804-026 and 804-027
Series 804 Push-Pull High Speed Mighty Mouse
Quick-Disconnect Plug Connector • #23 Contacts
Crimp Rear Release • Ordering Information
Series 804
Mighty Mouse
Series 804 Plug Connector
with Banding Platform
Quick Disconnect
These plugs snap
securely into receptacle housings and
release with a simple pull.
Two Keying Styles
A single master
key provides fast mating in low-light
situations, or specify three keys for more
polarizing options.
Two Shell Styles
Integral platform
for direct shield attachment using
the Band-Master™ ATS termination
system, or an accessory thread for
attaching a strain relief.
How To Order
Sample Part Number
804-026
-06
Shell Style
M
Shell Material / Finish
6-7
Shell Size- Insert
Arrangement
1
4
2
3
p
Contact Type
a
Shell Key
Position
C
Series
Plug
-06
Aluminum / Black Anodize
(Non-Conductive)
roHS Compliant
Aluminum / Electroless Nickel
roHS Compliant
Aluminum / olive Drab
Cadmium over Electroless
Nickel Finish
Aluminum / Zinc-Nickel over
Electroless Nickel
C
Connector supplied
with contacts
Pin
Socket
3
P
S
for Single
Master Key
Pos. A
(Normal)
Pos. B
Pos. C
Pos. D
Pos. E
Pos. F
OMIT
A
B
C
Plug with
Banding Platform
804-026
M
6-4
1
6
5
7
2
4
NF
6-7
3
7
10
9
8
2
1
4
Pin with 30 AWG
Crimp Barrel
Socket with 30 AWG
Crimp Barrel
Connector supplied
without contacts
Pin Connector,
Less Contacts
Socket Connector,
Less Contacts
G
H
ZN
D
E
F
Plug with
Accessory Thread
804-027
Aluminum / Zinc-Nickel Black
over Electroless Nickel
Stainless Steel / Passivate
Stainless Steel / olive Drab
Chromate over Cadmium
Stainless Steel / Zinc Cobalt
Alloy / Black Chromate
ZNU
Z1
7 - 10
7
12
16
19
17
13
3
1
4
8
A
B
ZB
ZC
9 - 19
6 3
11
15
18
23
25
1
8
14
20
5
10
17
22
7
13
19
2 4
9
12
24
16
21
10-26
26
Connectors with
contacts are supplied
with signal and/or
power crimp contacts.
These contacts are not
installed.
Coaxial contacts and
non-standard signal
contacts are ordered
separately.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
C-4
E-Mail: sales@glenair.com
Quick-Disconnect Plug Connector • #23 Contacts
Crimp Rear Release • Dimensions
Key
Ø
A
.990 (25.15)
Straight
Ridges
.561 (14.25)
.060 (1.52)
.950 (24.13) Max
.561 (14.25)
.060 (1.52)
ØB
ØC ØD
ØC
ØD
Integral Band Platform
804-026-06
E Thread
Accessory Thread
804-027-06
Shell
Size
6
7
9
10
Ø A Max.
In.
mm.
.495
12.57
.575
14.61
.670
.745
17.02
18.92
ØB
In.
.286
.390
.500
.564
mm.
7.26
9.91
12.70
14.33
Dimensions
ØC
In.
mm.
.282
7.16
.351
8.92
.454
.529
11.53
13.44
ØD
In.
.313
.383
.486
.563
mm.
7.95
9.73
12.34
14.30
E Threads
.3125-32 UNEF-2A
.4375-28 UNEF-2A
.5625-24 UNEF-2A
.6250-24 UNEF-2A
Plug Key Positions
Position
A
B
C
D
E
F
A°
150°
75°
95°
140°
75°
95°
B°
210°
210°
230°
275°
275°
210°
B°
A°
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
C-5
E-Mail: sales@glenair.com
Series 804
Mighty Mouse
804-026 and 804-027
Series 804 Push-Pull High Speed Mighty Mouse
