NETWORkS
COnCaVE TERMInaTIOnS
Cn
THICk FILM R-NETWORk
STRUCTURE
1
2
3
4
5
6
Ceramic substrate
Inner electrode
RuO
2
resistive film
Inner glass passivation
Outer electrode
Protective coating
nETWORKS
(PaSSIVE COMPOnEnTS)
IDEnTIFICaTIOn
TYPE
Cn 1E
Cn 1J, 2a, 2B
COaTIng
COLOR
Black
MaRKIng
None
White, 3 digits
Products with Pb-free terminations
meet EU-RoHS requirements
101
NOMINAL
RESISTANCE
F: 4 digits
G,J: 3 digits
TYPE DESIgnaTIOn (HOW TO ORDER)
Cn
PRODUCT CODE
2a
STYLE
1E, 1J, 2A, 2B
TD, TE, BK
*Please see “PACKAGING”
2, 4, 8
DIMEnSIOnS (mm)
SIZE
0404 (2 x 0402)
0804 (4 x 0402)
0606 (2 x 0603)
1206 (4 x 0603)
2506 (8 x 0603)
1008 (2 x 0805)
2008 (4 x 0805)
4008 (8 x 0805)
1012 (2 x 1206)
2012 (4 x 1206)
4012 (8 x 1206)
NEW
T: Sn
(L: Sn/Pb)
F: (±1%)
G: (±2%)
J: (±5%)
TYPE
Cn 1E 2
Cn 1E 4
Cn 1J 2
Cn 1J 4
Cn 1J 8
Cn 2a 2
Cn 2a 4
Cn 2a 8
Cn 2B 2
Cn 2B 4
Cn 2B 8
L
1.0 ± 0.1
2.0 ± 0.1
1.6 ± 0.2
3.2 ± 0.2
6.4 ± 0.2
2.54 ± 0.2
5.08 ± 0.2
10.16 ± 0.2
2.54 ± 0.2
5.08 ± 0.2
10.16 ± 0.2
W
1.0 ± 0.1
1.6 ± 0.2
2.0 ± 0.2
3.2 ± 0.2
c
0.2 ± 0.1
0.3 ± 0.2
0.4 ± 0.2
0.5 ± 0.3
d ±0.1
0.25
0.40
0.55
t
0.35 ± 0.1
0.45 ± 0.1
0.6 ± 0.1
a (top)
0.3 ± 0.1
0.5 ± 0.1
0.8 ± 0.1
a (bottom)
0.3 ± 0.1
0.4 ± 0.15
0.75 ± 0.15
b
0.07 ± 0.05
0.15 ± 0.01
P (ref.)
(0.50)
(0.80)
(1.27)
FEaTURES
■
2, 4 or 8 isolated resistor elements included in one array
■
Less board space than individual chip resistors
■
High cost reduction efficiency by eliminating mounter operations
■
High self-alignment effect in reflow soldering process
■
Suitable for image recognition systems due to square corner design
■
Precision type ±1% is available
■ CN1J4 parts are tested according to AEC-Q200 requirements
■
Meets or exceeds IEC 60115-1, JIS C 5201-1
■
Rated ambient temperature: +70°C
■
Operating temperature range: -55°C ... +125°C (+155°C on request)
■
Suitable for reflow and wave soldering
MaX.
WORKIng
VOLTagE
25 V
± 200: R
≥
10 Ω
± 400: R
<
10
0.063 W
0.1 W
0.125 V
50 V
100 V
200 V
CIRCUIT COnSTRUCTIOn
CN1E2
CN1J2
CN2A2
CN2B2
CN1E4
CN1J4
CN2A4
CN2B4
CN1J8
CN2A8
CN2B8
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order/or use.
R
1
=R
2
R
1
=R
2
= R
3
=R
4
R
1
=R
2
= R
3
=R
4
=R
5
=R
6
= R
7
=R
8
RaTIng
SIZE
NEW
TYPE
T.C.R.
(ppm/K)*
POWER RaTIng
(per element)**
MaX.
OVERLOaD
VOLTagE
50 V
100 V
200 V
400 V
RESISTanCE RangE
F (±1%)
E24 • E96
g (±2%)
E24
J (±5%)
E24
0404 (2 x 0402)
Cn 1E 2
0804 (4 x 0402)
Cn 1E 4
0606 (2 x 0603)
Cn 1J 2
1206 (4 x 0603)
Cn 1J 4*
2506 (8 x 0603)
Cn 1J 8
1008 (2 x 0805)
Cn 2a 2
2008 (4 x 0805)
Cn 2a 4
4008 (8 x 0805)
Cn 2a 8
1012 (2 x 1206) Cn
2B 2
2012 (4 x 1206)
Cn 2B 4
4012 (8 x 1206)
Cn 2B 8
–
10 Ω… 1 MΩ
–
10 Ω… 1 MΩ
–
–
10 Ω … 100 kΩ
10 Ω … 1 MΩ
1 Ω …1 MΩ
10 Ω … 1 MΩ
10 Ω … 1 MΩ
* CN1J4 (±1%) has TCR ±100ppm/K
** For resistors operated at an ambient temperature of +70°C or above, the power rating shall be derated.
Please note that network resistors generate higher heat rather than single flat chip resistors even under rated power output.
A few cross talks will occur in network resistors. In case of using them for a high frequency circuit, please design circuits taking the effect by the cross talks into consideration.
Rated voltage = Power rating x resistance value or max. working voltage, whichever is lower.
z
EUROPE GmbH • Kaddenbusch 6 • D-25578 Dägeling / ITZEHOE • PHONE: +49 (0) 48 21 / 89 89-0 • FAX: +49 (0) 48 21/ 89 89 89 • Internet: www.koaeurope.de
38
Revision: 14. Dec. 2009
Contact our sales representatives before you use our products for applications including
automotives, medical equipment and aerospace equipment. Malfunction or failure of the
products in such applications may cause loss of human life or serious damage .
4
NO . OF
RESISTORS
T
TERMINATION
SURFACE MATERIAL
TE
TAPING*
J
TOLERANCE
Contact us when you have
control request for environmen-
tal hazardous material other
than the substance specified
by EU-RoHS
