CXOXULP OSCILLATOR
32.768 kHz
Ultra-Low Power/Fast Start-Up/High Shock
DESCRIPTION
The CXOXULP 32.768 kHz oscillator achieves the low
power comparable with a tuning fork design and the fast
start-up and tight frequency stability attained by an AT cut
crystal design. Designed for applications requiring ultra-
low current (17 µA), fast start-up time (2 ms), and a tight
frequency stability (±30 ppm to ±100 ppm) over a wide
temperature range (-55
O
C to +125
O
C). These oscillators
are also capable of withstanding significantly higher shock
than a standard tuning fork design.
FEATURES
DIMENSIONS
A
4
TOP
C
3
D
3
BOTTOM
Ultra-low current (typical 17 µA)
Fast start-up (typical 2 ms)
Tight tolerance
High shock resistance
Low aging
CMOS output
Optional Output Enable/Disable with Tri-State
Low EMI emission
Hermetically sealed ceramic package
Full military testing available
Designed and manufactured in the USA
DIM
A
B
1
2
B
4
E
2
1
TYPICAL
inches
0.126
0.099
mm
3.20
2.50
1.00
1.12
1.00
0.75
MAXIMUM
inches
0.136
0.107
0.043
0.048
0.041
0.031
mm
3.40
2.70
1.09
1.21
1.10
0.85
C
(SM1)
0.039
C
(SM3/SM5)
0.044
D
E
0.040
0.030
PIN CONNECTIONS
APPLICATIONS
1. Output Enable/Disable (E) or no connection (N)
2. Ground
3. Output
4. V
DD
SUGGESTED LAND PATTERN
0.141 (3.6)
Military, Aerospace & Avionics
Communications
Navigation
GPS
Industrial, Computer & Communications
Miniature clock oscillator
Handheld instrumentation
Transponder/Animal migration
Medical
Test & diagnostic equipment
Handheld devices
0.110 (2.9)
0.031 (0.8)
0.039 (1.05)
0.051
(1.3)
inches (mm)
0.039
(1.0)
10216 Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice. Tighter
specifications available (contact factory).
Supply Voltage
1
Calibration Tolerance
2
Frequency Stability
Over Temperature
3
Output Load (CMOS)
Aging, first year
Shock
4
Vibration
5
3.3 V ±10%
±25 ppm, ±50 ppm, ±100 ppm
±10 to ±50 ppm for Commercial
±20 to ±100 ppm for Industrial
±50 to ±100 ppm for Military
15 pF
5 ppm
Std: 5,000 g, 0.3 ms, ½ sine
HG: 10,000 g, 0.3 ms, ½ sine
20 g, 10-2,000 Hz swept sine
Supply Voltage V
DD
-0.3 V to 5.0 V
Storage Temperature
-55
O
C to 125
O
C
Maximum Process Temperature 260
O
C for 20 seconds
ENABLE/DISABLE OPTIONS (E/N)
For the 32.768 kHz CXOXULP, Statek offers two
enable/disable options: E and N. The E-version has a Tri-
State output and stops oscillating internally when the
output is put into the high Z state. The N-version does not
have PIN 1 connected internally and so has no
enable/disable capability. The following table summarizes
the Enable/Disable option E.
Operating Temp. Range -10
O
C to 70
O
C (Commercial)
-40
O
C to 85
O
C (Industrial)
-55
O
C to 125
O
C (Military)
Electrical characteristics:
6
SYMBOL PARAMETER
MIN
TYP
MAX
UNIT
ENABLE/DISABLE OPTION E
FUNCTION TABLE
Enable (Pin 1 High*) Disable (Pin 1 Low)
Output
Frequency Output
Oscillates
High Z State
Stops
V
OH
V
OL
t
startup
t
r
t
f
I
DD
Output Voltage High
Output Voltage Low
Start-up Time
Rise Time (10%-90%)
Fall Time (10%-90%)
Duty Cycle
Input Current
0.9V
DD
2.0
2.6
2.4
45
50
17
µ
A
55
V
0.1V
DD
V
ms
ns
ns
%
Oscillator
*
When PIN 1 is allowed to float, it is held high by an internal pull-up resistor.
PACKAGING OPTIONS
CXOXULP
- Tray Pack
- 12 mm tape, 7” or 13” reels
Per EIA 481 (see Tape and Reel data
sheet #10109)
1. Other voltages available. Contact factory.
2. Other tolerances available.
3. Does not include calibration tolerance. Other tolerances available.
4. Higher shock available. Contact factory.
5. Per MIL-STD-202G, Method 204D, Condition D. Random vibration testing also available.
6. All parameters are measured at 25
O
C with a 10 M and 15 pF load with V
DD
= 3.3 V.
HOW TO ORDER CXOXULP 32.768 kHz SURFACE MOUNT CRYSTAL OSCILLATORS
CXOXULP
HG
4
Supply Voltage
1 = 1.8 V
2 = 2.5 V
3 = 3.0 V
4 = 3.3 V
S
“S” if special or
custom design.
Blank if Std.
N
Enable/Disable
Option
E or N
SM3
,
32.768k /
Frequency
k = kHz
50
Calibration
Tolerance
@ 25
0
C
(in ppm)
/
50
Frequency
Stability over
Temp. Range
(in ppm)
/
/
HG = High
Shock.
Otherwise
leave blank
Terminations
Blank = SM1
= Gold Plated
(Lead Free)
SM3 = Solder Dipped
SM5 = Solder Dipped
(Lead Free)
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
I
M = -55
O
C to +125
O
C
S = Customer Specified
OR
/
/
100
Total
Frequency
Tolerance
(in ppm)
/
I
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10216 Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
