PRAHT 100, PRAHT 135, PRAHT 182 (CNW)
www.vishay.com
Vishay Sfernice
High Temperature (230 °C) High Precision
Thin Film Wraparound Chip Resistor Arrays
FEATURES
• Tight TCR (10 ppm/°C) and TCR tracking
(to 2 ppm/°C)
• Very low noise < - 35 dB and voltage
coefficient < 0.01 ppm/V
• Ratio tolerance to 0.05 %
• Gold terminations for temperature up to 230 °C
• High temperature (230 °C)
• SnAg terminations for temperature up to 200 °C
• SMD wraparound chip resistor array
• Thin film technology
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
PRAHT arrays can be used in most applications requiring a
matched pair (or set) of resistor elements at very high
temperature up to 230 °C. The networks provide 2 ppm/°C
TCR tracking, a ratio tolerance as tight as 0.05 % and
outstanding stability. They are available in 1 mm, 1.35 mm,
and 1.82 mm pitch.
TYPICAL PERFORMANCE
ABSOLUTE
TCR
TOL.
10 ppm/°C
ABSOLUTE
0.5 %
TRACKING
2 ppm/°C
RATIO
0.05 %
DIMENSIONS
Independent resistors
B
PRAHT 100
DIM.
mm
mil
60
±6
PRAHT 135
mm
1.91
± 0.152
mil
75
±6
PRAHT 182
mm
3.06
± 0.152
mil
120
±6
A
D
E
One common point
F
A
1.52
± 0.152
C
B
0.5
± 0.127
0.38
± 0.13
1
0.7
± 0.1
0.49
0.66
2.57
20
±5
15
±5
40
27.6
±4
19.3
26
101.2
B = N x E (± 0.2 mm)
B = N x E (± 8 mil)
0.5
± 0.127
0.38
± 0.13
1.35
1.05
± 0.1
0.88
1.01
2.96
20
±5
15
±5
53
41.4
±4
34.5
39.8
116.5
0.5
± 0.127
0.40
± 0.13
1.825
1.525
± 0.1
1.99
1.49
4.11
20
±5
16
±5
72
60
±4
78.3
58.7
161.8
B
C
D
A
D
E
Suggested land pattern
(according to IPC-7351A)
C
F
E
F
G
min.
X
max.
Z
max.
G
min.
X
max.
Z
max.
E
Revision: 20-Nov-12
Document Number: 53057
1
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PRAHT 100, PRAHT 135, PRAHT 182 (CNW)
www.vishay.com
Vishay Sfernice
(1)
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: PRAHT100I4-1K00BWGT
P
R
A
H
T
1
0
0
I
4
-
1
K
0
0
B
W
G
T
GLOBAL MODEL
PRAHT 100
PRAHT 135
PRAHT 182
CONFIG.
I:
Independent
C:
Common
NUMBERS OF
RESISTORS
4
VALUE
(2)
Decimal
R or K
ABS. TOL.
D
= 0.5 %
F
=1%
B
= 0.1 %
RATIO TOL.
B
= 0.1 %
W
= 0.05 %
TERMINATION
(3)
N:
SnAg over nickel barrier
G:
Gold over nickel barrier
PACKAGING
Blank
=
Waffle pack
T
=
Tape and reel
N
and
G:
Lead (Pb)-free/ RoHS version
Notes
(1)
Part number can only have 18 digits. Depending on information needed a compromise has to be found. Consult Vishay.
(2)
When the last digit(s) of the ohmic value is (are) 0, it (they) can be omitted.
E.g.: PRAHT100I4-2K20BWGT
can be ordered under PRAHT100I4-2K2BWGT
PRAHT100I4-1K00BWGT
can be ordered under PRAHT100I4-1KBWGT
(3)
N termination for temperature up to 200 °C.
G termination for temperature up to 230 °C.
