SPECIFICATIONS
Current rating:
Contact material:
Contact plating:
Insulator material:
Insulator resistance:
Withstanding:
Processing temperature:
Operating temperature:
1 amp
Copper alloy
Gold
Nylon 6T, UL94V-0
5,000 megohms min.
500VAC for 1 min.
230°/50sec. max.
-40°C to +105°C
A
Recommended PC Board
SMD Layout
B
C
C
A
D
E
D
W
E
F
RoHS compliant
Rev.
Description
A PNT, DIM
Series
Insulator
Rows
Type
Contacts
Contact Length
BPH
X
X
XX
XX
XX
2mm
[blank]=2mm
1-2
[blank]=Straight
Single Row: 1-40 SD=Stand.4.0mm (.157”)
unshrouded
(.079”), (2.7mm
RA=Right Angle
Double Row: 2-80 CSL(A/E/W) for custom
pin header
profile)
SM=Surface Mount
length (unit=inches)
C=1.5 (.059”),
(2.2mm profile)
Date
4/10/09
Approved
Greg
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
08/10/99
08/10/99
08/10/99 Part No.:
Options
XX
TN=Tin
[Blank]=None
SGXX=Selective Gold CP=Centering
GDXX=Gold
peg
XX=Flash if blank,
15,30,50u”
Plating
XX
E
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
G
BPH-2-SM-XX-XX-XX
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Pin header, 2mm pitch, dual row surface mount, optional
