MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
SS
Standard, Height 7mmL
Series
Miniaturized
Solvent Proof
Super miniature series with 7mmL height
Suited for use in compact audio equipment
Load life of 2000 hours at 85 C
Complied to the RoHS directive
Item
Operating temperature range
Leakage current max.
Capacitance tolerance
Dissipation factor max.
(at 120Hz, 20 C)
-40 ~ +85 C
I = 0.01CV or 4
Characteristics
A whichever is greater (after 1 minute)
20% at 120Hz, 20 C
WV
tan
4
0.35
6.3
0.24
10
0.20
16
0.16
25
0.14
35, 40
0.12
50
0.10
63
0.10
Low temperature characteristics
(Impedance ratio at 120Hz)
WV
Z-25 C/Z+20 C
Z-40 C/Z+20 C
4
6
12
6.3
4
8
10
3
6
16, 25
2
4
35 ~ 63
2
3
Load life
(after application of the rated
voltage for 2000 hours at 85 C)
Leakage current
Capacitance change
tan
Less than specified value
Within
20% of initial value
Less than 200% of specified value
are same as load life value.
Shelf life (at 85 C)
After 1000 hours no load test, leakage current, capacitance and tan
The measurement shall be performed at 20 C by the KS C 6035 clause 5.4.
DRAWING
(See page 99)
Unit : mm
DIMENSIONS & MAXIMUM PERMISSIBLE RIPPLE CURRENT
F
WV
4
6.3
10
16
25
35
40
4
4
4
4
4
50
7
7
7
7
7
7
7
7
7
14
17
21
25
30
37
51
72
88
4
4
4
4
4
5
5
6.3
63
7
7
7
7
7
7
7
7
14
17
21
25
30
42
51
72
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
4
4
5
5
6.3
6.3
7
7
7
7
7
7
43
51
71
86
122
148
4
4
5
5
6.3
6.3
7
7
7
7
7
7
52
62
86
104
148
179
4
4
5
5
6.3
6.3
7
7
7
7
7
7
46
57
78
94
132
162
4
4
5
5
6.3
6.3
7
7
7
7
7
7
43
52
73
87
122
148
4
4
5
5
6.3
7
7
7
7
7
37
46
64
78
108
4
4
5
5
6.3
7
7
7
7
7
33
40
57
69
98
4
4
5
6.3
6.3
7
7
7
7
7
33
40
57
80
98
4
5
6.3
6.3
Ripple current (mA rms) at 85 C, 120Hz
Case size
D
L (mm)
FREQUENCY COEFFICIENT OF PERMISSIBLE RIPPLE CURRENT
Frequency
F
60Hz
0.75
0.80
120Hz
1.00
1.00
1kHz
1.55
1.35
10kHz
2.00
1.50
50kHz
2.00
1.62
100kHz
2.00
1.75
~ 47
68 ~ 680
92
