Large Can Aluminum Electrolytic Capacitors
G-AA Series
screw terminal style
General purpose for industrial applications
High ripple current with 3000 hour life
High CV designs
Customized designs available
Rated Working Voltage:
Operating Temperature:
Nominal Capacitance:
Capacitance Tolerance:
Endurance:
16 ~ 500 VDC
-40 ~ +85ºC
150 ~ 1200000µF
± 20%
3000 hours at +85ºC with maximum specified ripple current (see page 4)
Part Number System
E
E
G
A
A
Voltage
Code
Capacitance
Code
Case Size
Code
Terminal Code
"E" type, high post, 10-32 NF-2B thread is standard
Please see page 34 for other terminal options and dimensions
Common Code
Series
Code
Please see page 34 for temperature and frequency ripple current multipliers
G-AA Typical Ratings
Cap.
(µF)
Nominal Size
D x L (inches)
Max 85°C R.C. (A
rms
)
120Hz
10k~100kHz
20°C ESR (Ω, max.)
120Hz
20kHz
Panasonic
Part Number
Cap.
(µF)
Nominal Size
D x L (inches)
Max 85°C R.C. (A
rms
)
120Hz
10k~100kHz
20°C ESR (Ω, max.)
120Hz
20kHz
Panasonic
Part Number
16 VDC Working, 20 VDC Surge
33000
39000
56000
68000
82000
100000
120000
130000
150000
82000
100000
120000
150000
180000
220000
270000
330000
270000
330000
390000
470000
500000
560000
390000
470000
560000
680000
750000
820000
1200000
1.375 x 1.625
1.375 x 2.125
1.375 x 2.625
1.375 x 3.125
1.375 x 3.625
1.375 x 4.125
1.375 x 4.625
1.375 x 5.125
1.375 x 5.625
2.000 x 1.875
2.000 x 2.125
2.000 x 2.625
2.000 x 3.125
2.000 x 3.625
2.000 x 4.125
2.000 x 5.125
2.000 x 5.625
2.500 x 3.125
2.500 x 3.625
2.500 x 4.125
2.500 x 4.625
2.500 x 5.125
2.500 x 5.625
3.000 x 3.125
3.000 x 3.625
3.000 x 4.125
3.000 x 4.625
3.000 x 5.125
3.000 x 5.625
3.000 x 8.625
5.16
5.86
7.30
8.31
9.37
10.51
11.67
12.41
13.44
10.01
11.01
12.41
13.98
15.42
16.93
19.08
20.63
19.31
21.02
22.50
24.11
25.05
26.23
23.79
25.51
27.08
28.74
29.88
30.97
36.78
5.93
6.74
8.40
9.56
10.78
12.09
13.42
14.27
15.46
11.51
12.66
14.27
16.08
17.73
19.47
21.94
23.72
22.21
24.17
25.88
27.73
28.81
30.16
27.36
29.34
31.14
33.05
34.36
35.62
42.30
0.0313
0.0269
0.0196
0.0167
0.0143
0.0123
0.0107
0.0101
0.0091
0.0143
0.0123
0.0107
0.0091
0.0081
0.0072
0.0052
0.0070
0.0064
0.0057
0.0053
0.0049
0.0048
0.0046
0.0053
0.0049
0.0046
0.0043
0.0042
0.0040
0.0037
0.0281
0.0242
0.0177
0.0150
0.0129
0.0110
0.0096
0.0091
0.0082
0.0129
0.0110
0.0096
0.0082
0.0073
0.0064
0.0047
0.0063
0.0057
