TF02M557.06E | Page 1 of 3
Product Family:
Part Number Series:
General Purpose Thick Film Chip Resistor
TFGL Series
Construction:
High Purity Alumina Substrate
Thick Film resistive element
Wrap around electrodes
RoHS 2011/65/EU compliant
100% matte tin over Ni terminations)
Features:
01005, 0201, 0402, 0603, 0805, 1206,
1210, 1218, 2010, 2512 sizes
Tolerances of ±1.0% and ±5.0%
Resistances from 1Ω to 10MΩ available
High volume production suitable for
commercial and special applications
These general purpose thick film chip resistors are constructed on a high grade ceramic body for extreme durability.
Utilizing a proprietary thick film resistive element to deliver a wide range of size, power handling and resistive values to
make this series suitable for most applications. Very competitive pricing for all volume levels.
Description:
Product Dimensions:
Dimension
TFGL0100
(0402)
(Metric)
L
W
0.016
±0.001
0.008
±0.001
TFGL0201
(0603)
0.024
±0.001
0.012
±0.001
TFGL0402
(1005)
0.039
±0.002
0.020
±0.002
TFGL0603
(1608)
0.063
±0.004
0.031
±0.004
TFGL0805
(2012)
0.079
±0.004
0.049
±0.004
TFGL1206
(3216)
0.122
±0.004
0.063
±0.004
TFGL1210
(3226)
0.122
±0.004
0.102
±0.004
TFGL1218
(3248)
0.120
±0.006
0.181
±0.008
TFGL2010
(5025)
0.197
±0.008
0.098
±0.008
TFGL2512
(6432)
0.252
±0.008
0.126
±0.008
H
Tb
Tt
0.005
±0.001
0.004
±0.001
0.003
±0.001
0.009
±0.001
0.006
±0.002
0.004
±0.002
0.014
±0.002
0.010
±0.004
0.008
±0.004
0.018
±0.006
0.012
±0.006
0.012
±0.004
0.020
±0.006
0.016
±0.008
0.016
±0.008
0.024
±0.006
0.018
±0.008
0.020
±0.008
0.022
±0.004
0.020
±0.008
0.020
±0.008
0.022
±0.004
0.020
±0.010
0.018
±0.010
0.022
±0.004
0.024
±0.010
0.026
±0.010
0.024
±0.004
0.035
±0.010
0.026
±0.010
All dimensions are shown in inches.
Metric case sizes are shown in parenthesis.
Part Numbering:
Ex: TFGL0603R1002J-T5
Product
Designator
English Size
WxL
01005 (use 0100),
0201, 0402
0603, 0805
1206, 1210
1218, 2010
2512
Temp. Coefficient of
Resistance (TCR)
R = 100 ppm/°C
S = 200 ppm/°C
W = See Charts
(TCR value is determined
by resistance value. See
electrical tables)
Resistance Value
Resistance
Tolerance
T&R Packaging Quantity
-T3 = 3,000
-T4 = 4,000
-T5 = 5,000
-T10 = 10,000
-T15 = 15,000
-T20 = 20,000
See electrical tables for available
options versus case size
TFGL
4 digits with the first 3 being
significant. The last digit specifies
the number of zeros. “R” denotes
decimal position as necessary
Jumper = JUMP
F = ±1.0%*
J = ±5.0%
(see electrical
tables)
* Note: Use “F” resistance tolerance code for all Jumper products indicating max resistance of 50mΩ.
Thin Film Technology Corp. | 1980 Commerce Drive, North Mankato, MN 56003 (USA) | +1 (507) 625-8445 |
www.thin-film.com
TF02M557.06E | Page 2 of 3
Electrical Specifications:
Type
English Size
Power
Resistance Range
Resistance
4.7Ω-9.1Ω= -200/+600
(W)
10Ω-91Ω = ±300 (W)
100Ω-1MΩ = ±200 (S)
TFGL01005
01005
1/32 Watt
4.7Ω ~ 1MΩ
TFGL0201
0201
1/20 Watt
TFGL0402
0402
1/16 Watt
TFGL0603
0603
1/10 Watt
TFGL0805
0805
1/8 Watt
1Ω ~ 10MΩ, + Jumper (0Ω)
E-24 Values = ±1.0% (F) or ±5.0% (J)
<10Ω = -200/+600 (W)
10Ω ~ 10MΩ = ±200 (S)
Operating 25 V
Overload 50 V
<10Ω = -200/+400 (W)
10Ω ~ 10MΩ =±100 (R)
Operating 50 V
Overload 100 V
Operating 75V
Overload 150 V
Operating 150 V
Overload 300 V
TCR ppm/°C (code)
Max Voltage
DC or RMS
Operating 15 V
Overload 30 V
Operating Temp.
