PCD6-12-1212 Overview

Single, Dual output DC-DC converter 1.5W ~ 25W

Preview

Download Datasheet

View All

-SERIES

Single output DC-DC converter 1.5W ~ 6W

Model name

P C 6 - 24 - 5

Series

name

Output

power

Input

voltage

Output

voltage

Features

Input/Output isolation

5 dimensions shield metal case

Over current protection

Adjustable output voltage

Remote ON/OFF control (6W type)

PC1R5 (1.5W type) Specifications

Model

Input Voltage

Output Voltage (*1)

Vdc

PC1R5

–5–3.3

PC1R5

–5–5

PC1R5

–5–12

PC1R5

–12–3.3

PC1R5

–12–5

PC1R5

–12–12

PC1R5

–24–3.3

PC1R5

–24–5

PC1R5

–24–12

PC1R5

–48–3.3

PC1R5

–48–5

PC1R5

–48–12

5VDC (4.5 ~ 9.0V)

5V±5%

12V±5%

(15V±5%)

12VDC (9 ~ 18V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 400

0 ~ 300

0 ~ 125

(0 ~ 100)

1.32

1.5

75 (73)

24VDC (18 ~ 36V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 400

0 ~ 300

0 ~ 125

(0 ~ 100)

1.32

1.5

76 (75)

48VDC (36 ~ 72V)

3.3V±5%

5V±5%

12V±5%

Vdc 3.3V±5%

On-Board Type Power Supply

(15V±5%)

0 ~ 400

0 ~ 300

0 ~ 125

(0 ~ 100)

1.32

1.5

76 (75)

Output Current

0 ~ 400

0 ~ 300

0 ~ 125

(0 ~ 100)

Output Power (max)

Efficiency (typ) (*2)

1.32

1.5

71 (70)

PC3 (3W type) Specifications

Model

Input Voltage

Output Voltage (*1)

Vdc

PC3

–5–3.3

PC3

–5–5

PC3

–5–12

PC3

–12–3.3

PC3

–12–5

PC3

–12–12

PC3

–24–3.3

PC3

–24–5

PC3

–24–12

PC3

–48–3.3

PC3

–48–5

PC3

–48–12

5VDC (4.5 ~ 9.0V)

5V±5%

12V±5%

(15V±5%)

12VDC (9 ~ 18V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 600

0 ~ 250

(0 ~ 200)

1.98

3.0

77 (77)

24VDC (18 ~ 36V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 600

0 ~ 250

(0 ~ 200)

1.98

3.0

78 (78)

48VDC (36 ~ 72V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 600

0 ~ 250

(0 ~ 200)

1.98

3.0

79 (79)

Vdc 3.3V±5%

Output Current

0 ~ 600

0 ~ 250

(0 ~ 200)

Output Power (max)

Efficiency (typ) (*2)

1.98

3.0

72 (72)

PC6 (6W type) Specifications

Model

Input Voltage

Output Voltage (*1)

Vdc

PC6

–5–3.3

PC6

–5–5

PC6

–5–12

PC6

–12–3.3

PC6

–12–5

PC6

–12–12

PC6

–24–3.3

PC6

–24–5

PC6

–24–12

PC6

–48–3.3

PC6

–48–5

PC6

–48–12

5VDC (4.5 ~ 9.0V)

5V±5%

12V±5%

(15V±5%)

12VDC (9 ~ 18V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 1500

0 ~ 1200

0 ~ 500

(0 ~ 400)

4.95

6.0

84 (84)

24VDC (18 ~ 36V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 1500

0 ~ 1200

0 ~ 500

(0 ~ 400)

4.95

6.0

84 (84)

48VDC (36 ~ 72V)

3.3V±5%

5V±5%

12V±5%

(15V±5%)

0 ~ 1500

0 ~ 1200

0 ~ 500

(0 ~ 400)

4.95

6.0

85 (85)

Vdc 3.3V±5%

Output Current

mA 0 ~ 1200

0 ~ 1000

0 ~ 500

(0 ~ 400)

Output Power (max)

Efficiency (typ) (*2)

Remote ON/OFF control

—

3.96

6.0

78 (78)

Possible (CNT terminal)

Common specifications

Withstand Voltage

Cooling

Operating Temperature

Over Current Protection

Input Protection

Input to Output: 500VAC for 1 minute

Convection cooling

–20 ~ +70°C (–20 ~ +50°C: 100%, +60°C: 70%, +70°C: 40%)

Output current limiting, automatic recovery. Avoid to operate overload or dead short for more than 30 seconds.

Built in Fuse on input line

(*1) Measured at the maximum output power with rated input voltage (5VDC, 12VDC, 24VDC, 48VDC)

(*2) At rated input voltage & maximum output power.

115