0.0052
0.0048
0.0044
0.0043
0.0041
0.0048
0.0044
0.0041
0.0039
0.0037
0.0036
0.0033
EEGAA1C333CAE
EEGAA1C393CCE
EEGAA1C563CEE
EEGAA1C683CGE
EEGAA1C823CHE
EEGAA1C104CKE
EEGAA1C124CLE
EEGAA1C134CNE
EEGAA1C154CPE
EEGAA1C823FBE
EEGAA1C104FCE
EEGAA1C124FEE
EEGAA1C154FGE
EEGAA1C184FHE
EEGAA1C224FKE
EEGAA1C274FNE
EEGAA1C334FPE
EEGAA1C274GGE
EEGAA1C334GHE
EEGAA1C394GKE
EEGAA1C474GLE
EEGAA1C504GNE
EEGAA1C564GPE
EEGAA1C394HGE
EEGAA1C474HHE
EEGAA1C564HKE
EEGAA1C684HLE
EEGAA1C754HNE
EEGAA1C824HPE
EEGAA1C125HWE
27000
33000
47000
56000
68000
82000
100000
110000
120000
68000
82000
100000
120000
150000
180000
220000
270000
220000
270000
330000
390000
430000
470000
330000
390000
470000
560000
620000
680000
1000000
1.375 x 1.625
1.375 x 2.125
1.375 x 2.625
1.375 x 3.125
1.375 x 3.625
1.375 x 4.125
1.375 x 4.625
1.375 x 5.125
1.375 x 5.625
2.000 x 1.875
2.000 x 2.125
2.000 x 2.625
2.000 x 3.125
2.000 x 3.625
2.000 x 4.125
2.000 x 5.125
2.000 x 5.625
2.500 x 3.125
2.500 x 3.625
2.500 x 4.125
2.500 x 4.625
2.500 x 5.125
2.500 x 5.625
3.000 x 3.125
3.000 x 3.625
3.000 x 4.125
3.000 x 4.625
3.000 x 5.125
3.000 x 5.625
3.000 x 8.625
20 VDC Working, 24 VDC Surge
4.95
5.72
7.12
8.05
9.12
10.21
11.45
12.25
13.04
9.75
10.70
12.17
13.57
15.22
16.68
18.86
20.50
19.08
20.89
22.62
24.21
25.38
26.49
23.92
25.62
27.34
29.03
30.25
31.41
37.54
5.69
6.58
8.19
9.26
10.49
11.74
13.17
14.09
15.00
11.21
12.31
14.00
15.61
17.50
19.18
21.69
23.58
21.94
24.02
26.01
27.84
29.19
30.46
27.51
29.46
31.44
33.38
34.79
36.12
43.17
0.0327
0.0274
0.0202
0.0174
0.0149
0.0129
0.0112
0.0104
0.0098
0.0149
0.0129
0.0112
0.0098
0.0085
0.0076
0.0068
0.0061
0.0068
0.0061
0.0056
0.0052
0.0050
0.0049
0.0056
0.0052
0.0049
0.0046
0.0045
0.0044
0.0040
0.0295
0.0246
0.0181
0.0157
0.0134
0.0116
0.0100
0.0094
0.0088
0.0134
0.0116
0.0100
0.0088
0.0077
0.0069
0.0061
0.0055
0.0061
0.0055
0.0050
0.0047
0.0045
0.0044
0.0050
0.0047
0.0044
0.0041
0.0040
0.0039
0.0036
EEGAA1D273CAE
EEGAA1D333CCE
EEGAA1D473CEE
EEGAA1D563CGE
EEGAA1D683CHE
EEGAA1D823CKE
EEGAA1D104CLE
EEGAA1D114CNE
EEGAA1D124CPE
EEGAA1D683FBE
EEGAA1D823FCE
EEGAA1D104FEE
EEGAA1D124FGE
EEGAA1D154FHE
EEGAA1D184FKE
EEGAA1D224FNE
EEGAA1D274FPE
EEGAA1D224GGE
EEGAA1D274GHE
EEGAA1D334GKE
EEGAA1D394GLE
EEGAA1D434GNE
EEGAA1D474GPE
EEGAA1D334HGE
EEGAA1D394HHE
EEGAA1D474HKE
EEGAA1D564HLE
EEGAA1D624HNE
EEGAA1D684HPE
EEGAA1D105HWE
