FEATURES
15KP17-15KP280
15000W TRANSIENT VOLTAGE SUPPRESSOR
Axial and radial available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number
Available as non-RoHS (Sn/Pb plating), standard, and as RoHS by adding “-PBF” suffix.
Available in both axial leaded and radial packages (“R” prefix for radial packages)
Selections for 170 to 280 volts standoff voltage
Suppresses transients up to 15000 watts @ 10/10000µa and 100000 watts @ 8/20µs
Fast response
MAXIMUM RATINGS
Rating
Peak Pulse Power Dissipation @ 25°C
Impulse Repetition Rate (Duty factor)
t
clamping
(0 volts to V
(BR)
min):
Operating and Storage Temperature:
Thermal Resistance:
Steady-State Power dissipation:
Forward Surge Voltage:
Solder Temperatures:
15000 watts at 10/1000µs
0.05%
< 100ps theoretical for unidirectional and < 5 ns for bidirectional
-65 to +150°C
20°C/W junction to lead or 80°C/W junction to ambient when mounted on FR4 PC board
with 4mm
2
copper pads and track width 1 mm, length 25 mm
6 watts at T
L
= 30°C or 1.56 watts at T
A
= 25°C when mounted on FR4 PC board described
for thermal resistance
200A, 8.3 ms half-sine wave
260°C for 10 s (maximum)
Value
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Part
Number
Reverse
Stand-Off
Voltage
V
WM
(1)
Volts
15KP17
15KP17A
15KP18
15KP18A
15KP20
15KP20A
15KP22
15KP22A
15KP24
15KP24A
15KP26
15KP26A
15KP28
15KP28A
15KP30
15KP30A
15KP33
17
17
18
18
20
20
22
22
24
24
26
26
28
28
30
30
33
Breakdown Voltage
V
(BR)
V
(BR)
@
Volts
18.9
18.9
20.0
20.0
22.2
22.2
24.4
24.4
26.7
26.7
28.9
28.9
31.1
31.1
33.3
33.3
36.7
l
(BR)
mA
50
50
50
50
20
20
10
10
5
5
5
5
5
5
5
5
5
Maximum
Clamping
Voltage
V
C
@ l
PP
Volts
32.3
29.3
34.2
30.9
37.9
34.3
41.1
37.1
45.0
40.7
48.7
44.0
52.4
47.5
56.2
50.7
66.0
Maximum
Standby Current
l
D
@ V
WM
µA
5000
5000
5000
5000
1500
1500
500
500
150
150
50
50
25
25
15
15
10
Maximum Peak
Pulse Current
l
PP
A
464
512
439
485
396
437
365
404
333
369
308
341
286
316
267
296
227
Maximum
Temperature
Coefficient of V
(BR)
α
V(BR)
mV/°C
19
17
20
18
24
21
27
24
30
27
32
29
35
31
27
34
46
Rev. 20150527
High-reliability discrete products
and engineering services since 1977
Reverse
Stand-Off
Voltage
V
WM
(1)
Volts
15KP33A
15KP36
15KP36A
15KP40
15KP40A
15KP43
15KP43A
15KP45
15KP45A
15KP48
15KP48A
15KP51
15KP51A
15KP54
15KP54A
15KP58
15KP58A
15KP60
15KP60A
15KP64
15KP64A
15KP70
15KP70A
15KP75
15KP75A
15KP78
15KP78A
15KP85
15KP85A
15KP90
15KP90A
15KP100
15KP100A
15KP110
33
36
36
40
40
43
43
45
45
48
48
51
51
54
54
58
58
60
60
64
64
70
70
75
75
78
78
85
85
90
90
100
100
110
Breakdown Voltage
V
(BR)
V
(BR)
@
Volts
36.7
40.0
40.0
44.4
44.4
47.8
47.8
50.0
50.0
53.3
53.3
56.7
56.7
60.0
60.0
64.4
64.4
66.7
66.7
71.1
71.1
77.8
77.8
83.3
83.3
86.7
86.7
94.4
94.4
100
100
111
111
122
l
(BR)
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
15KP17-15KP280
Maximum
Clamping
Voltage
V
