SPECIFICATIONS.
Current Rating:
Contact Resistance:
Contact Resistance:
Contact Material:
Insulator Material:
Contact Plating:
Withstanding:
Operating Temp:
2 Amps
1000 Megohms min.
20 m ohms max.
Phosphor Bronze
Polyester, UL94V-0 Nylon 6-T
Gold Flash, std
AC 500V
-40C ~ +105C
B
C
D
D
E
Series
BRS
2mm Receptacle
Strip
Rows
XX
01=Single
02=Double
Profile
BELPA
BELPA=2.3mm
Bottom Entry
Positions
XX
Single Row=01-40
Double Row=04-80
Tail Spac-
ing
F
F=5.0mm
Plating
XX
Option 1
Option 2
Option 3
Package
TB=Tube
TR=Reel
E
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
SM
CAP
TN=Tin
SM=Surface Mount Blank=none
SGXX=Selective Gold
PPF=film
GDXX=Gold (std)
PPL=Plastic
XX=flash if blank,
PPM=metal
10,15,30u”
F
Date
01/06/10
01/06/10
01/06/10 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
BRS-02-BELPA-XX-X-XX-SM-XX
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Female Header 2.3mm Bottom Entry, Dual Row SMD
