2SC5949
TOSHIBA Transistor
Silicon NPN Triple Diffused Type
2SC5949
Power Amplifier Applications
•
•
Complementary to 2SA2121
Recommended for audio frequency amplifier output stage.
Unit: mm
Absolute Maximum Ratings
(Tc = 25°C)
Characteristic
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
200
200
5
15
1.5
220
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
Note: Using continuously under heavy loads (e.g. the application of high
JEDEC
―
temperature/current/voltage and the significant change in
JEITA
―
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
TOSHIBA
2-21F1A
operating temperature/current/voltage, etc.) are within the
Weight: 9.75 g (typ.)
absolute maximum ratings.
Please design the appropriate reliability upon reviewing the
Toshiba Semiconductor Reliability Handbook (“Handling Precautions”/Derating Concept and Methods) and
individual reliability data (i.e. reliability test report and estimated failure rate, etc).
1
2006-11-16
2SC5949
Electrical Characteristics
(Tc = 25°C)
Characteristic
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note 1)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Conditions
V
CB
= 200 V, I
E
= 0
V
EB
= 5 V, I
C
= 0
I
C
= 50 mA, I
B
= 0
V
CE
= 5 V, I
C
= 1 A
V
CE
= 5 V, I
C
= 8 A
I
C
= 10 A, I
B
= 1 A
V
CE
= 5 V, I
C
= 8 A
V
CE
= 5 V, I
C
= 1 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Min
―
―
200
55
35
―
―
―
―
Typ.
―
―
―
―
60
0.4
1.0
30
270
Max
5.0
5.0
―
160
―
3.0
1.5
―
―
V
V
MHz
pF
Unit
μA
μA
V
Note 1: h
FE(1)
classification R: 55 to 110, O: 80 to 160
Marking
Part No. (or abbreviation code)
TOSHIBA
2SC5949
Lot No.
JAPAN
Characteristics
indicator
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
2
2006-11-16
