54F547DMQB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> 54F547DMQB

54F547DMQB: DescriptionF/FAST SERIES, OTHER DECODER/DRIVER, INVERTED OUTPUT, CDIP20, CERAMIC, DIP-20; Categorylogic logic; File Size796KB，6 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

54F547DMQB Overview

F/FAST SERIES, OTHER DECODER/DRIVER, INVERTED OUTPUT, CDIP20, CERAMIC, DIP-20

54F547DMQB Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	DIP,
Contacts	20
Reach Compliance Code	unknown
Other features	ADDRESS LATCHES; 3 ENABLE INPUTS
series	F/FAST
JESD-30 code	R-GDIP-T20
length	24.51 mm
Logic integrated circuit type	OTHER DECODER/DRIVER
Number of functions	1
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output polarity	INVERTED
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
propagation delay (tpd)	13.5 ns
Certification status	MILITARY
Maximum seat height	5.08 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	TTL
Temperature level	MILITARY
Terminal surface	NOT SPECIFIED
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm
Base Number Matches	1
