REVISION D
DO NOT
SCALE FROM
THIS PRINT
"E" (REF)
"A"
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
DSEC-XX-XX-X-XX.X-X-RA-TR
No OF POSITIONS
-30,-40,-50 (PER ROW)
SOLDER TAIL LEAD STYLE
-01: 1.57[.062]
-02: 2.36[.093]
TAPE & REEL
(STANDARD PACKAGING)
(SEE NOTE 4)
RIGHT ANGLE
-RA
SOLDER COMPOSTION & STYLE
-1: 63% TIN / 37% LEAD CHARGE TAIL
(USE SUB-IM-C-256-XX.X-X-1)
-2: 96.5% TIN / 3.5% SILVER
LEAD FREE CHARGE TAIL
(USE SUB-IM-C-256-XX.X-X-2)
C
12.96 .510
TO WAFER
12.96 .510 (REF)
C
L
"A"
WT-16-XX-T
(4 PLCS)
PLATING SPECIFICATION
-S:
30µ”
SELECTIVE GOLD, MATTE TIN ON TAILS
(USE SUB-IM-C-256-XX.X-S-X)
-L: 10µ” SELECTIVE GOLD, MATTE TIN ON TAILS
(USE SUB-IM-C-256-XX.X-L-X)
BOARD SPACING
-05.5: 5.5mm
-07.0: 7.0mm
*-08.5: 8.5mm
(* = NOT TOOLED)
C
"B" (REF)
C
0.80 .031 (TYP)
(TOL NON-ACCUM)
"A"
PIN 02 TOP SLOT
DSEC-XX-01-RA-XX.X
TOP
SLOT
"G" (REF)
BOTTOM
SLOT
0.80 .031
C
1.75 .069 (REF)
PIN 01 TOP SLOT
0.38 .015
(REF)
"F"
(ROW HEIGHT)
8.32 (REF)
2.15 .085
1.15 .045 (REF)
C
2.15 .085
PIN 02 BOTTOM SLOT
0.64 .025
(REF) (TYP)
C
"A"
"D"
PIN 01 BOTTOM SLOT
3.85 .152
9.00 .354
TOP CARD
1.32 .052 (REF)
0.64 .025 (REF) (TYP)
NOTES:
C
"C" (REF) (A-PIN CTRS.)
1.69 .067 (REF)
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 2.22N[.5 LB].
3. INSPECT DIMENSION AT 4 CORNERS OF PART.
4. FOR QUANTITIES UP TO 49 PIECES, NO LEADER,
TRAILER OR REEL WILL BE SUPPLIED
FOR QUANTITIES OF 50-124 PIECES, NO LEADER OR
TRAILER WILL BE SUPPLIED
C
BOARD SPACING
6.00 .236 (REF)
BOTTOM
CARD
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN
MILLIMETERS [INCHES].
TOLERANCES ARE:
DECIMALS
1.32 .052 (REF)
PIN 01
(DSEC-30-01-05.5-X-RA)
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
APPLICATION VIEW
1.10 .043 (REF)
(SOME DETAIL OMITTED FOR CLARITY)
(DSEC-30-01-05.5-X-RA)
FIG 1
PIN 04
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
MATERIAL:
INSULATOR: VECTRA E130i
CONTACT: PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
0.8mm PITCH RIGHT ANGLE ASSEMBLY
F:\DWG\MISC\MKTG\DSEC-XX-XX-X-XX.X-X-RA-TR-MKT.SLDDRW
BY:
KNOWLDEN
DSEC-XX-XX-X-XX.X-X-RA-TR
8/4/08
SHEET
1
OF
2
REVISION D
1.66 .065 (REF)
1.33 .052 (REF)
2.16 .085 (REF)
DSEC-XX-01-RA-XX.X
C
1.02±0.10 .040±.004
SUB-IM-C-256-XX.X-X-X
"F" (REF)
'B'
C
"H"(TYP)
1.00 .039
(REF)
"C"
"C"
C
0.15 [.006]
0.05 .002
(SEE NOTE 3)
C
C
1.27 .050
(3 PLCS)
9.00 .354
(REF)
2.05 .081
C
(ONE SOLDER CHARGE REMOVED TO SHOW CONTACT TAIL)
0.38 .015
(REF)
DETAIL 'B'
SCALE 12 : 1
(VIEW ROTATED 90 CCW FOR CLARITY)
SECTION "A"-"A"
SCALE 6 : 1
SECTION "C"-"C"
SCALE 12 : 1
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
0.8mm PITCH RIGHT ANGLE ASSEMBLY
DSEC-XX-XX-X-XX.X-X-RA-TR
BY:
KNOWLDEN
F:\DWG\MISC\MKTG\DSEC-XX-XX-X-XX.X-X-RA-TR-MKT.SLDDRW
8/4/08
SHEET
2
OF
2
