PC733
PC733
g
Lead forming type ( I type ) is also available. (
PC733I
)
AC Input Type Photocoupler
s
Features
1. AC input response
2. High isolation voltage between input and
output ( V
iso
: 5 000V
rms
)
3. Current transfer ratio
CTR : MIN. 15% at I
F
= ± 1mA, V
CE
= 5V
4. Low collector dark current
( I
CEO
: MAX. 10
- 7
A at V
CE
= 20V)
5. TTL compatible output
6. Recognized by UL, file No. E64380
s
Outline Dimensions
1.2
±
0.3
6
5
PC733
4
6.5
±
0.5
( Unit : mm )
Internal connection
diagram
6
5
4
1
2
3
1
2
7.62
±
0.3
3
Primary side mark
(Sunken place )
0.5TYP.
3.5
±
0.5
9.22
±
0.5
s
Applications
1. Telephone sets
2. Programmable controllers
3. System appliances, measuring instruments
4. Signal transmission between circuits of
different potentials and impedances
3.7
±
0.5
2.54
±
0.25
0.5
±
0.1
1
2
3
Anode, cathode
Anode, cathode
NC
θ
0.26
±
0.1
θ
=
0 to 13
˚
4
5
6
Emitter
Collector
Base
θ
s
Absolute Maximum Ratings
Parameter
Forward current
*1
Pead forward current
Power dissipation
Collector-emitter voltage
Emitter-collector voltage
Collector-base voltage
Emitter-base voltage
Collector current
Collector power dissipation
Total power dissipation
*2
Isolation voltage
Operating temperature
Storage temperature
*3
Soldering temperature
Symbol
I
F
I
FM
P
V
CEO
V
ECO
V
CBO
V
EBO
I
C
P
C
P
tot
V
iso
T
opr
T
stg
T
sol
Rating
± 50
±1
70
35
6
35
6
50
150
170
5 000
- 25 to + 100
- 40 to + 125
260
( Ta = 25˚C )
Unit
mA
A
mW
V
V
V
V
mA
mW
mW
Vrms
˚C
˚C
˚C
Input
Output
*1 Pulse width<=100µs, Duty ratio : 0.001
*2 40 to 60% RH, AC for 1 minute
*3 For 10 seconds
“
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that occur in equipment using any of SHARP's devices, shown in catalogs,
data books, etc. Contact SHARP in order to obtain the latest version of the device specification sheets before using any SHARP's device.
”
PC733
Fig. 5 Peak Forward Current vs. Duty Ratio
10 000
5 000
Peak forward current I
FM
( mA )
2 000
Forward current I
F
( mA )
1 000
500
200
100
50
20
10
5
5
10
- 3
2
5
Fig. 6 Forward Current vs.
Forward Voltage
500
200
100
50
20
10
5
2
1
T
a
= 75˚C
50˚C
25˚C
0˚C
- 25˚C
Pulse width<=100µ s
T
a
= 25˚C
10
-2
2
5
10
-1
2
5
1
0
0.5
1.0
1.5
2.0
2.5
(V)
3.0
3.5
Duty ratio
Forward voltage V
F
Fig. 7 Current Transfer Ratio vs.
Forward Current
100
V
CE
= 5V
R
BE
=
Current transfer ratio CTR ( % )
80
T
a
= 25˚C
Fig. 8 Collector Current vs.
Collector-emitter Voltage
50
Collector current I
C
( mA )
I
F
= 50mA
40
30
20
10
0
0
1
2
3
4
5
6
7
CE
P
C
( MAX.)
40mA
30mA
20mA
10mA
R
BE
=
T
a
= 25˚C
60
5mA
8
(V)
9
10
40
Collector-emitter voltage V
20
0
0.1
0.2
0.5
1
2
5
10
20
50 80
Forward current I
F
( mA )
Fig. 9 Relative Current Transfer Ratio vs.
Ambient Temperature
150
I
F
= 1mA
V
CE
= 5V
R
BE
=
Fig.10 Collector-emitter Saturation Voltage
vs. Ambient Temperature
Collector-emitter saturation voltage V
CE ( sat )
( mV )
150
I
F
= 20mA
125
I
C
= 1mA
R
BE
=
100
Relative current transfer ratio ( % )
100
75
50
50
25
0
- 25
0
-25
0
25
50
75
100
0
25
50
75
100
Ambient temperature Ta ( ˚C )
Ambient temperature T
a
( ˚C )
Application Circuits
