryllium Copper
Plating: .000200" min. Tin/Lead in contact area,
.000075"min. Tin/Lead in PC tail area over
.000050"min. Nickel overall
78802/78804/78805/
78807
Socket and Carrier
Ordering Information
ORDERING INFORMATION
Carrier and Corresponding Socket
Circuits
24
28 (24)*
28
28
28
28
28
28
28
28
28
28
32
32
32
32
32
32
32
32
Carrier
Order No.
50-39-5248
50-57-5285
50-39-5288
50-57-5286
50-65-2282
50-65-2283
50-65-2284
50-65-2285
50-65-2286
50-65-2287
50-65-2288
50-57-5284
50-57-5283
50-57-5283
50-65-3330
50-65-3332
50-65-3321
50-65-3334
50-65-3335
50-65-3365
Color
Black
Black
Black
Red
Yellow
Gray
Dark Green
Natural
Light Blue
Orange
Dark Blue
Purple
Black
Black
Yellow
Dark Green
Natural
Light Blue
Orange
Red
Keys
1, 5, 9
1, 5, 9
1, 5, 9
1, 5, 9
2, 4
2, 8
0, 2
1, 5
1, 7
1, 3
1, 9
No keys
1, 5, 9
1, 5, 9
2, 4
2, 0
1, 5
1, 7
1, 3
1, 5, 9
Circuits
24
28
28
28
28
28
28
28
28
28
28
28
32
32
32
32
32
32
32
32
Order No.
15-29-9242
15-29-9282
15-41-3281
15-29-2281
15-41-3283
15-41-3284
15-41-3285
15-41-3286
15-41-3287
15-41-3288
15-41-3289
†
15-41-3329
15-41-3329
15-41-3320
15-41-3326
15-41-3321
15-41-3324
15-41-3328
15-41-3336
Socket
Color
Black
Black
Black
Red
Yellow
Gray
Dark Green
Natural
Light Blue
Orange
Dark Blue
Black
Black
Yellow
Dark Green
Natural
Light Blue
Orange
Red
Keys
1, 5, 9
1, 5, 9
1, 5, 9
1, 5, 9
2, 4
2, 8
0, 2
1, 5
1, 7
1, 3
1, 9
1, 5, 9
1, 5, 9
2, 4
2, 0
1, 5
1, 7
1, 3
1, 5, 9
PCB Peg Position
No peg
No peg
6
1
2
3
6
5
4
7
8
No peg
No peg
2
6
5
4
7
1
* 28-circuit system designed for 24-circuit module
†
Any 28-circuit socket
990
E-43
Sockets and Edge Connectors
2.54 x 15.24mm
(.100 x .600") Pitch
Modular IC Socket System
