REVISIONS
D
A
F
2X .125 3.18
FOR (S) MOUNTING
REV.
A
ECO. NO
1505
DESCRIPTION
INITIAL RELEASE
DATE
9/13/2007
BY
VJ
F
.275 6.99
.200 5.08
.100 2.54
PC BOARD LAYOUT
CONNECTOR SIDE
E
D
B
A
.100 2.54
CONTACT ID
SCALE 4:1
.043 1.09 MIN
CONTACT MARKINGS:
1 3 5 ... 99
2 4 6 ... 100
E
E
FIRST
POSITION
INDICATOR
2X
.125 3.18
D
.075 1.91
CARDSLOT
C
D
A
.180 4.57
.250 6.35
C
.370 9.40
.297 7.54
INSERTION
DEPTH
.610 15.49
.030 0.77
.200 5.08
ROW SPACING
C
.060 1.52
.025 0.64
F
_ _ C _ _ DTAH-S189
B
ODD NUMBER SIDE
.100±.025 2.54±0.64
TAIL LENGTH
SECTION A-A
B
A
A
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
2. CONTACT MATERIAL: SEE PART NUMBER CODING.
3. PLATING: SEE PART NUMBER CODING.
4. OPERATING TEMPERATURE RATING: SEE PART NUMBER CODING.
5. PROCESSING TEMPERATURE: SEE PART NUMBER CODING.
6. UL FLAMABILITY RATING: 94V-0.
7. VOLTAGE RATING: 600 VDC MIN. AT SEA LEVEL.
8. CURRENT RATING: 3 AMP PER CONTACT PAIR.
9. VOLTAGE DROP: 30 MILLI VOLT AT RATED CURRENT.
10. INSULATION RESISTANCE: 5000 MEGA OHM.
11. CONNECTOR IDENTIFICATION: PART SHALL BE MARKED WITH PART NUMBER AND BARCODE.
12. ACCOMMODATES BOARD THICKNESS: .062 ± .008[1.57 0.20].
13. INSERTION FORCE: 16 OZ MAX PER CONTACT PAIR WHEN USING A .062[1.57] TEST BLADE.
INTERNAL INSPECTION TO BE PER SULLIN’S WORK INSTRUCTION W17.3-01.
14. BOARD WITHDRAWAL FORCE: 1 Oz MIN. PER CONTACT PAIR USING .062[1.57] PCB.
15. RIGHT ANGLE BEND TO HAVE .200[5.08] ROW SPACING.
8
7
6
5
CUSTOMER COPY
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES[MM]
TOLERANCES:
ANGULAR: 1
.XX= .02 [.508]
.XXX= .005 [.1270]
.XXXX= .0005 [.0127]
PARENTHETICAL INFORMATION IS FOR
REFERENCE ONLY
DATE
DRAWN
NAME
9/13/2007 V. JARA
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
SULLINS
ELECTRONICS
A
EDGECARD, .100 CC, HP
REV
_ _C_ _DTA_-S189
SIZE DWG. NO.
RoHS
COMPLIANT
4
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5-1984
3
2
C
C10969
1
A
SHEET 1 OF 3
SCALE: 3:1
FILE NAME: Z:\COMPONENTS\Part Assemblies\Customer Drawings\Customer Drawings for Catalog\C10969, _ _C_ _DTA_-S189 PRINT: 9/28/2007
8
7
6
5
4
3
2
1
D
F
2X #4-40
THREADED
INSERTS
D
D
F
2X
.125 3.18
2X #4-40
THREADED
INSERTS
E
E
.250 6.35
.250 6.35
_ _ C _ _ DTAI-S189
_ _ C _ _ DTAD-S189
D
_ _ C _ _ DTAT-S189
D
D
D
2X
.125 3.18
2X #4-40
THREADED
INSERTS
D
C
4X
.125 3.18
C
.430 10.92
.430 10.92
.245 6.22
_ _ C _ _ DTAS-S189
_ _ C _ _ DTAW-S189
_ _ C _ _ DTAX-S189
B
B
C
CUSTOMER COPY
A
_ _ C _ _ DTAN-S189
8
7
6
5
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES[MM]
TOLERANCES:
ANGULAR: 1
.XX= .02 [.508]
.XXX= .005 [.1270]
.XXXX= .0005 [.0127]
PARENTHETICAL INFORMATION IS FOR
REFERENCE ONLY
DATE
DRAWN
NAME
9/13/2007 V. JARA
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
SULLINS
ELECTRONICS
A
EDGECARD, .100 CC, HP
REV
_ _C_ _DTA_-S189
SIZE DWG. NO.