Range
Packaging
Type
English Size
Max Power @ 70°C
-55°C ~ 125°C
(derating from 100% at 70°C to 0% at 125°C)
20,000 pcs/reel
TFGL1206
1206
1/4 Watt
15,000 pcs/reel
TFGL1210
1210
1/3 Watt
-55°C ~ 155°C
(derating from 100% at 70°C to 0% at 155°C)
10,000 pcs/reel
TFGL1218
1218
1 Watt
5,000 pcs/reel
TFGL2010
2010
1/2 Watt
5,000 pcs/reel
TFGL2512
2512
1 Watt
Resistance Range (Ω)
Resistance Tolerance
(code)
1Ω ~ 10MΩ, + Jumper (0Ω)
E-24 Values = ±1.0% (F) or ±5.0% (J)
E-96 Values + Jumper = ±1.0% (F)
TCR ppm/°C (code)
<10Ω = -200/+400 (W)
10Ω~10MΩ = ±100(R)
<10Ω = ±200 (S)
10Ω ~ 10MΩ= ±100 (R)
Max Voltage:
Operating Temp.
Range
Packaging
Operating 200 V
-55°C ~ 155°C
(derating from 100% at 70°C to 0% at 155°C)
Operating 250 V
5,000 pcs/reel
3,000 pcs/reel
4,000 pcs/reel
Power Derating Curve:
Thin Film Technology Corp. | 1980 Commerce Drive, North Mankato, MN 56003 (USA) | +1 (507) 625-8445 |
www.thin-film.com
TF02M557.06E | Page 3 of 3
Conditions for Jumper:
Type
Power Rating
at 70°C
Resistance
Rated
Current
Peak
Current
Operating
Temp. Range
2.5 A
-55°C~125°C
1A
1.5 A
TFGL0201
1/20 W
TFGL0402
1/16 W
TFGL0603
1/10 W
TFGL0805
1/8 W
TFGL1206
1/4 W
TFGL1210
1/3 W
TFGL1218
1W
TFGL2010
1/2 W
TFGL2512
1W
MAX 0.050Ω (50mΩ)
2 A
3A
4.5 A
3.2 A
4.5 A
2A
3A
3.5 A
5A
7.5 A
11 A
8A
11 A
-55°C ~ 155°C
Reliability Specifications:
Test
Short Time Overload
Resistance to
Test Method
Applied voltage: 2.5X rated voltage or 2X maximum operating voltage, whichever is
less. Test duration: 5 seconds
Dip into 260°C solder bath until fully immersed
10 ±1 seconds
Test Temperature: 70°C
Specification
1% Tol: ±(1%+0.1Ω)
5% Tol: ±(2% +0.1Ω)
1% Tol: ±(0.5%+0.01Ω)
Load Life
Applied voltage: rated voltage
Test period: 1000 hours with power cycling as follows:
90 min. power ON/30 min. power OFF,
Test Condition: 40°C/95% RH
1% Tol: ±(1%+0.1Ω)
5% Tol: ±(3% +0.1Ω)
Moisture Load Life
Applied voltage: rated voltage
Test period: 1000 hours with power cycling as follows:
90 min. power ON/30 min. power OFF
Repeat 5 cycles as follows:
1% Tol: ±(1%+0.1Ω)
5% Tol: ±(3% +0.1Ω)
Temperature Cycle
-55°C(30 min.) / Room temp (2 min) /
+155°C(30 min.) / Room temp (2 min)
1% Tol: ±(0.5%+0.01Ω)
5% Tol: ±(1% +0.01Ω)
Minimum 95% coverage of new
solder
Solderability
Dip into 235°C solder bath until fully immersed (SAC solder)
2 ±0.5 seconds
Thin Film Technology Corp. | 1980 Commerce Drive, North Mankato, MN 56003 (USA) | +1 (507) 625-8445 |
www.thin-film.com
