Model N4A
Description:
The N4A Series OCXO is
where price and performance
meet. This 20mm square
Package is less that 10mm high
and offers exceptional price vs.
Performance value.
The NV4A Series OCXO are
An excellent choice for
Network and Timing
Applications.
OCXO
Features:
•
•
Excellent Frequency vs.
Temperature Stability
Available with
+3.3VDC or +5VDC
supply voltage
Output Level LVCMOS
or HCMOS
Available with SMT
Option in slightly larger
package
RoHS 5
•
•
•
Phase Noise:
Frequency
Offset
1 Hz
10 Hz
100 Hz
1 KHz
10 KHz
Option C
Option A
Square Wave Square Wave
-80 dBc/Hz
-65 dBc/Hz
-120 dBc/Hz
-100 dBc/Hz
-140 dBc/Hz
-120 dBc/Hz
-145 dBc/Hz
-140 dBc/Hz
-150 dBc/Hz
-145 dBc/Hz
Output Waveform:
HCMOS
LVCMOS
Type 4
Type 3
Level “0”: 0 to 0.5 V Level“0”:0 to 0.3V
Level “1”: 3.8 to 5 V Level”1”:2.8to3.3V
< 4 nsec
< 4 nsec
Rise/Fall Time
Rise/Fall Time
50 +/- 5%
50 +/- 5%
Duty Cycle
Duty Cycle
5V Supply Only
3.3V Supply Only
Supply Voltage
Power Consumption
Product Code
Supply Voltage & Power Consumption:
3.3V +/-10%
5V +/-10%
5V +/-10%
3.0W Startup Power
3.0W Startup Power 3.0W Startup Power
1.3W Steady State
1.0W Steady State
1.3 Steady State
Phase Noise option A Phase Noise Option C
C
D
D
Operating Temperature and Frequency Stability:
Operating
Temperature
Stability Code Stability Code Stability Code Stability Code
+/- 200 ppb
+/- 150 ppb
+/- 20 ppb
+/- 10 ppb
Range Code
Temperature
Phase noise option C
Phase Noise Option A
-20 to +70°C
3
N/A
G
N/A
B
-40 to +85°C
5
H
N/A
D
N/A
www.bliley.com
2545 West Grandview Blvd Erie, PA. 16506
Page 1 of 2
Tel
(814) 838-3571
Rev 4.0
Model N4A
OCXO
Pulling Range (Positive Slope):
A
C
Available only with Phase Noise Option
Supply
Tuning Range
+/-10 ppm .8ppm min./2.4ppm max.
5VDc
(0V to 4V on Vcontrol)
Product Code
Option E
Option C
Supply
Tuning Range
+/-10 ppm .8ppm min./2.4ppm max.
3.3VDc
(0 to 3.3V on Vcontrol)
Product Code
Option F
Option B
Aging:
(typical at 10 MHz after 30 days continuous operation)
Aging
Frequency Timeframe
10 MHz
1 Year
Less than .5ppm Phase Noise Option A
10 MHz
1 Year
Less than .1ppm Phase Noise Option B
Ordering Options:
Model #
N4A
Phase
Noise
A
C
Operating
Temp
3
5
Freq vs.
Temp
Stability
Supply
Volt
C
D
Output
Type
3
4
EFC
B
C
E
F
Customer
Frequency Option
S
8 to
30MHz
B
D
G
H
Part number format N4A-LNL-LNL-10M (Use –S at end for Surface Mount)
STANDARD PACKAGE OUTLINE
SMT OPTION OUTLINE
www.bliley.com
2545 West Grandview Blvd Erie, PA. 16506
Page 2 of 2
Tel
(814) 838-3571
Rev 4.0
