Diplexer
DPX-26x
Diplexer | AWS/PCS | Single and Twin Units | Indoor / Outdoor
•
•
•
•
•
•
Combines the AWS and PCS bands into a single output
Usable at the BTS or antenna end
Built in lightning protection on all ports
Available as single or twin unit, with various DC/AISG bypass configurations
Suitable for indoor or outdoor applications
Pole or wall mounting
Single Unit
Ordering Options
7/16-DIN Female
Connectors
4.3/10 Female
Connectors
Twin Unit
7/16-DIN Female
Connectors
4.3/10 Female
Connectors
When ordering replace “x” with correct option for bypass configuration and single or twin unit.
With Auto-Sense
DC/AISG bypass AWS low band
DC/AISG bypass PCS high band
Full DC/AISG bypass
No DC/AISG bypass (all ports DC grounded)
Electrical Characteristics
AWS (Low Band)
Frequency Band
Insertion Loss
Return Loss
Rejection, PCS
Continuous Average Power
Intermodulation, 2x43 dBm TX Carrier
PCS (High Band)
Frequency Band
Insertion Loss
Return Loss
Rejection, AWS
Continuous Average Power
Intermodulation, 2x43 dBm TX Carrier
General
DC Bypass Rating
DC/AISG Pass
Environmental
Temperature Range
Ingress Protection
Lightning Protection
Operation Compliance
Storage Compliance
Mechanical Characteristics
Finish
Connectors
Dimensions - Single Unit (H x W x D)
Weight - Single Unit
Mounting Options
Pole / Wall Bracket
Light Grey (NCS 1502-R)
See Ordering Options
135 x 140 x 50 mm
< 2.0 kg
Description
Two metal clamps for pole mount included
5.3 x 5.5 x 1.9 in
< 4.4 lbs
Fits Pipe Diameter
45-115 mm
1.8-4.5 in
-40° to +65° C
IP67
5 kA 8/20 μs
ETS 300 019-1-4 Class 4.1E
ETS 300 019-1-1 Class 1.2
-40° to +149° F
3A
Yes, ports that do not bypass DC/AISG are DC grounded
1850-1990 MHz
< 0.25 dB (typical); < 0.38 dB (maximum)
> 20 dB
> 50 dB
100 W
-117 dBm
1695-1780 / 2110-2200 MHz
< 0.2 dB (typical); < 0.3 dB (maximum)
> 20 dB
> 50 dB
100 W
-117 dBm
DPX-26A
DPX-264
DPX-266
DPX-262
DPX-260
DPX-26A-43F
DPX-264-43F
DPX-266-43F
DPX-262-43F
DPX-260-43F
DPX-26AA
DPX-265
DPX-267
DPX-263
DPX-261
DPX-26AA-43F
DPX-265-43F
DPX-267-43F
DPX-263-43F
DPX-261-43F
Quoted performance parameters are provided to offer typical or range values only and may vary as a result of normal manufacturing and operational conditions. Extreme operational
conditions and/or stress on structural supports is beyond our control. Such conditions may result in damage to this product. Improvements to product may be made without notice.
REV051817M
www.amphenol-antennas.com
1 of 2
Diplexer
DPX-26x
Diplexer | AWS/PCS | Single and Twin Units | Indoor / Outdoor
Electrical Block Diagrams
DC/AISG Bypass Low Band
DC/AISG Bypass High Band
Full DC/AISG Bypass
No DC/AISG Bypass
Quoted performance parameters are provided to offer typical or range values only and may vary as a result of normal manufacturing and operational conditions. Extreme operational
conditions and/or stress on structural supports is beyond our control. Such conditions may result in damage to this product. Improvements to product may be made without notice.
REV051817M
www.amphenol-antennas.com
2 of 2
