M200 Connectors
Female Vertical PC Tail
For Board to Board application
High Temperature material, Low Profile
Twin Beam contacts
Dual Entry
Suitable for use with M20/M200 male connectors series
Please contact sales@harwinasia.com for alternative plating
SINGLE ROW
2.54
B
5.08
M200-308
Recommended PC Board Pattern
2.54
CALCULATION:
A
B
(2.54 x No. of ways per row) + 0.3
2.54 x (No. of ways per row - 1)
DOUBLE ROW
A
3.50
0.
9
0
Recommended PC Board Pattern
3.55
B
HOW TO ORDER
M200-30 X
SERIES CODE
XX
XX
FINISH
45
Gold
TYPE
7
8
9
Single Row
Single Row
Double Row
NO. OF WAYS PER ROW
02 to 40
www.harwinasia.com
All dimensions in mm.
xx
0.
2.54
90
2.54
7.62
2.54
7.62
5.08
2.54mm (.100”) PITCH
M200-307
Recommended PC Board Pattern
A
3.50
3.55
0.
2.54
90
5.08
1.20
2
1.
0
1.
20