C
@ l
PP
Volts
54.8
66.0
59.7
72.8
65.8
77.1
69.7
80.7
73.0
85.9
77.7
91.5
82.8
96.8
87.5
104.0
94.0
107.0
97.3
115
104
126
114
135
122
140
126
152
137
160
146
179
162
196
Maximum
Standby Current
l
D
@ V
WM
µA
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum Peak
Pulse Current
l
PP
A
274
227
251
206
228
195
215
186
205
175
193
164
181
155
171
144
160
140
154
130
144
119
132
111
123
107
119
99
109
94
103
84
93
77
15000W TRANSIENT VOLTAGE SUPPRESSOR
Maximum
Temperature
Coefficient of V
(BR)
α
V(BR)
mV/°C
38
46
41
51
46
55
50
57
52
62
56
66
60
70
63
76
68
78
71
84
76
92
83
100
89
104
93
113
102
120
109
134
121
147
Part
Number
Rev. 20150527
High-reliability discrete products
and engineering services since 1977
Reverse
Stand-Off
Voltage
V
WM
(1)
Volts
15KP110A
15KP120
15KP120A
15KP130
15KP130A
15KP150
15KP150A
15KP160
15KP160A
15KP170
15KP170A
15KP180
15KP180A
15KP200
15KP200A
15KP220
15KP220A
15KP240
15KP240A
15KP260
15KP260A
15KP280
15KP280A
110
120
120
130
130
150
150
160
160
170
170
180
180
200
200
220
220
240
240
260
260
280
280
Breakdown Voltage
V
(BR)
V
(BR)
@
Volts
122
133
133
144
144
167
167
178
178
189
189
200
200
222
222
245
245
267
267
289
289
311
311
l
(BR)
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
15KP17-15KP280
Maximum
Clamping
Voltage
V
C
@ l
PP
Volts
178
214
193
231
209
268
243
287
259
304
275
321
291
356
322
393
356
428
38/8
464
419
500
452
Maximum
Standby Current
l
D
@ V
WM
µA
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum Peak
Pulse Current
l
PP
A
84
70
78
65
72
56
62
52
58
49
55
47
52
42
47
38
42
35
39
32
36
30
33
15000W TRANSIENT VOLTAGE SUPPRESSOR
Maximum
Temperature
Coefficient of V
(BR)
α
V(BR)
mV/°C
133
161
145
174
157
202
183
216
195
229
207
242
219
269
243
297
269
324
293
352
317
378
342
Part
Number
Note 1: Transient voltage suppressors are normally selected with reverse “Stand-Off Voltage” V
WM
which should be equal or greater than the dc or continuous peak operating voltage level.
Note 2: For bidirectional construction, indicate C or CA suffix after the part number.
SYMBOLS AND DEFINITIONS
Symbol
V
WM
P
PP
V
BR
Definition
Working peak (stand-off voltage)
Peak pulse power
Breakdown voltage
Symbol
I
PP
V
C
I
(BR)
Definition
Peak pulse current
Clamping voltage
Breakdown current
for V
(BR)
Symbol
I
D
Definition
Standby current
Rev. 20150527
High-reliability discrete products
and engineering services since 1977
MECHANCIAL CHARACTERISTICS
Case
Marking
Polarity
Digi I
Body-painted, alpha numeric
15KP17-15KP280
15000W TRANSIENT VOLTAGE SUPPRESSOR
Cathode band. Bidirectional not marked for polarity.
Case
Marking
Polarity
5R
Body-painted, alpha numeric
Cathode band. Bidirectional not marked for polarity.
Rev. 20150527
High-reliability discrete products
and engineering services since 1977
15KP17-15KP280
15000W TRANSIENT VOLTAGE SUPPRESSOR
Rev. 20150527
