MMS-108-01-L-SV datasheet, PDF

Datasheet> All Categories > The connector> The connector> MMS-108-01-L-SV

MMS-108-01-L-SV: Descriptionconn rcpt 2mm 8pos sgl vert pcb; CategoryThe connector The connector; File Size127KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

MMS-108-01-L-SV Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MMS-108-01-L-SV	-	-	View	Buy Now

MMS-108-01-L-SV Overview

conn rcpt 2mm 8pos sgl vert pcb

MMS-108-01-L-SV Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SAMTEC
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Factory Lead Time	2 weeks
Samacsys Description	8 Position, Single-Row, Classic Socket Strips, 2mm pitch
Other features	TOP ENTRY; BOTTOM ENTRY
body width	0.079 inch
subject depth	0.175 inch
body length	0.654 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (50)
Contact completed and terminated	Matte Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	1.0286 N
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.079 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	10u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	3.9 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.115 inch
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	8
Evacuation force-minimum value	.6116 N

Preview

Download Datasheet

View All

F-218 (Rev 10OCT17)

MMS–112–02–F–SH

MMS–112–01–L–DH

MMS–116–02–L–DV

(2.00 mm) .0787"

MMS–108–01–L–SV

MMS SERIES

TIGER CLAW SOCKET STRIP

™

Board Mates:

TMMH, TMM,

MTMM, MMT, TW,

LTMM, ZLTMM, TSH

Cable Mates:

TCMD

MMS

NO. PINS

PER ROW

PLATING

OPTION

ROW

OPTION

OTHER

OPTION

SPECIFICATIONS

For complete specifications

see www.samtec.com?MMS

Insulator Material:

Black LCP

Contact Material:

Phosphor Bronze

Plating:

Sn or Au over

50 µ" (1.27 µm) Ni

Current Rating (MMS/TMM):

3.9 A per pin

(2 pins powered)

Operating Temp Range:

-55 °C to +125 °C with Gold

-55 °C to +105 °C with Tin

Insertion Depth:

DH = (2.13 mm) .084" to

(2.79 mm) .110",

SH = (2.13 mm) .084"

minimum or pass-through

Top Entry DV/SV = (2.13 mm)

.084" to (4.32 mm) .170"

Bottom Entry DV/SV =

(4.27 mm) .168" minimum

(Plus board)

RoHS Compliant:

Yes

(2.00)

.0787

02 thru 40

(2.00) .0787

= Gold flash on contact,

Matte Tin on tail

–F

–L

= Single Vertical

–SV

= Single Horizontal

–SH

–DV

= Polarized

Position

–“XX”

–SV

–SH

= 10 µ" (0.25 µm) Gold contact,

Matte Tin on tail

= Double Vertical

(4.00)

.157

(2.00)

.0787

= Double Horizontal

–DH

–DV

No. of positions x

(2.00) .0787 + (0.56) .022

–DH

(4.45)

.175

–SH

–DH

–SV

–DV

(2.92)

.115

(4.70)

.185

(3.05)

.120

(2.00)

.079

(2.92)

.115

–SV

–SH

–DV

–DH

(4.70)

.185

(3.05)

.120

PROCESSING

Lead–Free Solderable:

Yes

SMT Lead Coplanarity:

(0.15 mm) .006" max*

*(.004" stencil solution

may be available; contact

IPG@samtec.com)

MMS

NO. PINS

PER ROW

PLATING

OPTION

ROW

OPTION

OTHER

OPTION

RECOGNITIONS

For complete scope

of recognitions see

www.samtec.com/quality

(2.00)

.0787

FILE NO. E111594

02 thru 40

(2.00)

.0787

(2.16)

.085

= Gold flash

on contact,

Matte Tin on tail

–F

–L

= Single

Vertical

–SV

= Polarized Position

–“XX”

–K

= Single

Horizontal

–SH

–DV

–SV

–SH

–S Row

(3.81) .150

(7.62) .300

(2.00) (4.17)

.0787 .164

–D Row

(5.71) .225

(10.01).394

= 10 µ" (0.25 µm)

Gold contact,

Matte Tin on tail

= Double

Vertical

= (5.50 mm) .217" DIA

Polyimide Film

Pick & Place Pad

(–SV & –DV only)

(–SV= 3 positions min.)

(–DV= 4 positions min.)

ALSO AVAILABLE

(MOQ Required)

• Alignment Pin (–DV only)

• Locking clips and Through-

hole pass-through options

• Other platings

Contact Samtec.

(4.00)

.157

= Double

Horizontal

(5.08)

.200

(5.71)

.225

(4.70)

.185

–DH

= Metal Pick & Place Pad

(4 positions min.)

(–DV only)

–M

–P

–DV

–DH

(1.22)

.048

No. of positions x

(2.00) .0787 + (0.56) .022

–P

–M

(1.22) .048

(1.39) .055

= Plastic Pick & Place Pad

(4 pos. min., –SV only)

(5 pos. min., –DV only)

(4.50)

.177

(1.39)

.055

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

= Tape & Reel Packaging

–DV

–DH

–TR

–SV

–SH

Due to technical progress, all designs, specifications and components are subject to change without notice.

All parts within this catalog are built to Samtec’s specifications.

Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.

WWW.SAMTEC.COM
