.100
[2.54] SINGLE ROW ELEVATED SOCKET
Specifications
Current Rating:
3 Amps
Insulator Resistance: 5000 Megohms min
Contact Resistance:
20m ohms max
Dielectric Withstanding: AC 500V
Operating Temperature: -40° ~± 105° C
Max Processing Temp: 230° C to 60 seconds
Contact Material:
Phosphor Bronze
Insulator Material:
Polyester, UL 94V-0, PBT
Finish:
See Contact Plating
.0197 [.50] + .100 [2.54] X No of Positions
.100 [2.54] X (No of Contacts -1)
.100 [2.54]
.095 [2.40]
R
C
R
Recognized under the recognized component
Program of Underwriters Laboratories, Inc.
Products specifications are subject to be changed
without notice.
.077 [1.95]
.244 [6.20]
.335 [8.50]
.100 [2.54]
PIN .0236X.0236 [.60]
Dimensions are in inches [mm]
PART NUMBERING
93 XX S
SERIES CODE
NO. OF CONTACTS
02
to
40
P 11
XX
XX
CONTACT PLATING
Lead Free & RoHS Compliant
.000050” Nickel underplate
CONTACT
03
= Gold Flash
80 =
10
μ
” Gold
85 =
15
μ
” Gold
90 =
30
μ
” Gold
STACKING HEIGHT
A
01
= .435 [11.05]
02
= .435 [11.05]
03
= .535 [13.59]
04
= .635 [16.13]
05
= .435 [11.05]
06
= .535 [13.59]
07
= .635 [16.13]
08
= .735 [18.67]
B
.098 [2.50]
.289 [7.35]
.191 [4.85]
.091 [2.30]
.480 [12.2]
.380 [9.65]
.280 [7.10]
.181 [4.60]
CONSULT FACTORY FOR CONNECTORS BUILT TO YOUR DESIGN
WWW.ECSCONN.COM
