VGA with RS232 over Cat5/Cat6 Extender Kit,
Box-Style Transmitter and Receiver, 1920x1440
at 60Hz (discontinued)
MODEL NUMBER:
B130-101S
Highlights
q
Extends a 1920 x 1440 (60Hz)
Video and RS232 Serial signal
up to 500 ft., or a 1024 x 768
(60Hz) Video and RS232 Serial
signal up to 1,000 ft., when
using 24Awg, Solid Wire
Cat5e/6 cable, such as Tripp
Lite's N022-01K-GY (Cat5) and
N222-01K-GY (Cat6)
q
For optimal image quality
between 500 and 1,000 ft., use
Zero-Skew cable, such as Tripp
Lite P524-01K
q
Supports bi-directional
communication
q
Compliant with the Federal
Trade Agreements Act (TAA) for
GSA Schedule Purchases
Description
Tripp Lite's B130-101S allows you to extend a 1920 x 1440 (60Hz) Video and RS232 Serial signal up to
500 ft., or a 1024 x 768 (60Hz) Video and RS232 Serial signal up to 1,000 ft., when using 24Awg, Solid
Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6). For optimal
image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K. The local
(Transmitter) unit features an additional VGA port for the connection of a local monitor. The remote
(Receiver) unit features built-in Equalization and Gain controls to adjust the video image. Includes
mounting hardware for both local and remote units, allowing them to be wallmounted, rackmounted or
pole mounted. Ideal for digital signage situations needing serial access, such as bar code scanners or
touchscreen monitors.
q
q
Package Includes
q
Local (Transmitter) unit
Remote (Receiver) unit
Mini-Screwdriver for EQ/Gain
adjustment
(x2) Mounting Hardware kits
(x2) External Power Supply
(Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A)
q
q
Features
q
Extends a 1920 x 1440 (60Hz) Video and RS232 Serial signal up to 500 ft., or a 1024 x 768 (60Hz)
Video and RS232 Serial signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as
Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
q
3.5mm Male to DB9 Male
adapter cable
q
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-
01K
q
3.5mm Male to DB9 female
adapter cable
q
Supports bi-directional communication
The local (Transmitter) unit features an additional VGA port for the connection of a local monitor
The remote (Receiver) unit features built-in Equalization and Gain controls to adjust the video image
Includes mounting hardware for both the local and remote units, allowing them to be wallmounted,
rackmounted or pole mounted
q
Owner's Manual
q
q
q
q
Ideal for digital signage situations needing serial access, such as bar code scanners or touchscreen
1/2
monitors
q
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule Purchases
Specifications
OVERVIEW
UPC Code
AC Adapter
037332151865
Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A, 5ft
PHYSICAL
Shipping Dimensions (hwd / in.)
Shipping Dimensions (hwd / cm)
Shipping Weight (lbs.)
Shipping Weight (kg)
2.200 x 10.200 x 7.600
5.59 x 25.91 x 19.30
1.8000
0.82
CONNECTIONS
Ports
Side A - Connector 1
Side A - Connector 2
Side A - Connector 3
Side B - Connector 1
Side B - Connector 2
Side B - Connector 3
1
(2) HD15 (FEMALE)
RJ45 (FEMALE)
DB9 (MALE)
HD15 (FEMALE)
DB9 (FEMALE)
RJ45 (FEMALE)
FEATURES & SPECIFICATIONS
Technology
Serial (RS232); VGA/SVGA
WARRANTY
Product Warranty Period
(Worldwide)
1-year limited warranty
© 2018 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
2/2