RoHS
COMPLIANT
4
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5-1984
3
2
C
C10969
1
A
SHEET 2 OF 3
SCALE: 2:1
FILE NAME: Z:\COMPONENTS\Part Assemblies\Customer Drawings\Customer Drawings for Catalog\C10969, _ _C_ _DTA_-S189 PRINT: 9/28/2007
8
7
6
5
4
3
2
1
N0. OF POSITIONS
POSITIONS A±.008[±0.20] B±.008[±0.20]
MM
12.70
15.24
17.78
22.86
27.94
30.48
35.56
40.64
43.18
48.26
53.34
58.42
60.96
68.58
71.12
73.66
76.20
86.36
88.90
99.06
106.68
109.22
121.92
124.46
137.16
149.86
152.40
162.56
175.26
200.66
226.06
251.46
INCH
0.700
0.800
0.900
1.100
1.300
1.400
1.600
1.800
1.900
2.100
2.300
2.500
2.600
2.900
3.000
3.100
3.200
3.600
3.700
4.100
4.400
4.500
5.000
5.100
5.600
6.100
6.200
6.600
7.100
8.100
9.100
10.100
MM
17.78
20.32
22.86
27.94
33.02
35.56
40.64
45.72
48.26
53.34
58.42
63.50
66.04
73.66
76.20
78.74
81.28
91.44
93.98
104.14
111.76
114.30
127.00
129.54
142.24
154.94
157.48
167.64
180.34
205.74
231.14
256.54
C±.015[±0.38]
INCH
0.860
0.960
1.060
1.260
1.460
1.560
1.760
1.960
2.060
2.260
2.460
2.660
2.760
3.060
3.160
3.260
3.360
3.760
3.860
4.260
4.560
4.660
5.160
5.260
5.760
6.260
6.360
6.760
7.260
8.260
9.260
10.260
MM
21.84
24.38
26.92
32.00
37.08
39.62
44.70
49.78
52.32
57.40
62.48
67.56
70.10
77.72
80.26
82.80
85.34
95.50
98.04
108.20
115.82
118.36
131.06
133.60
146.30
159.00
161.54
171.70
184.40
209.80
235.20
260.60
D±.010[±0.25]
INCH
1.175
1.275
1.375
1.575
1.775
1.875
2.075
2.275
2.375
2.575
2.775
2.975
3.075
3.375
3.475
3.575
3.675
4.075
4.175
4.575
4.875
4.975
5.475
5.575
6.075
6.575
6.675
7.075
7.575
8.575
9.575
10.575
E±.020[±0.51]
MM
36.45
38.99
41.53
46.61
51.69
54.23
59.31
64.39
66.93
72.01
77.09
82.17
84.71
92.33
94.87
97.41
99.95
110.11
112.65
122.81
130.43
132.97
145.67
148.21
160.91
173.61
176.15
186.31
199.01
224.41
249.81
275.21
F±.015[±0.38]
INCH
0.750
0.850
0.950
1.150
1.350
1.450
1.650
1.850
1.950
2.150
2.350
2.550
2.650
2.950
3.050
3.150
3.250
3.650
3.750
4.150
4.450
4.550
5.050
5.150
5.650
6.150
6.250
6.650
7.150
8.150
9.150
10.150
MM
19.05
21.59
24.13
29.21
34.29
36.83
41.91
46.99
49.53
54.61
59.69
64.77
67.31
74.93
77.47
80.01
82.55
92.71
95.25
105.41
113.03
115.57
128.27
130.81
143.51
156.21
158.75
168.91
181.61
207.01
232.41
257.81
F
E
D
C
INCH
_ _ C06DTA _ -S189
6
0.500
_ _ C07DTA _ -S189*
7
0.600
_ _ C08DTA _ -S189
8
0.700
_ _ C10DTA _ -S189
10
0.900
_ _ C12DTA _ -S189
12
1.100
_ _ C13DTA _ -S189
13
1.200
_ _ C15DTA _ -S189
15
1.400
_ _ C17DTA _ -S189
17
1.600
_ _ C18DTA _ -S189
18
1.700
_ _ C20DTA _ -S189
20
1.900
_ _ C22DTA _ -S189
22
2.100
_ _ C24DTA _ -S189
24
2.300
_ _ C25DTA _ -S189
25
2.400
_ _ C28DTA _ -S189
28
2.700
_ _ C29DTA _ -S189*
29
2.800
_ _ C30DTA _ -S189
30
2.900
_ _ C31DTA _ -S189
31
3.000
_ _ C35DTA _ -S189
35
3.400
_ _ C36DTA _ -S189
36
3.500
_ _ C40DTA _ -S189
40
3.900
_ _ C43DTA _ -S189
43
4.200
_ _ C44DTA _ -S189
44
4.300
_ _ C49DTA _ -S189 *
