SC63LCB

SMD POWER INDUCTORS

XXX

MARKING

●

Features

1. Magnetically shielded construction

2. LOW Profile (3.0mm max. height x 6.3mm square)

3. Low DC resistance makes this product very suitable for large current applications

CHARACTERISTICS

Part Number

Inductance

Test

DC Resistance

(uH)

Frequency

(Ω

MAX)

(1)

(2)

Saturation Temperature

(3)

(4)

Current

(A)

SC63LCB

nduct ance decr ease by

by current

BC63LCB I

Inductance decrease

cur r ent

1000

SC63LCB-1R0

SC63LCB-1R5

SC63LCB-2R2

SC63LCB-3R6

SC63LCB-4R7

SC63LCB-6R2

SC63LCB-100

SC63LCB-120

SC63LCB-150

SC63LCB-180

SC63LCB-220

SC63LCB-270

SC63LCB-330

SC63LCB-390

SC63LCB-470

SC63LCB-560

SC63LCB-680

SC63LCB-820

SC63LCB-101

SC63LCB-151

1.0

1.5

2.2

3.6

4.7

6.2

100

150

100KHZ

14m

16m

20m

27m

34m

40m

62m

66m

79m

100m

119m

150m

175m

188m

235m

275m

338m

413m

519m

778m

3.59

2.93

2.42

1.89

1.66

1.45

1.14

1.04

0.93

0.85

0.77

0.70

0.63

0.58

0.53

0.48

0.44

0.40

0.36

0.31

4.80

Inductance (µH)

4.60

4.37

4.15

3.80

3.42

2.91

2.30

2.22

1.99

1.50

1.42

1.35

1.21

1.14

1.02

0.92

0.89

0.80

0.60

I nduct ance( uH

)

100

151

220

0. 1

1R0

100

DC cur r ent ( m

DC current (mA)

1000

10000

100000

SC63LCB Temperature rise by

ent

63LC Tem at ur e r i se by cur r

current

per

Temperature

r i

°C

Tem at ur e

rise

se ℃

per

1000

2000

3000

4000

5000

6000

7000

8000

9000

10000

151

220

D cur r ent ( m

DC current (mA)

(1). Inductance tolerance for 1.0uH~6.2uH:

±30%,

for 10uH~150uH:

±20%.

Tested at 0.25V, 0ADC and 25℃

(2). DCR measured at 25℃.

(3). The DC current at which the inductance decreases by 30% from its initial value.

(4). The DC current that results in a 40℃ temperature rise from 25℃ambient.

Click here for

QUANTITY PER REEL & PACKING INFORMATION

Custom versions available upon request.

2011 Signal Transformer –Specification subject to change without notice. 07.11

www.signaltransformer.com

500 Bayview Avenue, Inwood, NY 11096

Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
