LTA-Series
LTA-Series
SINGLE POLE LIGHTED ROCKER SWITCHES
The illuminated predecessor to the Curvette series whose versatility has allowed it to stand the test of time.
Traditional styling coupled with self cleaning contacts, integrated wire leads, and various actuator choices
has made the LTA-Series appeal to a wide range of markets.
Product Highlights:
Neon or Incandescent Illumination
Long Paddle, Short Paddle or Rocker Actuators
Good for 125/250VAC or Low Voltage DC
Applications
Integrated Wire Lead Construction
Typical Applications:
Appliance
HVAC
Food Service
Transportation
Carling Technologies, Inc.
60 Johnson Avenue, Plainville, CT
06062
Email:
sales
@
carlingtech.com
Application Support:
team2
@
carlingtech.com
Phone:
860.793.9281
Fax:
860.793.9231
www.carlingtech.com
2 |
LTA-Series Single Pole Lighted Rocker Switches - General Specifications, Ordering Scheme, Dimensional Specifications
Dielectric Strength
UL/CSA:
1000V - live to dead metal parts
750V - across open contacts
Mechanical Life
100,000 cycles
Operating Temperature
32°F to 185°F (0°C to 85°C)
Electrical Life
100,000 cycles
1
Base Part Number
LTA201
2
Actuator
Style
P R
3
Actuator
Color
4
Bezel
Color/Style
B -A / 125N
5
Lens
Color
6
Lamp Voltage
1 BASE PART NUMBER: SERIES / CIRCUITRY / RATING
1
/
TERMINATION
10A 250VAC; 15A 125VAC; 3/4 HP 125-250VAC
Solder Lugs .250 Tabs
.187 Tabs
Wire Leads
OFF-NONE-ON
LTA200
LTA201
LTA203
LTA205
2 ACTUATOR STYLE
3
T
Rocker
P
Paddle
3 ACTUATOR COLOR
1
A
Amber
C
Clear
R
Red
G
Green 2
4 BEZEL COLOR
1
B
Black
5 LENS COLOR
2,3
Blank
No Lens
-A
Amber
-C
Clear
6 LAMP VOLTAGE
2
006V
6V incandescent
012V
12V incandescent
018V
18V incandescent
W
White
PS
Short Paddle
-G
-R
-LU
024V
125N
250N
Green
Red
Blue
B
W
Black 4
White 4
24V incandescent
125V neon
250V neon
Notes:
1
Additional ratings and colors are available. Consult factory for details.
2
Neon lamps not recommended with green or blue rocker/lenses.
3
Lens color is specified only if actuator style is P or PS. If style is T (rocker), then leave
position 5 blank.
4
Available with paddle (“P & PS”) style actuators only.
.069[1.75]
DIA
.156[3.96]
DIA
.375[9.52]
.250[6.35]
SOLDER LUG
.055[1.40]
DIA
.250[6.35]
6.000[152.40]
.050[1.27]
.390[9.77]
.250[6.35]
.250[6.35]
.250 TAB (Q.C.)
.187[4.74]
.187 TAB (Q.C.)
.500[12.70]
INTEGRATED WIRE LEAD
(no exposed conductors)
TERMINAL TYPE
.860[21.84]
.550[13.97]
.375[9.52]
.544[13.81]
.890[22.60]
1.120[28.44]
PADDLE
.520 [13.20]
.275[6.98]
1.125[28.57]
SHORT PADDLE
MOUNTING HOLE
Panel Thickness:
.020[.508] min. to
.250[6.35] max.
*Manufacturer reserves the right to change product specification without prior notice.
Email: sales
@
carlingtech.com Application Support: team2@carlingtech.com
Phone: (860) 793–9281 Fax: (860) 793–9231
www.carlingtech.com
Reps & Contact | 3