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
PRAHT 100
PRAHT 135
PRAHT 182
(1)
(2)
SIZE
100
135
182
RESISTANCE
RANGE
10 to 250K
10 to 500K
10 to 2M
POWER
RATING PER
RESISTOR
(1)
W
0.010
0.0125
0.020
ABSOLUTE
TOLERANCE
±%
0.1, 0.5, 1
0.1, 0.5, 1
0.1, 0.5, 1
RATIO
TOLERANCE
%
0.05, 0.1
0.05, 0.1
0.05, 0.1
ABSOLUTE
TCR
(2)
± ppm/°C
15
15
15
RATIO
TCR
(2)
± ppm/°C
2
2
2
Notes
At + 215 °C
At - 40 °C to + 215 °C
CLIMATIC SPECIFICATIONS
Operating temperature range
Storage temperature range
- 55 °C to + 215 °C
- 55 °C to + 230 °C
PACKAGING
Several types of packaging are available: Waffle-pack and
tape and reel.
NUMBER OF PIECES PER PACKAGE
WAFFLE PACK
SIZE
MOQ MAX. QUANTITY TAPE AND REEL
PER BOX
PRAHT 100 x 4 100
60
100
4000
PRAHT 135 x 4 100
60
100
4000
PRAHT 182 x 4 100
50
100
4000
PERFORMANCES
TEST
Noise
Voltage coefficient
PRAHT 100
Limiting voltage
PRAHT 135
PRAHT 182
SPECIFICATIONS
- 35 dB
0.01 ppm/V
50 V
100 V
150 V
DERATING
350
300
RATED POWER IN %
MECHANICAL SPECIFICATIONS
Substrate
Technology
Film
Terminations
(1)
Alumina
Thin Film
Nickel chromium with mineral passivation
N type: SnAg over nickel barrier
G type: Gold over nickel barrier
250
200
150
100
50
0
0
50
100
150
200
250
Note
(1)
N terminations for temperatures up to 200°C.
G terminations for temepratures up to 230°C.
AMBIENT TEMPERATURE IN °C
Revision: 20-Nov-12
Document Number: 53057
2
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PRAHT 100, PRAHT 135, PRAHT 182 (CNW)
www.vishay.com
PACKAGING RULES
Waffle Pack
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered exceeds maximum quantity of a
single waffle pack, the waffle packs are stacked up on the
top of each other and closed by one single cover.
To get “not stacked up” waffle pack in case of ordered
quantity > maximum number of pieces per package:
Please consult Vishay Sfernice for specific ordering
code.
Tape and Reel
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered is between the MOQ and the
maximum reel capacity, only one reel is provided.
When several reels are needed for ordered quantity
within MOQ and maximum reel capacity: Please consult
Vishay Sfernice for specific ordering code.
Vishay Sfernice
MARKING
On the primary package, printed information includes
Vishay S.A. trademark series and model, schematic number
of resistors, ohmic value, absolute tolerance, ratio tolerance,
type of termination: B tinned over nickel barrier.
Marking on parts:
8
7
6
5
M
1
R1
C
2
R2
D
3
R3
U
4
R4
E.g.: Ohmic value 13K:
Coded 1302: M = 1, C = 3, D = 0, U = 2
PERFORMANCE
DRIFTS
TESTS
CONDITIONS
CECC REQUIREMENTS
2.5 Un/2 s
- 55 °C + 155 °C/5 moisture cycles
- 55 °C + 155 °C/5 cycles 30'
1000 h/Pn at 215 °C
Load life
8000 h/Pn at 215 °C
Resistance to solder heat
Moisture resistance
High temperature storage
Note
• Rn: Nominal resistance
260 °C/10 s
0.01 Pn at + 40 °C 93 % RH
1000 h/no load at + 155 °C
0.7 % Rn
0.05 % Rn + 0.05
0.1 % Rn + 0.05
0.1 % Rn + 0.05
0.4 % Rn
0.01 % Rn
0.01 % Rn
0.02 % Rn
ABSOLUTE PER
(Typical Values)
0.05 % Rn + 0.05
0.1 % Rn + 0.05
0.05 % Rn + 0.05
0.5 % Rn
RATIO
0.01 % Rn
0.01 % Rn
0.01 % Rn
0.25 % Rn
Overload
Climatic sequences
Thermal shock
Revision: 20-Nov-12
Document Number: 53057
3
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
