PHOTONIC
DETECTORS INC.
Three Drive Emitter, Oximeter Component
(660/905 nm) Type PDI-E834
PACKAGE DIMENSIONS INCH (mm)
.205 [5.21]
RED L.E.D.
WIRE BOND
I.R. L.E.D.
Nonin capable
.055 [1.40]
.025 [0.64]
.225 [5.71]
CLEAR
ENCAPSULATE
METALIZED CERAMIC
SUBSTRATE
3X SOLDER PAD
CONTACT C
CONTACT B
CONTACT A
Metalized Ceramic Package
APPLICATIONS
Oximeter probes
Finger clamps
Reusable probes
FEATURES
Low cost
660 nm
+
/- 3 nm
3 drive line
DESCRIPTION:
The
PDI-E834
is a three drive line dual
emitter oximeter component. The 660 and 905 nm GaAlAs
emitters are high power LPE grown. The metalized ceramic
has clear epoxy encapsulation with top side solder pads.
These components are ideal for O.E.M. and repair replace-
ments of oximeter probe assemblies.
ABSOLUTE MAXIMUM RATING
(TA=25
O
C unless otherwise noted)
SYMBOL
PARAMETER
MIN
MAX
UNITS
P
d
I
FP
I
FP
V
R
T
o
& T
S
TS
Power Dissipation I
F
=20 mA
Continuous Forward Current
Peak Forward Current
Reverse Voltage
Storage & Operating Temp
Soldering Temperature*
-40
250
30
200
4
+80
240
o
o
SCHEMATIC
B
mW
mA
mA
V
C
C
660 nm
LED
A
C
905 nm
LED
* For 3 seconds max using a heat sink.
ELECTRO-OPTICAL CHARACTERISTICS
(TA=25
O
C unless otherwise noted)
SYMBOL CHARACTERISTIC
P
O
I
V
V
F
Radiant Flux**
Luminous Intensity**
Forward Voltage
Reverse breakdown
Peak Wavelength
Spectral Bandwidth
Rise Time
Fall Time
TEST CONDITIONS
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 10
m
A
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
660 nm
1.8
20
2.4
30
1.8
5
658
661
25
0.8
0.8
664
2.4
5
895
1.2
905 nm
1.8
MIN TYP MAX MIN TYP MAX
UNITS
mW
mcd
1.2
1.5
V
V
V
R
l
p
905
50
0.8
0.8
915
nm
nm
m
S
m
S
λ
T
r
T
r
**
Bare chip measured packaged in a flat TO-18/ TO-46 header without resin coating or cap.
Information in this technical data sheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications
are subject to change without notice.
[FORM NO. 100-PDI-E834 REV A]
