SG73G
endured pulse power flat chip resistors
(ultra precision grade)
NEW
features
•
Superior to RK73 series chip resistors in
pulse withstanding voltage and high power
•
High precision resistor with T.C.R. ±50x10
-6
/K
and tolerance ±0.25%, ±0.5%
•
Suitable for both reflow and flow solderings
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
AEC-Q200 Qualified
resistors
EU
dimensions and construction
Type
c
L
c
(Inch Size Code)
L
Dimensions
inches
(mm)
W
c
d
t
W
Solder
Plating
t
d
Protective
Coating
Resistive Inner
Film
Electrode
Ni
Plating
SG73G1J
(0603)
SG73G2A
(0805)
SG73G2B
(1206)
.063±.008 .031±.004 .012±.004 .012±.004 .018±.004
(1.6±0.2)
(0.8±0.1)
(0.3±0.1)
(0.3±0.1) (0.45±0.1)
.079±.008 .049±.004
(2.0±0.2) (1.25±0.1)
.126±.008 .063±.008
(3.2±0.2)
(1.6±0.2)
.012
(0.3
.016
(0.4
+.008
-.004
+0.2
)
-0.1
+.008
-.004
+0.2
)
-0.1
.012
(0.3
.016
(0.4
+.008
-.004
+0.2
)
-0.1
+.008
-.004
+0.2
)
-0.1
.02±.004
(0.5±0.1)
.024±.004
(0.6±0.1)
Ceramic
Substrate
Derating Curve
100
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
1J/0.2W
2A/0.25W
2B/0.33W
100
80
1J/0.2W
2A/0.25W
2B/0.33W
100
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
2A/0.5W (100°C)
2B/0.5W (120°C)
1J/0.33W (125°C)
% Rated Power
60
40
20
0
-60 -40 -20
-55
0
20
40
60
80 100 120 140
70
Ambient Temperature
(°C)
160
155
0
100 120 140 160
125
155
Terminal Part Temperature
(°C)
20
40
60 80
0
60 80 100 120 140 160
125
155
Terminal Part Temperature
(°C)
20
40
For resistors operated at an ambient temperature
of 70°C or above, a power rating shall be derated
in accordance with the derating curve.
For resistors operated at a terminal part temperature of described for each size or above, a power rating shall be
derated in accordance with the derating curve. Please refer to “Introduction of the derating curve based on the terminal
part temperature” in the beginning of our catalog before use. *1 If you want to use the rated power of *1, please use the
derating curve based on the terminal part temperature on the right hand side.
ordering information
SG73G
Type
SG73G
2A
Power
Rating
1J: 0.33W
2A: 0.5W
2B: 0.5W
T
Termination
Material
T: Sn
TD
Packaging
TP: 2mm pitch punch paper
TD: 4mm pitch punched paper
TE: 4mm pitch embossed plastic
For further information on packaging,
please refer to Appendix A
1002
Nominal
Resistance
D: 3 significant figures
+ 1 multiplier “R” indicates
decimal on value <100Ω
D
Tolerance
C: ±0.25%
D: ±0.5%
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/25/17
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
59
SG73G
endured pulse power flat chip resistors
(ultra precision grade)
resistors
applications and ratings
Part
Designation
Power
Rating
@ 70°C
0.2W
SG73G1J
(0603)
0.33W*
1
––
125°C
Rated
Ambient
Temp.
70°C
Rated
Terminal
Part Temp.
125°C
±50
10 - 1M
150V
200V
T.C.R.
(ppm/°C)
Max.
Resistance
Range (Ω)
C±0.25%, D±0.5%
E-24/E-96
Absolute
Maximum
Working
Voltage
Absolute
Maximum
Overload
Voltage
Operating
Temp.
Range
0.25W
SG73G2A
(0805)
0.5W*
1
70°C
125°C
±50
10 - 1M
200V
400V
-55°C
to
+155°C
––
100°C
0.33W
SG73G2B
(1206)
0.5W*
1
70°C
125°C
±50
10 - 1M
200V
400V
––
120°C
Parentheses indicate EIA package size codes. Rated voltage =
√Power
rating x resistance value or max. working voltage, whichever is lower. If any questions should
arise whether to use the “Rated Ambient Temperature” or the “Rated Terminal Part Temperature,” please give priority to the “Rated Terminal Part Temperature.” Prior to
use and for more details refer to “Introduction of the derating curves on the terminal part temperature” in the beginning of the catalog. *1 If you want to use the rated
power of *1, please use the derating curve based on the terminal part temperature on the previous page.
environmental applications
One-Pulse Limiting Electric Power
One-Pulse Limiting Electric Power
1000
100
10
2B
2A
1J
1
0.1
.001
.01
.1
1
10
100
1000
The maximum applicable voltage is equal to the max.
overload voltage. Please contact factory for resistance
characteristics of continuous applied pulse.
Pulse Duration
(ms)
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload (Short time)
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
High Temperature Exposure
Requirement
∆
R
Limit
Within specified
tolerance
Within specified
T.C.R.
±2%
±1%
±0.5%
±2%
±2%
±1%
±(%+0.1Ω)
Typical
—
—
±0.5%
±0.75%
±0.3%
±0.75%
±0.75%
±0.3%
25°C
+25°C/-55°C and +25°C/+125°C
Rated Voltage x 2.5 for 5 seconds (2A: 0.5W rated power x 2 for 5 seconds)
260°C ± 5°C, 10 seconds ± 1 second
-55°C (30 minutes), +125°C (30 minutes), 100 cycles
40°C ± 2°C, 90%~95%RH, 1000 hours; 1.5 hr ON, 0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
+155°C, 1000 hours
Test Method
Additional environmental applications can also be found at www.koaspeer.com
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/25/17
60
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
