S O L I D STAT E E L A P S E D T I M E M O N I TO R
200 SERIES
FEATURES
•
High levels of reliability and accuracy for consistent data
acquisition and storage.
•
Silent operation – no moving parts. Eliminates gear and motor
noise.
•
Serial digital output for PC or peripheral reader interface.
•
Safe, reliable EEPROM memory storage of data without
battery back up.
•
Optional resetttable version available.
•
Compact size designed for easy, PC board mounting.
•
Memory will arm only when power has been applied for five
seconds (with no loss of time).
•
Low power consumption.
•
Over 45 years of Curtis design experience and Elapsed Time
Indicators expertise.
SPECIFICATIONS
•
Voltage Range:
4.75 – 10 VDC
•
Reset Voltage:
20VDC +/- 5%
•
Reset Pulse Width:
100 micro sec minimum; 1 sec max
•
Recording and Display Capability:
99,999.99 hours
•
Resolution:
0.01 hours
•
Accuracy:
+/- 0.1% hours
•
Current Consumption:
0.4mA (max) @ 5VDC
•
Operating Temperature:
-40˚ C to +85˚ C
•
Storage Temperature:
-45˚ C to +90˚ C
DESCRIPTION
The Curtis 200 series are elapsed time monitors without displays
that offer unprecedented levels of reliability, performance and
flexibility.
APPLICATION
A wide range of applications including maintenance, total
hours monitoring, true warranty verification and leasing for
commercial, medical, industrial equipment and vehicles.
www.curtisinstruments.com
200 SERIES
DIMENSIONS mm
5.4
90°
TYP.
.58 TYP.
.30
TYP.
±.07
+0.7 -0.5
.57
TYP.
±.07
28.0
±.4
5
1 2
4
3
7.6
±.1
11.5
±.4
2.6
PIN ASSIGNMENT
1. INPUT POWER FROM READER
2. DATA OUTPUT
3. +5 VDC
4. COMMON
5. RESET +20 VDC ±5%
2.5
±.1
22.9
±.1
MODEL ENCODEMENT
201
Elapsed Time Monitor
PC
PC Board Mount
N
N = Non Reset
R = Reset
W A R R A N T Y
Two year limited warranty from time of delivery.
is a trademark of Curtis Instruments, Inc.
Specifications subject to change without notice
©2008 Curtis Instruments, Inc.
50150 REV D 12/08