49
4.800
_ _ C50DTA _ -S189
50
4.900
_ _ C55DTA _ -S189
55
5.400
_ _ C60DTA _ -S189
60
5.900
_ _ C61DTA _ -S189
61
6.000
_ _ C65DTA _ -S189
65
6.400
_ _ C70DTA _ -S189
70
6.900
_ _ C80DTA _ -S189*
80
7.900
_ _ C90DTA _ -S189*
90
8.900
_ _ C100DTA _ -S189*
100
9.900
* CONTACT FACTORY FOR AVAILABILITY
MM
INCH
29.85 1.435
32.39 1.535
34.93 1.635
40.01 1.835
45.09 2.035
47.63 2.135
52.71 2.335
57.79 2.535
60.33 2.635
65.41 2.835
70.49 3.035
75.57 3.235
78.11 3.335
85.73 3.635
88.27 3.735
90.81 3.835
93.35 3.935
103.51 4.335
106.05 4.435
116.21 4.835
123.83 5.135
126.37 5.235
139.07 5.735
141.61 5.835
154.31 6.335
167.01 6.835
169.55 6.935
179.71 7.335
192.41 7.835
217.81 8.835
243.21 9.835
268.61 10.835
F
E
D
C
PART NUMBER CODING
_ _ C _ _ DTA _-S189
MATERIALS (INSULATOR / CONTACT)
E = PBT/PHOSPHOR BRONZE
OPERATING TEMP: -65°C TO +125°C
PROCESSING TEMP: 260°C FOR 10 SECS MAX
B
MOUNTING STYLE
H = .125" DIA. CLEARANCE HOLES (PAGE 1)
NUMBER OF POSITIONS
(CONTACTS PER ROW)
I = #4-40 THREADED INSERT (PAGE 2)
S = .125" DIA. SIDE MOUNTING (PAGE 2)
N = NO MOUNTING EARS (PAGE 2)
D = FLUSH MOUNTING (PAGE 2)
W = FLUSH MOUNTING (PAGE 2)
T = FLUSH MOUNTING WITH # 4-40 THREADED INSERT (PAGE 2)
X = FLUSH MOUNTING WITH # 4-40 THREADED INSERT (PAGE 2)
B
R = PPS/PHOSPHOR BRONZE
OPERATING TEMP: -65°C TO +125°C
PROCESSING TEMP: 260°C FOR 120 SECS MAX
G = PA9T/PHOSPHOR BRONZE
OPERATING TEMP: -65°C TO +125°C
PROCESSING TEMP: 260°C FOR 120 SECS MAX
H = PBT/BERYLLIUM COPPER
OPERATING TEMP: -65°C TO +125°C
PROCESSING TEMP: 260°C FOR 10 SECS MAX
A = PPS/BERYLLIUM COPPER
OPERATING TEMP: -65°C TO +150°C
PROCESSING TEMP: 260°C FOR 120 SECS MAX
J = PA9T/BERYLLIUM COPPER
OPERATING TEMP: -65°C TO +150°C
PROCESSING TEMP: 260°C FOR 120 SECS MAX
(CONSULT FACTORY FOR OTHER MATERIALS)
PLATING
ALL PLATINGS ARE LEAD FREE AND HAVE .000050" NICKEL UNDERPLATE
CONTACT SURFACE
TERMINATION
G = .000010" GOLD
.000005" GOLD
Y=
B=
C=
**E =
S=
.000030" GOLD
.000005" GOLD
.000010" GOLD
.000100" PURE TIN, MATTE
.000030" GOLD
.000100" PURE TIN, MATTE
.000100" PURE TIN, MATTE, OVERALL
.000010" GOLD OVERALL
CUSTOMER COPY
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES[MM]
TOLERANCES:
ANGULAR: 1
.XX= .02 [.508]
.XXX= .005 [.1270]
.XXXX= .0005 [.0127]
PARENTHETICAL INFORMATION IS FOR
REFERENCE ONLY
DATE
DRAWN
NAME
9/13/2007 V. JARA
A
M = .000030" GOLD
.000010" GOLD OVERALL
** OVERALL PURE TIN ONLY AVAILABLE ON MATERIAL CODES E, R AND G
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
SULLINS
ELECTRONICS
A
EDGECARD, .100 CC, HP
REV
_ _C_ _DTA_-S189
SIZE DWG. NO.
RoHS
COMPLIANT
8
7
6
5
4
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5-1984
3
2
C
C10969
1
A
SHEET 3 OF 3
SCALE: 4:1
FILE NAME: Z:\COMPONENTS\Part Assemblies\Customer Drawings\Customer Drawings for Catalog\C10969, _ _C_ _DTA_-S189 PRINT: 9/28/2007
京公网安备 11010802033920号
EEWORLD
