Aluminium Electrolytic Capacitors/GUE
Screw Terminal Type
Series:
GUE
n
Features
Discontinued
Japan
U.S.A
Endurance : +85°C 2000 h
Miniaturized size and high-ripple-current product
n
Recommended Applications
For general-purpose inverter, power supply for
backup system, motor-control inverter
n
Specifications
Category temp. range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
Dissipation Factor
3ﾖCV
-25 to + 85°C
350 to 450 V .DC
820 to 10000 µ F
±20% (120Hz/+20°C)
(µA) or 5 (mA) whichever, smaller, after 5 minutes application of ratedd working
voltage at +20°C C:Capacitance(µF) V: W.V. (V.DC)
Endurance
Shelf Life
Please see the attached standard products list
After 2000 hours application of DC voltage with specified ripple current (< rated DC
working voltage ) at +85°C, the capacitor shall meet the following limits.
Capacitance change ±20% of initial measured value
D.F.
<
175 % of initial specified value
<
initial specified value
DC leakage current
After storage for 1000hours at +85±2
°C
with no voltage applied and then being stabilized
at +20
°C,
capacitors shall meet the limits specified in ìEnduranceî.(With voltage treatment)
n
Frequency Correction Factor for Ripple Current
W.V.(V)
φD(mm)
Freq.(Hz)
350
400, 450
36
51, 64
77, 90
36
51, 64
77, 90
50
0.71
0.83
0.85
0.65
0.81
0.85
60
0.79
0.88
0.90
0.74
0.87
0.90
120
1.00
1.00
1.00
1.00
1.00
1.00
300
1.09
1.07
1.05
1.09
1.07
1.05
360
1.10
1.08
1.06
1.10
1.08
1.06
1k
1.15
1.13
1.08
1.16
1.13
1.11
10k to
1.21
1.20
1.20
1.22
1.21
1.20
n
Dimensions in mm(not to scale)
P
.V.C. sleeve
M5x12
Hexagonal-bolt
Vent
L+4 max
φD
36
51
64
77
90
9 max
F
13.0
22.0
28.6
31.8
31.8
n
Mounting clamp
Type 1;
φ36
59 max
48±1
φD±1
F±1.0
Type 2
H
14
8.4
16
C
E
Type 3
120°
35
°
6
2-3.5x7
44±1
2
φ
D
10
B
A
26
ma
x
45
°
W
1
W
2
12
0
°
5
1
φ
D
(mm)
φD
51
64
77
A
B
C
80.0 68.0 57.5
93.0 81.0 70.0
104.5 93.5 90.0
E H
max
4.4
13
5.0
13
5.0
13
φD
51
64
77
90
φD1 φD2
65.0 74.0
76.0 86.0
89.0 100.0
101.6 113.0
W1
9.0
8.0
8.0
8.0
(mm)
W2
14.0
13.0
14.0
14.0
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consulation without fail.
Mar. 2005
30
°
–
EE185
–
Aluminium Electrolytic Capacitors/GUE
n
Standard Products
W.V.
(V)
Cap.
(±20%)
Case size
Dia.
(mm)
Specification
(µF)
1000
1200
1500
1800
2200
2700
Ripple
Length current
D.F.
(120Hz)
(120Hz)
(+85°C) (+20°C)
(mm)
(A)
Terminal
Pitch
(mm)
Part No.
( ):Mounting Clamp
No
2point 3 point
clamp clamp
36
51
51
51
51
51
51
64
64
64
77
77
77
77
90
51
51
51
51
51
64
64
64
77
77
77
77
90
51
51
51
51
64
64
64
64
77
77
77
90
90
125
65
75
96
96
103
125
103
125
145
96
125
145
145
150
75
96
96
103
125
103
125
145
96
125
145
145
150
75
96
96
125
96
103
125
145
103
125
145
150
150
3.36
3.36
3.69
4.53
4.98
5.91
6.90
7.95
9.09
9.55
9.55
11.49
13.56
14.91
16.83
3.36
4.05
4.53
5.34
6.21
7.20
8.37
8.74
8.74
10.53
12.30
13.56
15.90
3.06
3.72
4.05
5.13
5.75
6.60
7.56
8.40
8.40
9.57
11.28
13.41
14.46
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
13.0
22.0
22.0
22.0
22.0
22.0
22.0
28.6
28.6
28.6
31.8
31.8
31.8
31.8
31.8
22.0
22.0
22.0
22.0
22.0
28.6
28.6
28.6
31.8
31.8
31.8
31.8
31.8
22.0
22.0
22.0
22.0
28.6
28.6
28.6
28.6
31.8
31.8
31.8
31.8
31.8
ECOG2VU102M( )
ECOG2VU102R( )
ECOG2VU122L( )
ECOG2VU152K( )
ECOG2VU182K( )
ECOG2VU222K( )
ECOG2VU272J( )
ECOG2VU332G( )
ECOG2VU392F( )
ECOG2VU472E( )
ECOG2VU472T( )
ECOG2VU562D( )
ECOG2VU682C( )
ECOG2VU822C( )
ECOG2VU103A( )
ECOG2GU102L( )
ECOG2GU122K( )
ECOG2GU152K( )
ECOG2GU182K( )
ECOG2GU222J( )
ECOG2GU272G( )
ECOG2GU332F( )
ECOG2GU392E( )
ECOG2GU392T( )
ECOG2GU472D( )
ECOG2GU562C( )
ECOG2GU682C( )
ECOG2GU822A( )
ECOG2WU821L( )
ECOG2WU102K( )
ECOG2WU122K( )
ECOG2WU152J( )
ECOG2WU182G( )
ECOG2WU222G( )
ECOG2WU272F( )
ECOG2WU332E( )
ECOG2WU332T( )
ECOG2WU392D( )
ECOG2WU472C( )
ECOG2WU562A( )
ECOG2WU682A( )
N
N
Y
Y
Y
N
N
N
N
N
Y
N
N
N
N
Y
Y
Y
N
N
N
N
N
Y
N
N
N
N
Y
Y
Y
N
Y
N
N
N
N
N
N
N
N
F
C
D
D
D
C
C
C
C
C
D
C
C
C
D
D
D
C
C
C
C
C
D
C
C
C
D
D
D
C
D
C
C
C
C
C
C
F
P
P
P
F
F
F
F
F
P
F
F
F
F
P
P
P
F
F
F
F
F
P
F
F
F
F
P
P
P
F
P
F
F
F
F
F
F
F
F
350
3300
3900
4700
5600
6800
8200
10000
1000
1200
1500
1800
2200
2700
400
3300
3900
4700
5600
6800
8200
820
1000
1200
1500
1800
2200
450
2700
3300
3900
4700
5600
6800
Endurance : 85°C 2000h
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consulation without fail.
Mar. 2005
–
EE186
–
