PACIFIC DISPLAY DEVICES
LCD Component Data Sheet
Model Number: 12232-10
122 x 32 Dot
Graphic LCD Assembly
With SED1520 Graphics Controller
LED & EL Panel Backlight
CONTENTS
1.
GENERAL INFORMATION
1.1 Product Overview
1.2 Part Options and Numbering System
1.3 Absolute Maximum Ratings
1.4 Circuit Block Diagram
1.5 Mechanical Characteristics
1.6 Input Signal Function
1.7 LCM Power, Contrast Control and Bias
1.8 LCM Dimensions
1.9 LCM Schematic
1.10 LCM Application Notes
ELECTRICAL / OPTICAL CHARACTERISTICS
2.1 DC Electrical Characteristics
2.2 AC Electrical Characteristics
2.3 Optical Characteristics
2.4 LED Backlight Characteristics
2.5 EL Panel Backlight Characteristics
LCD CONTROLLER CHARACTERISTICS
3.1 LCD Controller Display and Control Functions (SED 1520)
3.2 LCD Controller Display Data Ram Address Map
RELIABILITY
PRECAUTIONS FOR USING LCD MODULES
139 Avenida Victoria – Suite 100 – San Clemente, CA – 92672
Tel: 949-361-8957 – Fax: 949-361-9158 – Web: www.pacificdisplay.com
2
2
3
3
3
4
4
5
6
7
2.
8
9
10
12
12
3.
13
15
16
17
4.
5.
SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE
MODEL NO: 12232-10
1. GENERAL INFORMATION
1.1 Product Overview
•
122 x 32 dot matrix LCD
•
STN (Super Twisted Nematic) or FSTN (Film compensated Super Twisted Nematic) Technology
•
SED1520 (or equivalent) Graphics Controller
•
Multiplex drive : 1/32 duty, 1/6 bias
•
LCD Module Service Life: 100,000 hours minimum
1.2 Part Options and Numbering System
12232
-10
-SL
-F
-ST
-LED
-GY
-6
Custom Option Designator:
•
(-10) SED1520 Cntlr, Connector
Built in Mounting Tabs
Operating Mode:
•
(-SL) STN Silver / Gray
•
(-GR) STN Green
•
(-BN) STN Blue Negative Image
•
(-FC) FSTN: Blk & Wht Image
•
(-FN) FSTN Neg:. Wht & Blk Image
Rear Polarizer Options:
•
(-F) Transflective
•
(-M) Transmissive
•
(-R) Reflective (No Backlight)
Operating Temperature:
•
(-ST) Standard (0 to +50 ºC)
•
(-ET) Extended (-20 to +70 ºC)
Backlight Options:
•
(-LED) Array Lit LED Backlight
•
(-ELP) EL Panel Backlight
Backlight Coloration Options:
•
(-GY) LED - Green/Yellow
•
(-AM) LED - Amber
•
(-WH) ELP – White
•
(-BG) ELP – Blue Green
Viewing Angle:
•
(-6) 6 o’clock
•
(-12) 12 0’clock
Additional Options:
•
PACIFIC DISPLAY DEVICES
02.21.06
2
SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE
MODEL NO: 12232-10
1.3 Absolute Maximum Ratings
Parameter
Supply voltage for logic
Supply voltage for LCD
Input voltage
Standard Operating temperature
Standard Storage temperature
Extended Operating temperature
Extended Storage temperature
Soldering Temp
Symbol
V
DD
– V
SS
V
DD
- V
O
VI
TOP (-ST)
TST (-ST)
TOP (-ET)
TST (-ET)
Tsolder
Min
-0.3
– 0.3
-0.3
0
-10
-20
-30
260
Max
6.7
13.0
V
DD
+0.3
50
60
70
80
Unit
V
V
V
ºC
ºC
ºC
ºC
ºC
1.4 Circuit Block Diagram
1.5 Mechanical Characteristics
Item
Module size (W×H×T)
Viewing area (W×H)
Active area (W×H)
Number of dots
Dot size (W×H)
Dot pitch (W×H)
Contents
65.1 x 27.1 x 15.1 Max (All configurations)
60.5 x 18.5
53.64 x 15.64
122 x 32
0.4 x 0.45
0.44 x 0.49
Unit
mm
mm
mm
dots
mm
mm
PACIFIC DISPLAY DEVICES
02.21.06
3
SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE
MODEL NO: 12232-10
1.6 Input Signal Function
Pin No.
1
2
3
4
5
Symbol
A0
/CS1
/CS2
CL
/RD
Level
H/L
L
L
H/L
L
Description
H : Data signal, L : Instruction signal
Chip select signal for SED 1520 (Master)
Chip select signal for SED 1520 (Slave)
2KHz External Clock (-FAA Chip Type)
L : Read data bus from controller mode
Appropriate /CS line must also be active
This is the “R/W” line on the 1520
L : Write data bus to controller mode
Appropriate /CS line must also be active
This is the ”E” line on the 1520
Ground
Data bit 0
Data bit 1
Data bit 2
Data bit 3
Data bit 4
Data bit 5
Data bit 6
Data bit 7
Supply voltage for logic
Falling Edge Reset – Selects 8080 Interface
Must be left “Low” during normal module operation
Input voltage for LCD backplane (Contrast)
LED Backlight Anode
LED Backlight Cathode
Notes*
2
2
5
3, 4
6
7
8
9
19
11
12
13
14
15
16
17
/WR
VSS
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
VDD
RES
L
0V
H/L
H/L
H/L
H/L
H/L
H/L
H/L
H/L
5.0V
H
L
3, 4
3
18
VO
---
1
19
LED-A
4.2V
20
LED-K
0V
*Notes:
1) VO is referenced to both VDD and temperature. See table on page 6 for exact value(s).
2) “/CS1” & “/CS2” tie to the separate /CS pins on the Master & Slave SED 1520 to be used as the Controller select.
The “E” (/WR) line cannot be used as a “E” line in a 6800 implementation since it is common to both controllers.
3) This module can only use the 8080 style interface, and it is set by the state of the reset line.
Reset occurs when reset line transitions High to Low.
Reset line MUST be left in “Low” signal level condition during normal module operation
4) If /CS1 & /CS2 are both active (high), and /RD line is set to Read (low), damage can occur to module due to bus
contention causing serious over-current conditions.
5) External 2KHz clock must be supplied – see SED-1520 data sheet for clock signal requirements
1.7 LCM Power, Contrast Control and Bias
VDD
VO
VR:
20Kohm
VEE: -5.0V
VSS
A
LED / EL
Backlight
K
PACIFIC DISPLAY DEVICES
02.21.06
4
Backlight
Power
VDD: +5V
LCM
SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE
MODEL NO: 12232-10
1.8 LCM Dimensions
PACIFIC DISPLAY DEVICES
02.21.06
5
